VideoLabs Stinger Pro II User Manual

Stinger Pro II
Features
•
Easy installation
•
Captures still images up to 704x576 (4CIF) and 16.8 million colors
•
Captures video up to 640x480 (25 fps on PAL or 30 fps on NTSC)
•
Full screen video with direct draw graphic adapters
•
Drag-and-drop videos and stills into any application
Packing list
StingerPro II video board
The CD containing:
•
Drivers for Windows 3.11, 95/98/2000, and NT 4.0
•
Videum Capture application to record audio and video clips, still images, animations or to set up a webcam
•
Third-Party Application Software, in full or trial version including Microsoft NetMeeting & RealPlayer G2.
System Requirements
•
120 MHz Pentium® or faster
•
one free PCI slot
•
minimum 16MB RAM (32 or 64MB recommended)
•
Windows® 3.11, 95, 98, 2000 or NT 4.0
•
VGA display with at least 16-bit color
Installing the Stinger Pro II Video Board
Tools required: you will need a screwdriver to complete the installation. You should also wear an antistatic strap
when installing any expansion board in your computer
Caution: Electrostatic discharge can cause damage to your computer circuitry, which can be followed by complete or intermittent
failures. At a minimum, touch a piece of grounded metal (like your computer chassis) to discharge any static electricity before
starting the installation.
Hardware Installation
1. Turn off the computer and all peripheral devices and unplug the computer from the wall outlet.
2. Remove the cover of the computer so you have access to the open slots.
3. Find an available PCI slot inside your computer.
4. Remove the protective slot cover from the back of the computer using a screwdriver. Save the screw, you
will use later it to secure the board. Save the slot cover you removed for later use.
