LT 208.050 Manual

ASSEMBLING OF THE CAN-OPEN;
• Fixe the standby bolting to the table with 4 screws.
• Fixe the stand with a clamp fi xation. Tighten very hard so that the base can't move when you open
a can.
• Fixe the stand with wall! fi xation hang on the wall (about 70/80 cm height).
Put the can-opener in the place allowed in the base, the blade facing the base.
UTILISATION
Disengage the knurled wheel in displacing the
Lift the can-opener and place the can against the
Let the tool drop and push down so that the blade
208050 en ma 2012.07
*208.050 CAN-OPENER - MANUAL
rilsan lever to the left.
pillar.
pierces the can lid
No. REF. DESCRIPTION
réf.
1 02870 RILSAN LEVER
2 02830 BLADE
3 02873 COURBANE RING
4 OX873 ST/ST RING
5 02877 BLADE SCREW
6 02872 NICKELED STEEL PLAQUETTE
7 02820 COG-WHEEL
8 02810 BODY ALONE 02
9 SQUARE 02
10 02888 SCREW 6X10 FOR 02
02840 HANDLE FOR CAN OPENER 02
OX842 HANDLE + CLIP FOR 02
02880 BED PLATE TO BE BOLTED EPOXY 02
02890 CLAMP BASE EPOXY 02
