Raven Steel Hang-On Stand
MODEL: PVHO-200
• Always Wear a Safety Harness with this Product
• Practice Using at Ground Level
• Weight Limit: 300 lbs.
• Tree Size: 9"-18" diameter
L
E
W A R N I N G
Every year serious injury or death can occur from hunting related accidents. To ensure your safety, please completely read and follow this safety manual
and all warning labels before assembling, installing or utilizing this product.
Do not use this product before fully understanding all safety warnings and instructions. If you have questions, are unsure about any information or need additional
information concerning your product, contact our customer service department at 1-866-972-6168 or visit www.Primaltreestands.Com. Keep and
maintain this safety and instruction manual in a safe location for future reference.
Distributed by Primal Vantage Company Inc., 2407 W. Euclid Ave., Littleton, CO 80120
Instruction and Safety Manual
K
D
SAFETY MUST BE YOUR FIRST PRIORITY WITH THIS PRODUCT
H
B
G
C
F
A
Thank you very
much for choosing
We appreciate
your business!
©2020 (rev. 1/20)
Advertisement
Summary of Contents for PRIMAL TREESTANDS PVHO-200
- Page 1 Instruction and Safety Manual Raven Steel Hang-On Stand Thank you very much for choosing MODEL: PVHO-200 • Always Wear a Safety Harness with this Product • Practice Using at Ground Level We appreciate • Weight Limit: 300 lbs. your business! •...
- Page 2 Treestand Safety Warnings Please read the following instruction manual and warnings labels completely before utilizing this product. Failure to understand and execute the instructions and warnings may result in serious injury or death. In the event of an accident, have a plan for rescue, including the use of devices that may be easily reached while suspended.
- Page 3 Treestand Safety Warnings NEVER adjust your stand while in use. Practice the attachment of this treestand at ground level before using in a hunting environment. ALWAYS ensure that you and your treestand are safely secured to a healthy tree. Your tree stand MUST be attached tightly to the tree and secured in place. If the stand is not secure, it may shift while in use, resulting in serious injury or death.
-
Page 4: Proper Care And Maintenance
Choosing A Safe Tree • ALWAYS thoroughly inspect the tree before installing your product. DO NOT install your TREE/LADDER STAND onto any dead or unsafe tree, telephone or utility pole, structural column, or man-made structure. Doing so may result in serious injury or death. •... - Page 5 Raven Steel Hang-On Stand MODEL: PVHO-200 • Always Wear a Safety Harness with this Product • Weight Limit: 300 lbs. • Practice Using at Ground Level • Tree Size: 9”-18” diameter PARTS LIST 1 Foot Platform......Part # PFP-538 1 Seat Platform......
- Page 6 Model: PVLS-200 Assembly Instructions Page 1 Raven Steel Hang-On Stand Attach Top Tree Brace to Vertical Support using 1-M8x40mm bolt. Attach Bottom Tree Brace to the rear of Foot Platform using 2-M8x55mm bolts Attach to the opposite side from the ring and 1-M8x40mm bolt.
- Page 7 Model: PVLS-200 Assembly Instructions Page 2 Raven Steel Hang-On Stand LEFT SIDE Cable to Vertical Support CLOSEUP Washer Washer Cable Washer RIGHT SIDE CLOSEUP Washer Washer Attach one end of Cable to the front of Foot Platform using 1-M8x48mm bolt with 3 washers on both sides.
- Page 8 Model: PVLS-200 Assembly Instructions Page 3 Raven Steel Hang-On Stand Attach Seat Platform to the top of Vertical Support using 1-M8x63mm bolt with 3 washers on each side. Insert a washer on the bolt, then insert the bolt through Vertical Support , insert another washer on the bolt, then insert the bolt through Seat Platform...
-
Page 9: Installation Instructions
Model: PVLS-200 Installation Instructions Raven Steel Hang-On Stand FIG.1 FIG.2 STEP 2: With the treestand in the folded position, wrap Tree Strap around the tree once and hook STEP 1: While wearing your the other end into the tree strap bracket. (See safety harness, connect your Fig.1 and Fig. - Page 10 W A R N I N G Failure to follow all warnings listed below could result in serious injury or death. NEVER leave the ground without checking every ladder DO NOT use this tree stand while under the influence of ALWAYS read and understand all warnings and instructions section connection to ensure they are firmly connected.
