Solgaz SP-34-PM Operation Manual

Built-in-combination steam oven with hot air and microwave
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SOLGAZ
Sp. z o.o.
www.solgaz.eu
Operation manual
Built-in-combination steam oven
with hot air and microwave
model
SP-34-PM
Read these instructions carefully before using
your microwave oven, and keep it carefully.
If you follow the instructions, your oven will provide you
with many years of good service.
SAVE THESE INSTRUCTIONS CAREFULLY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP-34-PM and is the answer not in the manual?

Questions and answers

Related Manuals for Solgaz SP-34-PM

Summary of Contents for Solgaz SP-34-PM

  • Page 1 Operation manual Built-in-combination steam oven with hot air and microwave model SP-34-PM Read these instructions carefully before using your microwave oven, and keep it carefully. If you follow the instructions, your oven will provide you with many years of good service.

  • Page 2: Table Of Contents

    CONTENTS CONTENTS PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY ADDENDUM SPECIFICATIONS IMPORTANT SAFETY INSTRUCTIONS TO REDUCE THE RISK OF INJURY TO PERSONS GROUNDING INSTALLATION SETTINGUPYOUROVEN IMPORTANT INFORMATION ABOUT INSTALLING FITTED UNITS INSTALLATION DIMENSIONS BUILDING IN 10-11 BEFORE FIRST USE OPERATION INSTRUCTION 13-30 TROUBLESHOOTING...

  • Page 3: Precautions To Avoid Possible Exposure To Excessive Microwave Energy

    PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since this can result in harmful exposure to microwave energy. It is important not to break or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces.

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTION WARNING To reduce the risk of fire, electric shock, injury to persons or exposure to excessive microwave oven energy when using your appliance, follow basic precautions, including the following: 1. Warning: Liquids and other foods must 13. Install or locate this oven only in not be heated in sealed containers since accordance with the installation they are liable to explode.
  • Page 5 23. Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling the container. 24.Children should be supervised to ensure that they do not play with the appliance. 25.The appliances are not intended to be operated by means of an external timer or separate remote-control system.

  • Page 6: To Reduce The Risk Of Injury To Persons Grounding Installation

    To Reduce the Risk of Injury to Persons Grounding Installation DANGER 2)The extension cord must be a grounding- type 3-wire cord. Electric Shock Hazard 3)The long cord should be arranged so Touching some of the interna components that it will not drape over the counter top or can cause serious personal injury or death.
  • Page 7 UTENSILS See the instructions on "Materials you can use in microwave oven or to be avoided in microwave oven." There may be certain non-metallic utensils that are not CAUTION safe to use for microwaving. If in doubt, you can test Personal Injury Hazard the utensil in question following the procedure below.

  • Page 8: Settingupyouroven

    Materials to be avoided in microwave oven Utensils Remarks Aluminum tray May cause arcing. Transfer food into microwave-safe dish. Food carton with May cause arcing. Transfer food into microwave-safe dish. metal handle Metal or metal- Metal shields the food from microwave energy. Metal trim may trimmed utensils cause arcing.

  • Page 9: Important Information About Installing

    IMPORTANT INFORMATION ABOUT INSTALLING • This appliance is NOT intended for use in a commercial environment. • Please observe the installation instructions provided and note that this appliance should only be installed by a qualified technician. • The appliance is fitted with a plug and must only be connected to a properly installed earthed socket.

  • Page 10: Fitted Units

    Installation dimensions min 45 min 45 Ventilation grid Cupboard feet Note: There should be gap above the oven. Building in • Do not hold or carry the appliance by the door handle. The door handle cannot hold the weight of the appliance and may break off. 1.
  • Page 11 Fully insert the appliance and centre it. Do not kink the connecting cable. Screw the appliance into place. The gap between the worktop and the appliance must not be closed by addtional battens.

  • Page 12: Before First Use

    BEFORE FIRST USE Initial cleaning and heating Removing the microwave oven all of the protection foil on the front. For more information see the "CLEANING". Before the first use of the appliance, ￭ Remove all accessories and wash out of the microwave. ￭...

  • Page 13: Operation Instruction

    OPERATION INSTRUCTION Control Panel This microwave oven uses modern electronic control to adjust cooking parameters to meet your needs better for cooking. 1.Clock Setting When the microwave oven is electrified, "00:00" will blink, buzzer will ring once. 1) Press " "...
  • Page 14 Microwave Power Chart Microwave Power 100% Display 900W 700W 450W 300W 100W You can see from the table below from which power levels you can choose and for which foods the power levels are suitable. Power level Food 900 W - Boiling water, reheating - Cooking chicken, fish, vegetables 700 W...
  • Page 15 4. Convection Cooking 1) Press the " " button to activate the microwave function. "01:00" displays and the microwave icon appears. 2) Press " " or " " or " " to select convection mode. The default temperature is 180 degrees. 3) Press "...
  • Page 16 6. Microwave + Grill Cooking 1) Press the " " button to activate the microwave function. "01:00" displays and the microwave icon appears. 2) Press" " or " "or " " to select the " MW+GRILL" combination mode. 3) Press " "...
  • Page 17 7) Press" " to select the time setting mode. The default time is 10 minutes. 8) Press" "or " " to select the cooking time . The MAX.time is 90 minutes. 9) Press " " button to start cooking. 8. Microwave + Grill Fan Cooking 1) Press the "...
  • Page 18 Note: 1) For non-steam menu (P01-P20), press " " to confirm menu selection and enter the weight of menu selection state automatically, at this point, you can press " " or " ", choose the automatic menu weight cooking time display. 2) For the steam menu, at this time, if you need to adjust the default cooking time, you can press , and makes the default cooking time of flashing, at this point,...
  • Page 19 12. Steam Function 1) In standby mode, press " " button, enter the steam mode, time lights up by default 10:00. Press the key several times, in steam mode swich between other work. You can also press " " or " "...
  • Page 20 14. Microwave+Steam Function 1) In standby mode, press " " button, enter the steam mode, time lights up by default 10:00. Press the key several times, in steam mode switch between other work. You can also press " " or " "...
  • Page 21 16. Display Specification (1) When setting, if no other operation,it will confirm automatically after 10 seconds. Except clock setting for the first time. (2) During setting program, after adjusted for 3 seconds, it will confirm automatically. Except auto menu, it will confirm after adjusted for 10 seconds. (3) When the oven is in setting state or pause state, including auto menu and defrost program, if no operation in 5 minutes, it will enter into the off state.
  • Page 22 Defect codes Below defect codes may occur during steam functions : E-06: 1-Water tank is not close well. E-05: water system abnormal, need to contact for Engineer to check, below is the possibilities. 1-The water sensor is abnormal. 2-The water pipe is abnormal. 3-The water pump is abnormal.
  • Page 23 STEAM MENU AUTO-MENU DISPLAY WEIGHT POWER Steam100℃ Trout +300W Steam100℃ Salmon Filet +100W Steam100℃ Pikeperch +300W Prawns Steam100℃ Steam100℃ Halibut filet +300W Cockles Steam100℃+100W Steam100℃ Cod filet +300W Steam100℃ Herring +300W Steam100℃ Tuna filet +100W...
  • Page 24 Steam100℃ Crab +300W Chicken leg Steam100℃+300W Chicken Steam100℃ breast +300W Steam100℃ Meatball +300W Turkey Steam100℃ escalope +300W Pork filet, Steam100℃ whole +300W Steam100℃ Sausages +100W Eggs in Glass Steam100℃ Eggs, hard Steam100℃ Eggs, soft Steam100℃ 200g+400mL Brown rice + Steam100℃+ 450W/ water Steam100℃+ 300W 400g+800mL...
  • Page 25 Steam100℃+300W Eggplant/ Aubergine Steam100℃ +300W Beans Steam100℃ Broccoli Steam100℃ +300W Cauliflower Steam100℃ +300W Peas Potatoes with skin Steam100℃+ 300W （whole, small） Potatoes with skin Steam100℃ (whole, big) Potatoes without skin Steam100℃+ 300W (pieces) Steam100℃+300W Carrots Steam100℃+300W Corn cobs...
  • Page 26 Steam100℃ Bell peppers Steam100℃ Hot peppers Steam100℃+300W Mushrooms Steam100℃+300W Leeks Steam100℃ Brussels sprouts Steam100℃+300W Celery Steam100℃+100W Asparagus Steam100℃+300W Spinach Steam100℃+300W Courgette...
  • Page 27 NO-STEAM MENU DISP AUTO-MENU WEIGHT POWER 450W Melt chocolate 450W 450W 450W Melt butter 450W 450W 100W+220℃ Sweet potato 100W+220℃ 100W+220℃ 100W+220℃ 1000 100W+220℃ Chicken Whole 1200 100W+220℃ 450W+220℃ 450W+220℃ 450W+220℃ Chiken leg 450W+220℃ 450W+220℃ 450W+220℃ 450W+220℃ 300W+220℃ 300W+220℃ 300W+220℃ Chiken Wings 300W+220℃...
  • Page 28 450W+220℃ 450W+220℃ 450W+220℃ Roast Pork 450W+220℃ 450W+220℃ 450W+220℃ 1000 450W+220℃ 100W+220℃ 100W+220℃ Chicken kabobs 100W+220℃ 100W+220℃ 100W+220℃ Pre-heat/220℃ Shrip Pre-heat/220℃ Pre-heat/220℃ 100W+220℃ 100W+220℃ 100W+220℃ Beef steak 100W+220℃ 100W+220℃ 100W+220℃ 1000 100W+220℃ 100W+220℃ barbecued 100W+220℃ Sparenes 100W+220℃ Chocolate Pre-heat/180℃ cookies lemon cookies Pre-heat/200℃...
  • Page 29 (+800ml cold water) 700W Pasta (+1000ml cold water) (+1200ml cold water) Soup 900W Pizza 900W Muffin 900W 50+500ml water 100+1000ml water Oatmeal 900W/450W 150+1500ml water Baked Apple 700W Sandwich 900W Popcorn 900W Fudge Brownies 100W+180℃ Bread Grill Level3 Chick nuggets 100W+220℃...
  • Page 30 peanut chocolate Pre-heat/180℃ cookies hanburg 100W+220℃ Pre-heat/180℃ Muffin (70g*12)

  • Page 31: Troubleshooting

    TROUBLE SHOOTING It is forbidden to run the unit without any food inside. It is very dangerous. According to Waste of Electrical and Electronic Equipment (WEEE) directive, WEEE should be separately collected and treated. If at any time in future you need to dispose of this product please do NOT dispose of this product with household waste.

This manual is also suitable for:

Tr934f6h-s00eTr934f2h-s00e
