This is a safety alert symbol and should never be ignored. When you see this symbol on labels or in manuals, be alert to
the potential for personal injury or death.
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, personal
injury or loss of life. Installation and service must be
performed by a licensed professional installer (or
equivalent), service agency or the gas supplier.
As with any mechanical equipment, personal injury can
result from contact with sharp sheet metal edges. Be
careful when you handle this equipment.
BG802DFE Gas Furnace
The BG802DFE gas furnace is shipped ready for
installation in the downflow position fueled by natural gas.
A conversion kit (ordered separately) is required for use in
LP/ Propane gas applications.
Manufactured By
Blue Summit LLC
8201 C National Turnpike
Louisville, KY 40214
508145-01B
INSTALLATION INSTRUCTIONS
BG802DFE
Warm Air Gas Furnace
Downflow Air Discharge
This manual must be left with the homeowner for future reference.
WARNING
CAUTION
Table of Contents
BG802DFE Gas Furnace .......................................... 1
Unit Dimensions ........................................................ 2
Parts Arrangement..................................................... 3
Shipping and Packing List ......................................... 4
Safety Information ..................................................... 4
General ...................................................................... 6
Combustion, Dilution & Ventilation Air ....................... 6
Downflow Installation ................................................. 9
Filters ........................................................................11
Duct System .............................................................11
Venting..................................................................... 12
Gas Piping ............................................................... 17
Electrical .................................................................. 19
Integrated Control DIP Switch Settings ................... 27
On-Board Links and Diagnostic Push Button .......... 27
Unit Start-Up ............................................................ 28
Other Unit Adjustments............................................ 31
Heating Sequence of Operation .............................. 31
Service..................................................................... 32
Repair Parts List ...................................................... 34
Blower Performance ................................................ 35
*P508145-01B*
Issue 2108
(P) 508145-01B
Page 1 of 36
Advertisement
Table of Contents
Related Manuals for Alpine Home BG802DFE
Summary of Contents for Alpine Home BG802DFE
-
Page 1: Table Of Contents
INSTALLATION INSTRUCTIONS BG802DFE Warm Air Gas Furnace Downflow Air Discharge This manual must be left with the homeowner for future reference. This is a safety alert symbol and should never be ignored. When you see this symbol on labels or in manuals, be alert to the potential for personal injury or death. -
