MODEL 1501
INSTRUCTIONS AND WARRANTY FOR THE
STAND AID
STAND AID INFORMATION
OPERATING INSTRUCTIONS
REPLACEMENT PARTS
CAUTION:
All Stand Aid models should be used only on level, smooth surfaces. Please
exercise caution and good judgement when operating your unit.
STAND AID, PTA, FREEDOM CHAIR
39 Cambro Road, Clayton VIC 3168
info@mobilitycare.net.au
STAND AID MODEL 1501
SERIAL #___________
Phone:
(03) 9568 8383
1-712-324-2153 (In Iowa)
www.mobilitycare.net.au
READ complete manual
CAREFULLY BEFORE
attempting operation.
PO BOX 386
Sheldon, IA 51201
1-800-831-8580
Fax: 712-324-5210
www.stand-aid.com
Advertisement
Summary of Contents for Stand Aid 1501
- Page 1 SERIAL #___________ STAND AID READ complete manual STAND AID INFORMATION CAREFULLY BEFORE OPERATING INSTRUCTIONS attempting operation. REPLACEMENT PARTS CAUTION: All Stand Aid models should be used only on level, smooth surfaces. Please exercise caution and good judgement when operating your unit.
- Page 2 3. Make sure table is adjusted high enough so that lift arms don’t come in contact with table, causing damage. 4. Open Safety Gate, place your feet onto the floor of the Stand Aid in the Heel Straps and Toe Straps. Bring Lift Arms down to your lap, and place the Slings D- ring onto the Lift Arm Hook Slides, making sure they are secure on the Slides.
-
Page 3: Table Of Contents
Safety Gate and Back Support Options ......Pages #9-10 Battery Installation ..............Page #11 Battery Charging Information / Preventive Maintenance ..Page #12 Operating Instructions ............ Pages #13,14 Stand Aid Additional / Stand Aid Safety Switch ..... Page #15 Stand Aid Part Ordering Policies .......... Page #16... -
Page 4: Limited Warranty Information
LIMITED WARRANTY Each Stand Aid of Iowa, Inc. product has been care- fully inspected and tested before shipment. According- ly, we warrant each STAND AID which is sold against defects in workmanship and material under normal use for one year and the batteries which are warranted for 90 days. - Page 5 ATTENTION: IMPORTANT We ask that you take time to acquaint yourself with your Stand Aid, it’s adjustments and controls. We highly recommend that someone assist you as you familiarize yourself with the unit. Again, we remind you to use your Stand Aid only on level, smooth surfaces.
-
Page 6: Safety Precautions
D-rings of the sling are on the lift hooks properly. 11. Always unplug the key from the Stand Aid when unit is not in use. 12. Never operate the Stand Aid lift arms while the Safety gate is in the locked position. -
Page 7: Parts Breakdown
PARTS BREAKDOWN SAFETY GATE SEE PAGES 9 & 10. Page 7... - Page 8 STAND AID MODEL 1501 PARTS LIST REF. # PART # QTY. DESCRIPTION 1. 85002002 1/1 Lower Side Rt/Lt. 2. 85002003 Lower Front 3. 85002000 1/1 Upper Sides Rt./Lt. 4. 85002007 Floor Pan 5. 85002019 1/1 Table Hinge Rt./Lt. 6. 85002004 Table Frame 7.
- Page 9 With optional SAFETY GATE With BACK SUPPORT The “SAFETY GATE” easily attaches to the frame of the Stand Aid to give you added support. One four-inch pad and one two-inch pad will accompany the Safety Gate. It will depend on the physical build of the user as to what pad will be used.
- Page 10 With optional SAFETY GATE LATERAL BACK SUPPORT The “SAFETY GATE and LATERAL BACK SUPPORT” can also be added for those requiring more back support. This attachment easily clamps onto the Safety Gate and comes with an extra safety belt to hold the upper body snug against the back rest.
-
Page 11: Battery Installation
If you use your lift unit extensively on a daily basis, charge your bat- tery 2-3 times per week for 8-10 hours per charging session. If you put your Stand Aid in storage the battery should be fully charged and recharged every 45 days. Never let your battery go completely dead. - Page 12 CHARGING PROCESS FOR THE STAND AID MODEL 1501, PLUG THE POWER CORD INTO A WALL ELECTRICAL OUTLET, THE CHARGER IS LOCATED NEXT TO THE BATTERY IN BATTERY PAN. Please be advised that you can over-charge the battery. Stand Aid has changed the Battery Charger system.
-
Page 13: Operating Instructions
Next, remove the footpads from your wheelchair and position the chair in the rear of the Stand Aid. Loosen the foot straps on the floor of the Stand Aid and place your feet on the floor. The strap that fits over the top of your instep should be snug but not tight. - Page 14 Once you have entered the Stand Aid 1501 and are in an upright posi- tion, close the safety gate behind you and adjust the unit to the correct height by loosening the four knobs for upper side adjustment. Raise or lower the upper side rails of the Stand Aid until the safety gate is support- ing the lower half of the buttocks.
-
Page 15: Stand Aid Additional / Stand Aid Safety Switch
STAND AID SAFETY SWITCH Stand Aid of Iowa has added a safety switch to the 1501 model. This switch is located in front of the knee pad and to the right; it is silver in color. The safety switch will allow the user to oper-... - Page 16 PERTAIN TO ANY ORDER UNDER $300.00 UNLESS OTHER ARRANGEMENTS HAVE BEEN MADE. RETURN GOODS: PLEASE CALL STAND AID OF IOWA SERVICE DEPARTMENT FOR A RETURN AUTHORIZATION NUMBER (RA#). WARRANTY PARTS AND EXCHANGE PARTS CAN BE RETURNED AT NO CHARGE. ALL OTH-...
- Page 17 THE FOLLOWING IS A COMPLETE DESCRIPTION OF THE STAND AID #1501. STAND AID; battery operated lift, brings a person from a seated to passive standing posi- tion. Adjustable frame to accommodate persons 4’2” to 7 ft. tall. Frame is constructed of steel, round and square.
