Summary of Contents for Discovery Telecom ESIM120
- Page 1 GSM Gate Controller eSIM120 GPRS USeR ManUal Тел: +7 495 7907870 Моб: +7 965 4429948 Skype: Discoverytelecom Mail: info@discoverytelecom.ru www.discoverytelecom.ru...
-
Page 2: Table Of Contents
Content 1. operation description ..............3 2. GPRS configurations and activation ........... 4 2.1. Configuring standart GPRS parameters ..........4 2.2. Standart GPRS parameters ..............4 2.3. GPRS activation ..................5 2.4 Additional Commands via SMS Messages ........5 3. Configuration Using Internet Browser .......... 6 3.1. -
Page 3: Operation Description
After activating Server mode the administrator connects directly to ESIM120 using web browser. However, this mode will operate only in the case GSM operator of the SIM card used in the device provides a static IP address. -
Page 4: Gprs Configurations And Activation
Here in the place of “settings” and “parameters” enter the corresponding commands from Table 1. For example, sending SMS message „1111 setgprs:type:client“ you indicate to ESIM120 to work in Client mode from the next session. All standart GPRS parameters with detailed information is provided in Table 1. -
Page 5: Gprs Activation
Here “settings” and “parameters” are corresponding entries from Table 1. For example, sending SMS message „1111 connect:type:client“ you indicate to ESIM120 to work in Client mode in the upcoming session (other parameters will be the same as standart GPRS parameters). To specify more than one parameter, you have to separate settings and parameters with ';' symbol (for example, sending SMS message „1111... -
Page 6: Configuration Using Internet Browser
3.1. Login to Configuration Webpage ESIM120 configuration webpage is accessible on the address that is formed referring to what mode is supported at that time: Client mode. Upload www.eldes.lt/login webpage to login with received username and password (use default GPRS •... -
Page 7: Basic Configuration
2 Delay - Output impulse duration. The default parameter set by the manufacturer is 2 seconds. Sh1... 8 - The number of scheduler according to which the specified output operates. For more information please refer to chapter 3.6. ESIM120 GPRS USER ManUal... -
Page 8: Users Settings
3.2.5 SMS Language The system ESIM120 communicates with the user via SMS messages, which are used for sending various informational messages about system status. For the sake of comfort the user has an option to choose the language in which the SMS messages will be delivered: •... -
Page 9: Gprs Settings
Profile – Code name of the current GPRS parameters. The initial name provided by the manufacturer is profile1. Client – Gate controller ESIM120 is accessible via Internet browser through the intermediate server. Server – The device will operate in Server mode, i. e. it will be accessible directly via Internet browser without the use of any other additional programs. -
Page 10: User Database
By opening the section Data Base View from the initial menu you will be able to review all information of users, stored in the database, who can control gate controller ESIM120 output signals by phone call. It also provides brief database statistics. Up to 100 users per webpage are indicated. -
Page 11: Advanced Data Base Configuration
You can search for one number at a time. Once the user is found in the database, the following information can be edited: ESIM120 GPRS USER ManUal... -
Page 12: Log Management
Ring Count - Specified user validation limit according to the set quantity of phone calls to ESIM120. The user is automatically deleted from database as soon as the set value of phone calls is depleted. Maximum value is 4294967296. -
Page 13: Clock Settings
(-s) control by the specified user stored in the user database will be activated. Mo – monday, Tu– tuesday, We – wednesday, Th – thursday, Fr – friday, Sa – saturday, Su – sunday, All – always. ESIM120 GPRS USER ManUal... -
Page 14: Troubleshooting
4. troubleshooting the connection with the device is lost during configuration (a browser window informing about the lost connection with the server opens). Problem causes and possible solutions: • Interrupted GPRS connection with the device. Click the button Refresh in the toolbar of the Internet browser. If browser window informing about the lost connection with the server opens repeatedly, send SMS message with the text xxxx gprsreset, where “xxxx”...
