Page 8: General
1.2 Target Group • These operating instructions are aimed at developers, planners, installers, owners and machine operators who want to safeguard their systems with safety technology from wenglor sensoric GmbH (referred to in the following as “wenglor”). • The instructions are also aimed at qualified specialist personnel, who are commissioning the SEFG safety light curtain for the first time, maintaining it or integrating it in a machine with accessories and additional products where applicable.
Page 9: Limitation Of Liability
prepared.
Page 10: For Your Safety
2. For Your Safety 2.1 Use for Intended Purpose The product is based on the following functional principle: Safety Light Curtain The Light Curtain monitors the safety field between the emitter and the receiver. If the safety field is penetrat- ed by an object, a switching command is triggered.
Page 11: Use For Other Than The Intended Purpose
• The product is not suitable for use in potentially explosive atmospheres. • The product may only be used with accessories supplied or approved by wenglor, or in combination with products approved by wenglor. A list of approved accessories and combination products can be accessed at www.wenglor.com on the product detail page.
Page 12: Important Safety Precautions
• In the event of possible changes, the respectively current version of the operating instruc- tions can be accessed at www.wenglor.com in the product’s separate download area. • Read the operating instructions carefully before using the product.
Page 13: Approvals And Ip Protection
2.7 Approvals and IP Protection RoHS 3. Product Description The SEFG safety light curtain is a piece of electro-sensitive protective equipment (ESPE) used to safeguard danger points, danger zones and accesses to machines. The ESPE monitors the safety field between the emitter and the receiver. When an object penetrates the safety field and one or multiple beams are interrupted, a switch command is triggered on both safety outputs.
Page 14 This product has the following properties: • ESPE type 4, per EN 61496-1 • PL e per EN ISO 13849-1 and SIL 3 per EN 62061 • Finger protection: 14 mm resolution, 0.25 m to 7 m range or • Hand protection: 30 mm resolution, 0.25 m to 20 m range •...
Page 15: Technical Data
4. Technical Data 4.1 General Technical Data For US and Canada: Device to be supplied by a certified Class 2 power supply that complies with the requirements according NEC and CEC. Order no. Order no. Finger protection Hand protection Emitter SEFG531…SEFG542 SEFG511...SEFG522 SEFG631…SEFG642...
Page 16 Safety outputs OSSD Safety outputs OSSD PNP semiconductor Number of safety outputs ≤ 300 mA Switching current safety output Leakage current safety output ≤ 2 mA ≤ 2.3 V Voltage drop at safety output Max. voltage in off state < 2 V ≤...
Page 17: Response Times
Finger protection Hand protection Functions Finger protection Hand protection Safety operating mode Restart inhibit Contactor Monitoring Muting Blanking SEFG431...SEFG442 and SEFG411...SEFG422 The following table specifies the tightening torques of the plugs and mounting options in order to assure compliant, error-free operation: Connection type Tightening torque (Nm) NOTE!
Page 18: Weight Tables
Hand protection Response time [ms] SEFG Muting SEFG SFH [mm] Number Basic setting Special Muting/Blanking Beams setting SEFG451 SEFG411 11.8 SEFG452 SEFG412 13.0 SEFG453 SEFG413 10.0 14.5 SEFG454 SEFG414 10.8 15.7 SEFG455 SEFG415 11.8 17.2 SEFG456 SEFG416 12.6 18.4 SEFG457 SEFG417 1061 13.6...
Page 19: Housing Dimensions Safety Light Curtain
4.4 Housing Dimensions Safety Light Curtain Figure 2: Overall housing dimensions: 1=Emitter, 2=Receiver, SFH=Safety field height NOTE! • The lower boundary of the safety field (control panel) is indicated by a line on the ESPE. • The upper boundary of the safety field is located on the bottom end of the indicator lamp cap and is also indicated by a line.
Page 20 Resolution SEFG SEFG SFH [mm] Length device L Muting Muting/Blanking [mm] 14 mm SEFGx71; SEFGx31; 30 mm SEFGx51 SEFGx11 14 mm SEFGx72; SEFGx32; 30 mm SEFGx52 SEFGx12; 14 mm SEFGx73; SEFGx33; 30 mm SEFGx53 SEFGx13 14 mm SEFGx74; SEFGx34; 30 mm SEFGx54 SEFGx14 14 mm...
Page 21: Housing Dimensions, Mounting Technology
4.5 Housing Dimensions, Mounting Technology Mounting bracket ZEFX001 • For attachment to the ends (top/bottom) of the ESPE • Scope of delivery: 1 piece • Including screws and washers Mounting bracket ZEFX002 • For attachment to the ends (top/bottom) of the ESPE •...
Page 22 Mounting bracket ZEFX003 • For attachment to the profile at the side of the ESPE • Installation in protection column Z2SSxxx • Scope of delivery: 2 pieces • Including screws, washers and slot nut Mounting bracket ZEMX001 • For wall/profile mounting •...
Page 23: Control Panel
4.6 Control Panel The different operating and parametrization states of emitters and receivers are shown via the LEDs and the segment display (receivers only). 4.6.1 Control panel emitter LEDs Display Color Power Green (GN) Supply voltage CODE Yellow (YE) Beam coding HI RAN Yellow (YE)
Page 24: Scope Of Delivery
4.7 Scope of Delivery The SEFG4xx (set) consists of the following components: • Emitter (SEFG5xx) and receiver (SEFG6xx) with the same safety field height • Quick-start guide • CD operating instructions • Test rod according to the resolution of the ESPE –...
Page 25: System Overview
4.8 System Overview Connection Equipment (Selection) Illumination Technology M12×1; 5-pin (Transmitter) Straight, PVC S35G-5M ESPE top/bottom ZEFX001* ZAS35R501 ESPE on Side Profile ZEMX001 Straight, PUR ZC4L001 10 m ESPE/Protection Column top/bottom ZEFX002 S35W-3M Angled, PVC ESPE in protection column on side profile ZEFX003 S35W-5M M12×1;...
Page 26: Accessory Products
4.9 Accessory Products 4.9.1 Mounting Elements Order no. Figure Material Assembly note ZEFX001 Plastic PA • Mounting on ends (top/bottom) of the ESPE (scope of delivery) ZEFX002 Plastic PA • Mounting on ends (top/bottom) of the ESPE • Installation in safety column Z2SSxxx ZEFX003 Stainless steel •...
Page 27: Connection Cables
M12×1; 5-pin (PUR) Straight plug ZAS35R501 Emitter 10 m ZC4L001 M12×1; 5-pin (PVC) Angle plug Straight plug S35W-3M Emitter S35W-5M S35G-5M 4.9.3 Connection Cables M12×1; 5-pin (PVC) Straight plug Receiver BG88SG88V2-2M (cascading) Safety Light Curtain...
Page 28: Safety Relays
4.9.5 Path-Folding Mirrors Possible applications can be significantly expanded through the use of a path-folding mirror. The wenglor path-folding mirror can therefore secure a danger zone from several sides with just one ESPE. NOTE! The range of the ESPE is reduced by approximately 10% per utilized mirror.
Page 29 Application example    1 Emitter 2 Receiver 3 Path-folding mirror Z2UGxxx    1 Emitter 2 Receiver 3 Safety column with path-folding mirror Z2SU00x Safety Light Curtain...
Page 30: Safety Columns
4.9.6 Safety Columns • The safety columns enable ESPE to be used in tough environments and protect them from mechanical damage. • The muting booms Z2MGxxx (see Section 4.8.9, page 31) can also be mounted on the safety columns. • Floor or wall fastening is possible depending on the mounting used. Order number Installation space Housing material...
Page 31: Io-Link Master
This guarantees the IO-Link signal extraction and enables the wTeach2 software to be used. 4.9.9 Muting Boom • The wenglor muting sets enable quick initial start-up of muting solutions. • The sets contain all required components, pre-assembled on muting booms for implementing standard muting solutions.
Page 32 Z2MG002 Z2MG003 Further information can be found in the operating instructions for the muting sets. Technical Data...
Page 33: Muting Connection Box Zfbb001
4.9.10 Muting Connection Box ZFBB001 The muting connection box ZFBB001 is connected to the extension connection of the ESPE. The following functions can be implemented with the relevant parametrization of the ESPE: • Confirmation of restart inhibit and override (connection of a button) •...
Page 34: Laser Alignment Tool Z98G001
Section 5.2.6.6.1, page 104 4.9.14 Parametrization Software wTeach2 The wenglor software wTeach2 can be used for easy parametrization and status monitoring. The connection takes place via the IO-Link master EFBL003. Further information can be found in the operating instructions for the DNNF005.
Page 35: Project Engineering
5. Project Engineering This chapter contains important information for correct integration of the ESPE in the machine. 5.1 Engineering 5.1.1 Safety Field    Sfb / range  = emitter  = receiver  = safety field SFH = safety field height Sfb = safety field width Range Resolution d Safety Light Curtain...
Page 36 Safety field The safety field is the area of the ESPE where an object (e.g. person or object) is detected according to the resolution. Safety field height The safety field height describes the dimension of the range within which a standardized test object (test rod) is recognized by the ESPE.
Page 37: Securing The Danger Zone
5.1.2 Securing the Danger Zone The danger zone must be secured by means of the ESPE alone, or by means of the ESPE in combination with additional mechanical safety devices. Reaching round the sides, over or underneath must be prevented. The danger zone may only be accessible via the ESPE’s safety field.
Page 38: Safety Clearance
5.1.3 Safety Clearance 5.1.3.1 General Information The safety clearance is the minimum distance between the safety field of an ESPE and the danger zone. It’s task is to prevent the danger zone from being reached before the hazardous motion is completed. In accordance with ISO 13855, the safety clearance is influenced by the following factors: •...
Page 39: Safety Clearance For Vertical Approach To The Safety Field
5.1.3.2.1 Safety Clearance for Vertical Approach to the Safety Field a [mm] = height of the danger zone K×T b [mm] = height of the top edge of the safety field H [mm] = reference height, height of the safety field above ground Danger zone boundary NOTE! •...
Page 40 = K × T + C Safety clearance for access through the safety field RT = Reach through Approach speed with vertical safety field K = 2000 mm/s K = 1600 mm/s (if S > 500 mm) T [s] Total response time T = (t Response time of the ESPE Response time of the safety switching device...
Page 41 a [mm] Height of the [mm] Additional horizontal clearance from the danger zone danger zone 2600 2500 2400 2200 2000 1800 1100 1100 1600 1150 1150 1100 1000 1400 1200 1200 1100 1000 1200 1200 1200 1100 1000 1000 1200 1150 1050 1150...
Page 42 Procedure when working with table 8.2.2: Required S  C Known a, S  C a, b S  C In the left column, Select the next smallest Select the next smallest search the row with the b-value b-value known value a In the relevant In the relevant In the relevant...
Page 43 Step 1: Calculate the safety clearance S for reaching through = 2,000 mm/s × ( t ) + C = 2,000 mm/s × (0.0162 s + 0.015 s + 0.3 s) + 8 ×(30 mm – 14 mm) = 790 mm ...
Page 44: Safety Clearance For Horizontal Approach To The Safety Field
5.1.3.2.2 Safety Clearance for Horizontal Approach to the Safety Field Danger zone boundary S = (K × T ) + C S = (1,600 mm/s × T ) + (1,200 mm – 0.4 × H) S [mm] Safety clearance S = (1600 mm/s × T) + (1200 mm – 0.4 × H) S may not be ≤...
Page 45 Sample calculation: An ESPE with a resolution of 30 mm and a SFH of 900 mm (SEFG416) is to be used to safeguard the area. A check must be carried out to determine whether the selected ESPE is suitable. Step 1: Calculate safety clearance •...
Page 46: Safety Clearance For Angled Approach To The Safety Field
5.1.3.2.3 Safety Clearance for Angled Approach to the Safety Field The following versions apply for applications with 5° < α < 85°. Danger zone boundary α Angle α > 30° < 30° Calculation in accor- vertical approach horizontal approach dance with (see Section 5.1.3.2.1, page 39) (see...
Page 47: Minimum Clearance To Reflective Surfaces
5.1.4 Minimum Clearance to Reflective Surfaces DANGER! Risk of personal injury or property damage with reflective surfaces within the aperture angle between the emitter and receiver! The system’s safety function is disabled. Personal injury and damage to equipment may occur. •...
Page 48: Functions
5.2 Functions This section contains important information on the functions of the ESPE and their usage conditions. 5.2.1 Functions Overview Detailed descriptions of the individual functions can be found in the following sections. Section SEFG muting SEFG muting/ blanking Operational functions Safety operating mode / automatic restart Section 5.2.3.1 Restart inhibit (RES)
Page 49 Non-safety-related functions Measured value read-out Section 5.2.6.1 Display setting (segment display) Section 5.2.6.2 Signal output Section 5.2.6.3 Integrated indicator lamp Section 5.2.6.4 Alignment aid (signal strength) Section 5.2.6.5 microSD memory card Section 5.2.6.6 Password protection Section 5.2.6.7 IO-Link 1.1 interface Section 5.2.6.8 X = function included −...
Page 50: Combinable Functions
5.2.2 Combinable Functions Safety operating mode / automatic restart Start-up disabling and restart  inhibit Contactor monitoring   Beam coding    Cascading     Muting (complete)      Partial muting   ...
Page 51: Operational Functions
5.2.3 Operational Functions 5.2.3.1 Safety Operating Mode (Automatic Restart) In this operating mode, the switching outputs are disabled when the safety field is penetrated. The switching outputs are automatically enabled after interruption of the safety field has ended. A check must be carried out to determine whether safety operating mode is permitted for the application. WARNING! •...
Page 52: Contactor Monitoring (Edm)
Note that: • The restart inhibit (RES) is parametrized on the receiver. • Enable via the signal sequence (RES input) 0  1  0 • The 1-signal must last for 0.1 s…4 s. • If the restart inhibit is deactivated, safety operating mode / automatic restart is activated automatically. 5.2.3.3 Contactor Monitoring (EDM) •...
Page 53: Range
Note that: • The receiver only detects beams which correspond to its code. • The first and the last beam in the safety field act as synchronization beams. One synchronization beam is sufficient for the receiver to assign the coding and to synchronize the emitter and receiver. •...
Page 54: Cascading
5.2.3.6 Cascading ESPE can be connected so that they all drive a single safety output in order to monitor several safety fields simultaneously. Emitter 1 and receiver 1 = master Emitter 2 and receiver 2 = slave  24 V DC F-PLC 24 V DC •...
Page 55: Cascading Via Extension Connection Of The Espe
Example for determining the response time: • Cascading of 2× SEFG413 • Response time t = 10 ms Master • Response time t = 10 ms Slave • Response time t = 10 ms + 10 ms Casc Master Slave •...
Page 56: Cascading Of Other Safety Sensors With Ossd Outputs
5.2.3.6.3 Cascading of Other Safety Sensors with OSSD Outputs WARNING! • Cascading safety sensors with OSSD outputs is not permitted. • If these sensors are used, incorrect signals may impair the safety function. 5.2.3.6.4 Cascading of Contact-based Safety Components WARNING! •...
Page 57: Muting
5.2.4 Muting Muting is a function that safely bridges the ESPE for a short time so that objects can be moved through the safety field without the OSSDs switching off. The muting cycle is activated as soon as the responsible sensors detect an object. When arranging them, it is therefore important to ensure that the muting cycle can not be triggered by a person.
Page 58 (e.g. from a sensor). NOTE! • For easy initial start-up, wenglor offers muting sets (Z2MGxxx), which can be mounted directly on the ESPE or the safety column Z2SSxxx. • Further details are available in the standard IEC 62046.
Page 59: Muting Signals
5.2.4.1 Muting Signals Muting signals are for: • Detecting the material (object) to be transported • Forwarding the detection signal to the ESPE to activate muting • Detecting the removal of the object • Forwarding the free signal to the ESPE to deactivate muting Muting signals can be generated, for example, by: •...
Page 60: Muting Visualization
5.2.4.2 Muting Visualization • The receivers have an integrated illuminated cap (see “5.2.6.4 Integrated Indicator Lamp” on page 102), which shows the muting status. • A continuous white light signals an active muting sequence. • It is also possible to connect an external muting lamp on the signal output. 5.2.4.3 Cross Muting Cross muting enables an object to be transported in or out of the danger zone.
Page 61 Calculating the minimum distance d ≥ v × (t ESPE d [m] Minimum distance between the detection points of the MS and the safety field of the ESPE (see Figure 4) v [m/s] Speed of the material on the conveyor line Processing time muting signals ESPE Is the time required by the ESPE for processing all muting signals.
Page 62 Valid muting sequence: Action Comments 1. Muting start MS1 and MS2 are activated. Both sensors must be activated within a time frame of 4 seconds. 2. Muting active MS1 and MS2, penetration of the The safety field is interrupted, the OSSDs safety field.
Page 63: 2-Sensor Linear Muting
5.2.4.4 2-Sensor Linear Muting The 2-sensor linear muting enables the user to transport an object out of the danger zone. The two MS are located within the danger zone, so that it is not possible to activate the muting from outside the danger zone. Muting is active as soon as MS1 and MS2 are activated.
Page 64 NOTE! In order to carry out a valid muting sequence, the object must have at least the length l (with l = d Example: • Belt speed v = 0.5 • Processing time muting signals = 95 ms ESPE • Response time MS = 1 ms ≥...
Page 65: 4-Sensor Linear Muting With Sequence Monitoring
5.2.4.5 4-Sensor Linear Muting with Sequence Monitoring The 4-sensor linear muting with sequence monitoring enables the user to transport an object into or out of the danger zone. Two MS are located inside and two MS are located outside the danger zone. The distances a and b represent the distances between the muting object and a separating safeguard (fence).
Page 66 Calculating the minimum distance ≥ v × (t 1/2/3/4 ESPE Minimum distance between MS1 and MS2 (see Figure Minimum distance between MS2 and safety field of the ESPE (see Figure Minimum distance between the safety field of the ESPE and MS3 (see Figure Minimum distance between MS3 and MS4 (see Figure...
Page 67 Valid muting sequence: Action Comments 1. Muting start MS1 is activated first, followed by MS2. 2. Muting active MS1 and MS2 active, penetration of The safety field is interrupted, the OSSDs the safety field (muting object moves remain in the ON state. through ESPE).
Page 68: 4-Sensor Linear Muting With Time Monitoring
5.2.4.6 4-Sensor Linear Muting with Time Monitoring The 4-sensor linear muting with time monitoring enables an object to be transported into or out of the danger zone. Two MS are located inside and two MS are located outside the danger zone. The distances a and b represent the distances between the muting object and a separating safeguard (fence).
Page 69 Calculating the minimum distance ≥ v × (t 1/2/3/4 ESPE Minimum distance between MS1 and MS2 (see Figure Minimum distance between MS2 and safety field of the ESPE (see Figure Minimum distance between the safety field of the ESPE and MS3 (see Figure Minimum distance between MS3 and MS4 (see Figure...
Page 70 Valid muting sequence: Action Comments 1. Muting start Both sensors must be activated within a MS1  MS2 are active time frame of 4 seconds. 2. Muting active The safety field is interrupted, the OSSDs MS1  MS2 are active  penetration of the safety field remain in the ON state.
Page 71: Muting Functions
5.2.4.7 Muting Functions 5.2.4.7.1 Combinable Muting Functions Signal input and configuration Parameters configuration Muting types Cross muting − − − 2-sensor linear − − − muting 4-sensor linear − − − muting with se- quence monitoring 4-sensor linear − − −...
Page 72: Belt Stop Signal
5.2.4.7.3 Belt Stop Signal The parameterizable “belt stop signal” function enables a high system availability for applications where the conveyor belt is stopped operationally. It stops the muting sequence temporarily. To this end, if there is an active signal on the “belt stop signal” input, the timers that monitor the initiation and maintenance of the muting sequence are paused.
Page 73: Muting Enable
5.2.4.7.4 Muting Enable The “Muting Enable” function is intended to provide added safety for the user when working with muting. If the function is activated during parametrization, the “Muting Enable” input is evaluated. The muting can now be enabled or blocked using the external Muting Enable signal. If the Muting Enable input is active, muting is initiated with a valid muting sequence.
Page 74: Direction Setting (Only For 4-Sensor Muting)
5.2.4.7.5 Direction Setting (Only for 4-Sensor Muting) This function increases the safety during muting by specifying and checking the sequence of the activation and deactivation of the MS. If an object passes through the safety field in a direction other than the one de- fined, the muting cycle is not initiated.
Page 75: Partial Muting
5.2.4.7.7 Partial Muting The “Partial Muting” function can be used to secure the danger zone even more effectively. With this ap- proach, only part of the ESPE (e.g. at object height) is hidden within a valid muting sequence, while the other light beams remain permanently active and cause the OSSDs to be switched off if interrupted.
Page 76: Full Muting Enable
5.2.4.7.8 Full Muting Enable For applications where the object height varies, the muting can be extended to the total safety height of the ESPE at specific times with the “Full Muting Enable” function. This function should only be used if “Partial Muting”...
Page 77: Gap Suppression
5.2.4.7.9 Gap Suppression For transport items with gaps, brief interruptions in the muting signal are to be expected. The “Gap Suppres- sion” function ensures that a brief interruption in the detection does not result in the muting being terminated. If the function is activated, interruptions of up to 250 ms are accepted in the signal from a MS. DANGER! •...
Page 78 Input ”override” penetration Override active Figure 17: Signal sequence with override DANGER! • There must be no persons in the danger zone during override. • The entire danger zone must be clearly visible by the operator during the override. NOTE! •...
Page 79: Blanking
5.2.5 Blanking Blanking is required for applications including objects which continuously protrude into the safety field, thus interrupting specific light beams of the ESPE. In order to maintain a high availability of the application even under these conditions, the interrupted beams are excluded from the evaluation during “blanking”. A safety field penetration at any other point of the ESPE switches the OSSDs and stops the hazardous motion.
Page 80 DANGER! • The blanking function poses increased risk, as the hidden area of the safety field is not monitored for penetration. • Additional measures, such as mechanical protection (see Figure 19), should be used to prevent reaching through the hidden beams. It must not be possible to reach through the “shade”...
Page 81: Fix Blanking
5.2.5.2 Fix Blanking If a fixed object is always located in the same position in the safety field, “Fix Blanking” can be used to hide individual beams. It is also possible to hide multiple objects within the safety field. Taught-in area Figure 20: Permissible object positioning with fix blanking Safety Light Curtain...
Page 82: Conditions Of Use
5.2.5.2.1 Conditions of Use • If a non-hidden beam is covered, this is classed as a penetration and the OSSDs are switched. • Hidden areas are monitored. Beams must not be detected in this area (“monitored blanking”). I.e. they must always be covered by the blanking object. If a hidden beam is uncovered, the receiver enters error state.
Page 83: Examples Fix Blanking
Figure 22: Prevention of shadow formation 5.2.5.2.2 Examples Fix Blanking Fix blanking with 1 object Beam no. OSSD status Parameters configuration: hide beam 6 – 7 – 8      Object movement 1 beam down OFF (error) ...
Page 84: Fix Blanking With Edge Tolerance
Fix blanking with 2 objects Beam no. OSSD status 10 11 Parameters configuration: hide beam 6 – 7 and       9 – 10 Object movement 1 beam down  OFF (error)   OFF (error) Object movement 1 beam up ...
Page 85: Conditions Of Use
5.2.5.3.1 Conditions of Use • If a non-hidden beam is covered, this is classed as a penetration and the OSSDs are switched. • Hidden areas are monitored. Beams must not be detected in this area (“monitored blanking”). I.e. they must always be covered by the blanking object. If a hidden beam is uncovered, the receiver enters error state.
Page 86: Effective Resolution For Calculating The Safety Clearance
5.2.5.3.2 Effective Resolution for Calculating the Safety Clearance DANGER! • The edge tolerance reduces the effective resolution of the ESPE. • The value for the effective resolution can be found in the tables below. • A new calculation of the safety clearance taking into account the effective resolution of the ESPE is essential.
Page 87 Effective resolution without construction around the sides of the hidden object • If no mechanical construction is installed in the hidden area, the effective resolution changes according to the maximum object size.  Object  Edge tolerance    Resolution (data sheet) Relevant suppression Effective resolution...
Page 88: Examples Fix Blanking With Edge Tolerance
5.2.5.3.3 Examples Fix Blanking with Edge Tolerance 1 object is hidden Beam no. OSSD status Parameters configuration: hide beam 6 – 7 – 8      Object movement 1 beam down      Object movement 1 beam up ...
Page 89: Floating Blanking
5.2.5.4 Floating Blanking In certain applications, objects which do not have a clear defined position are permanently located in the safety field of the ESPE. These could be cables or tool parts, for example, which move through the safety field for process-related reasons.
Page 90 80 mm 20 mm Tolerance 100 mm 1: Hidden object O min: minimum object size O max: maximum object size Tolerance: Suppression through object move- ment Figure 26: Object monitoring floating blanking • The maximum object speed is 0.2 m/s. •...
Page 91: Effective Resolution For Calculating The Safety Clearance
5.2.5.4.2 Effective Resolution for Calculating the Safety Clearance DANGER! • The tolerance reduces the effective resolution of the ESPE. • The value for the effective resolution can be found in the table below on page 92 . • A new calculation of the safety clearance taking into account the effective resolution of the ESPE is essential.
Page 92 Effective resolution without construction around the sides of the hidden object • If no mechanical construction is installed in the hidden area, the effective resolution changes according to the maximum object size.  1 moving object Resolution (data sheet) Relevant hiding (tolerance) Effective resolution 14 mm 1 beam...
Page 93: Examples Floating Blanking
5.2.5.4.3 Examples Floating Blanking 1 Object is hidden • Beams 1 and 15 are synchronization beams • Parameter configuration: – 1 object – Object: min. size 2 beams, max. size 4 beams Beam no. OSSD status 10 11 12 13 14 15 Parameters ...
Page 94 2 Objects are hidden • Beams 1 and 15 are synchronization beams • Parameter configuration: – 2 objects – Object 1 [O1]: min. size 2 beams, max. size 4 beams – Object 2 [O2]: min. size 2 beams, max. size 4 beams Beam no.
Page 95 Figure 27: Valid/invalid floating configurations Valid floating blanking Valid floating blanking config- Invalid floating blanking Configuration: uration, but additional penetra- configuration: • The actual number of objects • The object leaves the safety field tion. matches the number taught-in. • The actual number of objects no longer matches the number taught-in (monitored blanking).
Page 96: Reduced Resolution
5.2.5.5 Reduced resolution • This function reduces the resolution of the ESPE electronically. • This allows for the selection of an object size, as of which the safety output should be switched. • Obstructions (chips, cables) which could interrupt the safety field therefore do not cause a switch-off or interrupt the process unnecessarily.
Page 97: Example Reduced Resolution
Physical resolution Number of blocked Effective resolution Undetected object (see ESPE data sheet) beams size * 14 mm 14 mm – ≤ 3 mm 24 mm ≤ 13 mm 34 mm ≤ 23 mm 44 mm ≤ 33 mm 54 mm ≤...
Page 98: Comparison Blanking Functions
5.2.5.6 Comparison Blanking Functions Fix blanking Fix blanking with Floating blanking Reduced edge tolerance resolution Section Section 5.2.5.2, Section 5.2.5.3, Section 5.2.5.4, Section 5.2.5.5, page 81 page 84 page 89 page 96 Object movement None By ± 1 beam within Within the safety Inside and outside the safety field...
Page 99: Non-Safety-Related Functions
5.2.6 Non-Safety-Related Functions 5.2.6.1 Measuring Function • Different measuring functions can be used on the device for controlling system parts, for example. This enables muting parts to be measured or their size checked, among other things. • The recorded process data can be accessed via IO-Link. The following values (see Figure 28) can be determined via the measuring function:...
Page 100 Example of the measuring function NCBB NCBB FBB – First Beam Blocked Beam no. 6 Beam no. 6 LBB – Last Beam Blocked Beam no. 9 Beam no. 15 NBB – Numbers of Beams 4 beams 6 beams Blocked NCBB – Numbers of Cumulated 4 beams 4 beams Beams Blocked...
Page 101: Display Settings
5.2.6.2 Display Settings • The display setting can be adjusted so that it does not interfere during operation (e.g. at manual work sta- tions). • The following settings can be selected: Standard Energy saving mode LEDs Always active according to status Always active according to status Activation segment display Automatic...
Page 102: Integrated Indicator Lamp
5.2.6.4 Integrated Indicator Lamp • The receiver of the ESPE has a transparent end cap with integrated indicator lamp. • Depending on the parameter configuration and sensor, the different status of the ESPE is shown depending on the situation. The integrated indicator lamp is not monitored. This means that an indicator lamp failure has no impact on the function of the ESPE.
Page 103: Memory Function
5.2.6.6 Memory Function • The ESPE can be expanded with a microSD memory card (complementary accessories), which can be read and written on. • This enables a parameter configuration to be transferred from the memory card to the ESPE and a parame- ter configuration for a ESPE to be saved on the memory card.
Page 104: Access To The Memory Card
• File system: type FAT32 • The microSD card can be removed/replaced at any time (without impairing operation) • Preferred type (wenglor order no.): ZNNG013 5.2.6.6.3 File System The following instructions must be followed to guarantee successful use of the microSD card: •...
Page 105: Password Protection
• The ESPE (e.g. SEFG631) always saves the file in the top level of the microSD card Name Type File folder File folder HEX file HEX file • Multiple files from different ESPE (e.g.: SEFG613.hex, SEFG632.hex) can be saved in the parent folder. •...
Page 106: Io-Link Interface (C/Q)
5.2.6.8 IO-Link Interface (C/Q) IO-Link is a standardized communication system for connecting intelligent sensors and actuators to an auto- mation system. This takes place via a point-to-point connection. The IO-Link interface in the SEFG has the following function for the user: •...
Page 107: Transport And Storage
6. Transport and Storage 6.1 Transport • Upon receipt of shipment, inspect the goods for damage in transit. • In the case of damage, conditionally accept the package and notify the manufacturer of the damage. • Then return the device, making reference to damage in transit. 6.2 Storage The following points must be taken into consideration with regard to storage: •...
Page 108: Installation
• When installing the safety light curtain, it must be taken into account that the safety field width must not change when the safety light curtain is active. • Only mounting elements recommended by wenglor may be used for installation. DANGER!
Page 109: Positioning The Espe
7.1 Positioning the ESPE The following points must be observed when aligning the ESPE: Same mounting height • The emitter and receiver must be mounted parallel to each other and at the same mounting height. Parallel alignment • The emitter and receiver must be mounted so that a rectangular safety field is formed.
Page 110 Multiple systems must not influence each other Receiver Emitter Emitter Receiver • With multiple systems, it is important to ensure that a receiver is only reached by the light from the corresponding emitter. • This can be guaranteed with the following measures: –...
Page 111: Installation With Mounting Bracket
7.2 Installation with Mounting Bracket • Protect the product from contamination during installation. • Observe all applicable electrical and mechanical regulations, standards, and safety rules. • Protect the product against mechanical influences. • Make sure that the sensor is mounted in a mechanically secure fashion. •...
Page 112: Installation With Mounting Bracket Zefx002
7.2.2 Installation with Mounting Bracket ZEFX002 Figure 31: Installation with ZEFX002 7.2.3 Installation with Mounting Bracket ZEFX003 Figure 32: Installation with ZEFX003 Installation...
Page 113: Installation With Mounting Bracket Zemx001
7.2.4 Installation with Mounting Bracket ZEMX001 Figure 33: Installation with ZEMX001 7.2.5 Warning Strips • Both the emitter and the receiver of the ESPE have a yellow warning strip in a side groove on both sides. • If mounting is to take place over the side groove (see Section 7.2.2, page 112, Section 7.2.3, page 112, Section 7.2.4, page 113), the warning strip must be removed at the relevant point.
Page 114: Electrical Connection
8. Electrical Connection DANGER! Hazardous machine state Failure to comply poses risk of fatal injury! • No hazardous motions must be possible during installation, electrical connection and initial start-up. • It is important to ensure that the OSSDs of the ESPE have no impact on the machine during installation, electrical connection and initial start-up.
Page 115 System connection Receiver Emitter Expansion connection Receiver E1 (MS3 / belt stop / Full Muting Enable / cascading) E2 (MS4 / Muting Enable / cascading) E3 (MS1) E4 (MS2) RES / Override NOTE! Pin 1 and Pin 3 on the extension connection are only intended for supplying muting sensors or cascaded receivers (see EN 61496-1, Paragraph 7 a).
Page 116 The inputs of the extension connection have the following assignment with muting connection box ZFBB001: Input Input E1 Input E2 Input E3 Input E4 Input E5 Function MS3 / MS3 / MS4 / RES / override belt stop / Full MS4 / Muting Muting Enable / Enable / cas-...
Page 117: Parameters Configuration
9. Parameters Configuration 9.1 General The parameters configuration of the ESPE can be carried out via: • Keys on the emitter (see Section 9.3, page 117) and receiver (see Section 9.4, page 120) • IO-Link interface (see Section 9.5, page 150) The following applies invariably: •...
Page 118: Default Settings
9.3.1 Default Settings Function Default settings Beam coding Coding OFF Range High range 9.3.2 Calling up the Menu (User Level “Admin”) • The configuration menu can be called up from the RUN mode, as well as from error mode. • To prevent unintentional parameter configurations, the call-up of the configuration menu is divided into the following steps: 1.
Page 119: Menu Structure
9.3.3 Menu Structure The menu is laid out as follows: Range HI RANGE Coding CODE 9.3.4 Parametrization of the Range and Coding • The “Menu down” key ( ) can be used to switch between the two settings (range/coding). • The “Apply” key ( ) changes the setting within the menu item: –...
Page 120: Parametrization Of The Receiver
NOTE! • When setting the beam coding, the parameters must be configured on both the emitter and receiver (see Section 9.4.6, page 127). • To deactivate the beam coding, it must be deactivated on both the emitter and receiver (see Section 9.4.6, page 127).
Page 121: Calling Up The Menu (User Level "Admin")
Muting end through clearing of the ESPE Partial muting Full Muting Enable Gap suppression Override Display and expert menu: Display Energy saving mode Signal output Acknowledgment prompt restart inhibit Indicator lamp All (muting and OSSD status) Password protection active, 0000 9.4.2 Calling up the Menu (User Level “Admin”) •...
Page 122: Menu Structure
Password menu: • The current selected digit flashes. Password Selec- Change with Selec- Change with Selec- tion tion tion      digit digit OSSD OSSD OSSD SIG LOW SIG LOW SIG LOW ERROR ERROR ERROR Selec- Dial in ...
Page 123 Level 0 Level 1 Level 2 Level 3 Level 4 300S TIME   STOP*   ENAB*  CODE  DIRE**  CASC ESPE END***   Txxx PART T-IN   MUTG LSEQ LTME FULL*   GAPS ...
Page 124 Level 0 Level 1 Level 2 Level 3 REDU Txxx BLNK*  FIXT  OSSD DISP ENRG  CONT SYNC  SIGN LAMP  EXPT RSET <I> CARD  PASS  <R>  SAVE LOAD  SAVE CANC Input CHAN ...
Page 125: Parametrization Of The Restart Inhibit (Res)
9.4.4 Parametrization of the Restart Inhibit (RES) • For more information on the restart inhibit function, see Section “5.2.3.2 Start-Up Disabling and Restart Inhibit (RES)” on page • The following steps are used for activation or deactivation: OSSD Search RES Selection Switch on Selection...
Page 126: Parametrization Of The Contactor Monitoring (Edm)
9.4.5 Parametrization of the Contactor Monitoring (EDM) • For more information on the contactor monitoring function, see Section Section 5.2.3.3, page • The following steps are used for activation or deactivation: OSSD Search EDM Selection Switch on Selection SIG LOW ERROR OSSD OSSD...
Page 127: Parametrization Of The Beam Coding (Code)
9.4.6 Parametrization of the Beam Coding (CODE) • For more information on the beam coding function (see Section 5.2.3.4, page 52). • If beam coding is used in combination with blanking operating modes and partial muting, beam coding must first be taught in. Blanking or muting objects can then be taught in during an additional parameters configuration procedure.
Page 128: Parametrization Cascading (Casc)
9.4.7 Parametrization Cascading (CASC) • For more information on the cascading function, see Section Section 5.2.3.6, page • The following steps are used for activation or deactivation: Search OSSD Selection Switch on Selection CASC SIG LOW ERROR OSSD OSSD Switch off ...
Page 129: Parametrization Muting (Mutg)
9.4.8 Parametrization Muting (MUTG) • For more information on the muting function, see Section Section 5.2.4, page • The following steps are used for activation or deactivation: Search OSSD Selection Switch off Selection MUTG SIG LOW ERROR OSSD OSSD Cross muting ...
Page 130 The parameter configuration of the different muting functions is described in more detail in the following sections. NOTE! If muting is activated (regardless of the selected muting type), restart inhibit RES is activated automatically. Parameters Configuration...
Page 131: Parametrization Cross Muting (X)
9.4.8.1 Parametrization Cross Muting (X) • For general information on the cross muting function, see Section 5.2.4.3, page • All settings under the muting function must be carried out in one go. If the cross muting menu item is called up again, the parameter configurations must be set again for the desired options.
Page 132 Switch on • The muting can be enabled or blocked using the external Muting Enable signal. OSSD – ON: Muting enable activated. The input is evaluated and is SIG LOW OSSD required for initiating muting. ERROR SIG LOW – OFF: Muting enable input deactivated. The input is not evaluat- ERROR ed.
Page 133 Switch off • The “partial muting” function limits the impact of muting to a partial area of the safety field. OSSD – OFF: No partial muting. SIG LOW OSSD – T-IN: Teach-in the relevant muting area. ERROR SIG LOW • To do this, move an object of the desired size into the safety ERROR field Teach-in...
Page 134: Parametrization 2-Sensor Linear Muting (2L)
Switch on • The “override” function enables the OSSDs to be enabled if a penetration of the safety field is detected and the muting se- OSSD quence is not valid. SIG LOW OSSD • This can be necessary if a valid muting sequence is interrupted ERROR SIG LOW (due to a conveyor belt stop, for example).
Page 135 Switch on • The “belt stop” function stops the monitored muting counter for as long as a valid signal is present. This means that the muting OSSD duration can be extended in the event of process-related mal- SIG LOW OSSD functions.
Page 136 c) Muting enable Switch on • The muting can be enabled or blocked using the external Muting Enable signal. OSSD – ON: Muting enable activated. The input is evaluated and is SIG LOW OSSD required for initiating muting. ERROR SIG LOW –...
Page 137 f) Gap suppression Switch on • For transport items with gaps, brief interruptions in the muting signal are to be expected. The “gap suppression” function pre- OSSD vents this from ending the muting function. SIG LOW OSSD – ON: The muting signals (MS1...MS4) are delayed by 250 ms. ERROR SIG LOW –...
Page 138: Parametrization 4-Sensor Linear Muting With Sequence (Lseq) Or Time Monitoring (Ltme)
9.4.8.3 Parametrization 4-Sensor Linear Muting with Sequence (LSEQ) or Time Monitoring (LTME) • For general information on 4-sensor linear muting with sequence monitoring, see Section 5.2.4.5, page , or Section 5.2.4.6, page 68 for 4-sensor linear muting with time monitoring. •...
Page 139 c) Muting end through clearing of the ESPE Activate • The “Muting end through clearing of the ESPE” function deter- mines which signal initiates the end of the muting process. OSSD – ESPE: Muting is ended immediately after the safety field is SIG LOW OSSD freed.
Page 140 f) Override Switch on • The “override” function enables a stopped object to be removed from the muting area. OSSD • This can be necessary if a valid muting sequence is interrupted SIG LOW OSSD (due to a conveyor belt stop, for example). ERROR SIG LOW –...
Page 141: Parametrization Blanking (Blnk)
9.4.9 Parametrization Blanking (BLNK) • For general information on the blanking function, see Section 5.2.5, page • The following steps are used for activation or deactivation: OSSD Search BLNK Selection Switch off Selection Teach-in SIG LOW ERROR OSSD OSSD OSSD Reduced resolution ...
Page 142 The parameter configuration of the different blanking functions is described in more detail in the following table: a) Reduced resolution Teach-in • The parameter configuration takes place by teaching in potential obstructions. These obstructions must be brought into the safety OSSD field during the teach-in process.
Page 143: Setting The Display (Disp)
d) Floating blanking Teach-in • The parameter configuration takes place by teaching in the blanking objects. These obstructions must be brought into the OSSD safety field during the teach-in process. SIG LOW OSSD • Pressing the -key teaches in the highest value recorded ERROR SIG LOW during the teach-in process.
Page 144: Expert Menu (Expt)
9.4.11 Expert Menu (EXPT) • Advanced settings can be made in the expert menu. • The setting is carried out in the following steps: OSSD Search EXPT Selection Signal output Selection SIG LOW ERROR OSSD OSSD Indicator lamp   ...
Page 145 The parameter configuration of the different expert settings is described in the following table: a) Signal output Deactivate • Pin 6 of the IO-Link output is on the system connection of the receiver. If IO-Link communication is not active, this output can OSSD alternatively be used as a signal output.
Page 146 b) Indicator lamp Muting • The parameters for the integrated indicator lamp function can be configured by selecting LAMP. OSSD – MUT: Muting state display. SIG LOW OSSD – ALL: Muting and OSSD state display. ERROR SIG LOW • For more information on the indicator lamp, see Section 5.2.6.4, ERROR page 102.
Page 147 e) Memory card Save • If a memory card is inserted, the following options are available: – SAVE: Saves the parameter configuration most recently saved OSSD in the sensor memory to the memory card (see Section 9.4.12, SIG LOW OSSD page 149).
Page 148 Load • The parameter configuration saved on the memory card is loaded using the following steps: 1. Load the parameter configuration from the memory card: Expert Selection Memory card Selection Load settings OSSD OSSD OSSD     SIG LOW SIG LOW SIG LOW ERROR...
Page 149: Saving The Configuration And Restart (Run)
To change the password, proceed as follows: Change PW Selection Selection Change with Change with OSSD OSSD OSSD  1 digit  2 digit …   SIG LOW SIG LOW SIG LOW ERROR ERROR ERROR … Selection Confirmation Selection If all 4 digits have been entered OSSD...
Page 150: Parametrization Via The Io-Link Interface
NOTE! The latest versions of the software, IODD and the interface protocol are available on the wenglor homepage in the download area for the product. If the connection is successful, the following operating displays are shown during the parameter configuration via IO-Link (see Section 11.1.1, page 158...
Page 151: Process Data
9.5.2 Process Data The following process data is output cyclically by the ESPE: Process data Description OutputState Output status of the ESPE 8 bit encrypted InputState Status of the inputs (RES, EDM, MS1- MS4, cascading) 8 bit encrypted Parameter set A Parameter set B Measuring function Muting...
Page 152: Parameter Data
9.5.3 Parameter Data NOTE! • To prevent impermissible or unintentional changes to the ESPE, a password must be entered to carry out a parameter configuration (see Section 5.2.6.7, page 105). • Setting parameter data requires user level “Admin”. • There is only one password for the ESPE, regardless of whether the setting takes place on the control panel or via IO-Link.
Page 153: Examples For Setting The Parameter Data
NOTE! • Due to the different dependencies between the functions, it is not possible to make block changes to parameters. This means that each parameter must be written individually to the ESPE. • When changing a parameter, the data should be loaded again so that all changes are visible for any other parameters (marked in color depending on the master).
Page 154: Data Storage
Example 2: Fix blanking is to be parametrized (Teach-in) Starting point: • ESPE parameter configuration as per delivery state. • ESPE is positioned and installed correctly with the correct electrical connection. • Fix blanking is to be parametrized. 1. Password entry •...
Page 155: Initial Start-Up
10. Initial Start-Up DANGER! Hazardous machine state • No hazardous motions must be possible on the machine during installation, electrical connection and initial start-up. • It is important to ensure that the OSSDs of the ESPE have no impact on the machine during installation, electrical connection and initial start-up.
Page 156: Aligning The Emitter And Receiver
10.3 Aligning the Emitter and Receiver The signal strength is shown on the segment display for easy alignment of the emitter and receiver. This feature is active automatically for 30 s after switch-on. During parameters configuration, the display can be shown for a lengthy period of time (up through timeout) (see Section 9.4.11, page 144).
Page 157: Checking For Initial Start-Up
5. Tighten the mounting so that the ESPE can no longer be adjusted. The tightening torques for the different mounting components must be observed. NOTE! wenglor offers a suitable laser alignment tool Z98G001 to make a reliable alignment easier even with large distances (see Section 4.8.11, page 34).
Page 158: Operation
11. Operation 11.1 Operating Display Information on the status of the ESPE is output via the operating displays. For diagnostic information for the ESPE, see Section 13, page 164. Status and diagnostic information can also be read out for IO-Link. Relevant information can be found in the interface protocol of the ESPE.
Page 159: Operating Displays Receiver
11.1.2 Operating Displays Receiver OSSD SIG LOW ERROR The following status displays can be read off in normal operation: Display Explanation LED 1 lit, OSSD The OSSDs are in OFF state LED 2 off OSSD LED 1 off, OSSD The OSSDs are in ON state LED 2 lit LED off No acknowledgment required...
Page 160 The display is laid out as follows: Digit 1 Digit 2 Digit 3 Digit 4 Status displays during muting If muting is parametrized, information on the current muting sequence and diagnostic information can be read off the segment display. This information is shown as follows: Input 3 Input 4 Muting active...
Page 161: Calling Up The Current Parametrization ("Worker" User Level)
Examples: Signal is applied on E1 and E2, muting is active. E.g.: Active 4-sensor muting, where the object is activating two MS Signal is applied on E3 and E4. e.g.: Cross muting was deactivated due to clearing of the ESPE (parametrized in ESPE), even though the object is still activating two MS.
Page 162: Servicing
• No repairs may be carried out on the ESPE. • No changes or manipulations may be carried out on the ESPE. 12.1 Maintenance NOTE! • This wenglor sensor is maintenance-free. • The instructions for the annual (see Section 12.4, page 163) and daily inspection (see Section 12.3, page 163),...
Page 163: Daily Inspection
12.3 Daily Inspection The described checks are intended to confirm compliance with national / international safety regulations. NOTE! • Regulations governing operator induction by specialist personnel must be observed before work is commenced. • The company which operates the machine is responsible for training. Daily inspections must be conducted by a person who has been authorized and engaged to do so by the company which operates the machine when work begins, and whenever a new shift is started.
Page 164: Diagnosis
• Analyze and remedy the cause of the error based on the diagnosis information (see Sec- tion 13.2, page 164). • If the error cannot be eliminated, contact wenglor’s support department (see the wenglor homepage for contact details). DANGER! Risk of personal injury or property damage in case of non-compliance! The system’s safety function is disabled.
Page 165: Error Indicator On The Receiver
13.2.2 Error Indicator on the Receiver Display Error According to the diagnosis code in the segment display (see Section 13.3, page 165) OSSD 1 (red) LED lit OSSD OSSD2 LED off (green) LED off SIG LOW LED off SIG LOW ERROR LED lit ERROR...
Page 166: Codes For General Errors
13.3.2 Codes for General Errors Code Affected Status Description/cause Measures components Emitter / Temporary, restarts Parameter configuration receiver after 2 s request from normal op- eration and error mode Emitter / Temporary, restarts Parameter configuration receiver after 2 s request from normal op- eration and error mode Application errors E 010...
Page 167 E 030 Receiver Permanent • Contactor short to • Check the contactor positive function • Contactor does not • Configure the EDM drop parameters correctly • Incorrect parameter configuration E 031 Receiver Permanent • Contactor short to • Check the contactor positive function •...
Page 168 • Internal error • Disconnect the power E 2xx receiver supply and restart the ESPE. • If this error occurs repeatedly, contact the wenglor support department. E126 Receiver Permanent • SD card present but • Write SD card again file is damaged...
Page 169: Codes For Muting Errors
13.3.3 Codes for Muting Errors • The following codes are displayed until a muting cycle is initiated • The first message to occur is always shown Code Description/cause Measures Runtime error muting Restart muting and check the sequence. Time exceeded when initiating muting Time exceeded when initiating the second Restart muting and check the sequence.
Page 170: Codes When Accessing The Memory Card
OSSDs are off as a result of a slave device If the OSSDs of the slave device are switched off, switching off. the muting process is canceled on the master device. Override timeout: Max. time for static over- End override requests. Generate new override ride request exceeded (is shown for as long request if necessary.
Page 171: Decommissioning
• The ESPE neither contains nor gives off any environmentally harmful substances. It consumes minimum amounts of energy and resources. 15. Proper Disposal • wenglor sensoric GmbH does not accept the return of unusable or irreparable devices. • Respectively valid national waste disposal regulations apply to product disposal. 16. Appendix 16.1 Checklists...
Page 172 Have additional mechanical protective measures been installed which prevent reaching under, over or around the safety field, and are they protected against manipulation? Installation Have the components of the ESPE been correctly attached and secured against loosening, shifting and rotation after adjustment? Is the external condition of the ESPE and all associated system components flawless? Has the acknowledgment key for resetting the ESPE been correctly installed outside of the danger zone, and is it functional?
Page 173: Checklist Annual Inspection
16.1.2 Checklist Annual Inspection Have any changes or manipulations been carried out on the machine, which could have an impact on the safety system? Have any changes or manipulations been carried out on the ESPE, which could have an impact on the safety system? The ESPE is connected correctly to the machine.
Page 174: Checklist Daily Inspection
16.1.3 Checklist Daily Inspection The ESPE is free from visible damage. The lens cover is not scratched or contaminated. The danger zone is only be accessible via the ESPE’s safety field. Cables, plugs and mounting are in flawless condition. Checking the effectiveness of the ESPE: •...
Page 175: Connection Examples
16.2 Connection Examples 16.2.1 Connection Example Start-Up Disabling and Restart Inhibit • Start-up disabling and restart inhibit RES via ESPE • No contactor monitoring EDM • Connection to safety relay SR4B3B01S Safety Light Curtain...
Page 176: Connection Examples Muting
16.2.2 Connection Examples Muting • Start-up disabling and restart inhibit RES via ESPE • Connection to safety relay SR4B3B01S • Connection of the necessary muting components via the extension connection NOTE! Quick electrical connection of the muting components is possible via the muting sets (incl.
Page 177 Muting with connection box ZFBB001  2-sensor muting     Port 6 Port 4 Port 2  Port 5   Port 3 Port 1 F-SPS Receiver SEFGxxx Emitter SEFGxxx Connection line M12×1; 4/5-pin Connection line M12×1; 8-pin Connection box ZFBB001 MS with connection cable on M12×1;...
Page 178 Muting configuration with connection box ZFBB001  2-sensor muting with additional signal     Port 6 Port 4 Port 2  Port 5   Port 3 Port 1 F-SPS   Receiver SEFGxxx Emitter SEFGxxx Connection line M12×1; 4/5-pin Connection line M12×1;...
Page 179 Muting configuration with connection box ZFBB001  4-sensor muting     Port 6 Port 4 Port 2  Port 5   Port 3 Port 1 F-SPS   Receiver SEFGxxx Emitter SEFGxxx Connection line M12×1; 4/5-pin Connection line M12×1; 8-pin ZFBB001 Connection Box MS with connection cable on M12×1;...
Page 180: Connection Examples Cascading
 16.2.3 Connection Examples Cascading Cascading of 1 master and 1 slave system      F-SPS   Receiver SEFGxxx MASTER Emitter SEFGxxx MASTER Connection line M12×1; 4/5-pin Connection line M12×1; 8-pin Connection cable BGS88SG88VS-2M Receiver SEFGxxx SLAVE Emitter SEFGxxx SLAVE Connection line M12×1;...
Page 181  Cascading and muting with connection box ZFBB001      F-SPS     Port 6 Port 4 Port 2 Port 5 Port 3 Port 1 Receiver SEFGxxx MASTER Emitter SEFGxxx MASTER Connection line M12×1; 4/5-pin Connection line M12×1;...
Page 182: Order Notes
16.3 Order Notes The operating instructions apply for the following sensors. SEFG muting Finger protection SFH [mm] Emitter Receiver SEFG471 SEFG531 SEFG671 SEFG472 SEFG532 SEFG672 SEFG473 SEFG533 SEFG673 SEFG474 SEFG534 SEFG674 SEFG475 SEFG535 SEFG675 SEFG476 SEFG536 SEFG676 1061 SEFG477 SEFG537 SEFG677 1211 SEFG478...
Page 183 SEFG muting / blanking Finger protection SFH [mm] Emitter Receiver SEFG431 SEFG531 SEFG631 SEFG432 SEFG532 SEFG632 SEFG433 SEFG533 SEFG633 SEFG434 SEFG534 SEFG634 SEFG435 SEFG535 SEFG635 SEFG436 SEFG536 SEFG636 1061 SEFG437 SEFG537 SEFG637 1211 SEFG438 SEFG538 SEFG638 1361 SEFG439 SEFG539 SEFG639 1511 SEFG440 SEFG540...
Page 184: Eu Declaration Of Conformity
16.4 EU Declaration of Conformity The EU declaration of conformity can be found on our website at www.wenglor.com in the product’s separate download area. Appendix...
Page 185: Index Of Changes
16.5 Index of Changes Version Date Description / change 1.0.1 07/08/2019 First version 1.0.2 05/11/2019 Revision 16.6 Index of Abbreviations Version Description / change Height of the danger zone Height of the top edge of the safety field ESPE Electro-sensitive protective equipment Margin for the safety clearance Margin for the safety clearance for access over the safety field Margin for the safety clearance for access through the safety field...
Page 186 Safety clearance Safety clearance for access over the safety field Safety clearance for access through the safety field Safety Field Width Safety Field Height Safety Integrity Level SIL CL Safety Integrity Level Claim Level F-PLC Failsafe control Total response time Response time of the ESPE Response time of the safety switching device Response time of the machine...
Page 187: Index Of Figures
16.7 Index of Figures Figure 1: Product structure Figure 2: Overall housing dimensions: 1=Emitter, 2=Receiver, SFH=Safety field height Figure 3: Relationship between C and S Figure 4: Arrangement cross-muting with retro-reflex sensors Figure 5: Signal path during cross-muting Figure 6: Arrangement 2-sensor linear muting Figure 7: Signal path with 2-sensor linear muting Figure 8: Arrangement 4-sensor linear muting with sequence monitoring Figure 9: Signal path for the 4-sensor linear muting with sequence monitoring...

This manual is also suitable for:

Sefg muting Sefg muting/blanking Sefg471 Sefg531 Sefg671 Sefg472 ... Show all

Wenglor SEFG Series Operating Instructions Manual

1 General

2 For Your Safety

3 Product Description

4 Technical Data

5 Project Engineering

6 Transport and Storage

7 Installation

8 Electrical Connection

9 Parameters Configuration

10 Initial Start-Up

11 Operation

12 Servicing

13 Diagnosis

16 Appendix

14 Decommissioning

15 Proper Disposal

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wenglor SEFG Series

Summary of Contents for Wenglor SEFG Series

This manual is also suitable for:

Table of Contents
