- Page 1 ASSEMBLY INSTRUCTIONS 72" x 36" Conference Table W- Metal Base Lot Code # NEED HELP? Call 1−800−950−4782 www.bushbusinessfurniture.com Part Number A176663A Keep manual for future reference.
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION A176663A WARNING Do not move unit when loaded. Doing so could cause instability, product collapse, tip over, and/or serious injury. No mueva la unidad cuando esté cargada. Hacerlo puede causar inestabilidad, que el producto se derrumbe, que se la caiga encima y/o heridas (golpes) serias. - Page 3 EXPLODED VIEW A176663A 99BTOP7236AAC 99BTOP7236ACS [ 1 ] W176667 [ 1 ] W176664 99BTOP7236SG 99BTOP7236AMR [ 1 ] [ 1 ] W186894 W176665 99BTOP7236HC 99BTOP7236AMC [ 1 ] W179036 [ 1 ] W176666...
-
Page 4: Exploded View
EXPLODED VIEW A176663A 99YLEGSV - QTY 2 [ 2 ] H171568 [ 4 ] H172193 99STCH72ASV - QTY 1 [ 1 ] H172866 [ 1 ] H176662... -
Page 5: Fasteners / Hardware
FASTENERS / HARDWARE A176663A Fasteners are shown in actual size. los fijadores son demonstrados en su tamaño actual. les attaches sont montrées dans l'échelle grandeur. H175656 [ 6 ] [ 4 ] H172201 Spacer Leveler [ 6 ] H172196 [ 22 ] H142302 #10 x 3/4"... - Page 6 A176663A STEP [ 2 ] H172195 H175656 [ 2 ] 3/8−16 X 1−3/4" Spacer [ 2 ] H172196 [ 2 ] lock Nut 3/8-16 9/16" Safety glasses gafas de seguridad Lunettes de protection...
- Page 7 A176663A STEP [ 2 ] H172195 H175656 [ 2 ] 3/8−16 X 1−3/4" Spacer [ 2 ] H172196 lock Nut 3/8-16 Safety glasses gafas de seguridad Lunettes de protection [ 2 ] 9/16"...
- Page 8 A176663A STEP [ 2 ] H172195 H175656 [ 2 ] 3/8−16 X 1−3/4" Spacer [ 2 ] H172196 lock Nut 3/8-16 Safety glasses gafas de seguridad Lunettes de protection [ 2 ] 9/16" An assistant may be required. Un asistente puede ser necesario.
- Page 9 A176663A STEP [ 22 ] H142302 #10 x 3/4"...
- Page 10 A176663A STEP [ 20 ] H23682 [ 4 ] H172201 #10 x 1" Leveler An assistant is required. Es necesario un ayudante. Un assistant est nécessaire. Tighten all screw. Apriete todos los tornillos. Serrez toutes les vis.
- Page 11 A176663A STEP With an assistant carefully stand unit upright. Con un asistente cuidadosamente levante la unided a una posicion vertical. Avec l'aide d'un assistant placez soigneusement l'unité debout. [ 1 ] H84026 Grommet...
- Page 12 A176663A STEP Maximum Weight: 200 Lbs. Peso Máximo: 200 Libras Poids Maximum: 90.7 kilogramme...
