  • Page 1 English User's Manual ® F980 Color Display Monitor...

  • Page 2: Table Of Contents

    Controls & Connectors ··················································· 10 Front ···················································································· 10 Rear ····················································································· 10 1 INSTALLATION 1-1 Connecting the Monitor to the PC ·························· 11 1-2 Using the AUTO-SIZING Button ······························ 12 1-3 Setting the Resolution ············································· 13 2 ADJUSTMENTS & SETTINGS USING THE SCREENMANAGER 2-1 About ScreenManager ·············································...
  • Page 3 Eizo Nanao Corporation. Eizo Nanao Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to Eizo Nanao Corporation's receipt of said information.

  • Page 4: Precautions

    Apparaten skall anslutas till jordat nätuttag. IMPORTANT! To ensure personal safety and proper maintenance. Please read this section and the caution statements on the monitor (refer to the figure above). This manual uses the safety symbols below. They denote critical information.
  • Page 5 If the monitor falls, disconnect the power immediately and have the unit checked by a qualified service engineer before using it again. Using a monitor after it has been dropped may result in fire or electric shock. • Keep the plastic packing bags away from children and infants.
  • Page 6 By not doing so may result in fire or electric shock. • Handle the power cord with care. * Do not place the cord underneath the monitor or other heavy * Do not pull on the cord. * Do not attempt to repair a damaged cord.
  • Page 7 Touching the plug with wet hands is dangerous and can cause electrical shock. • At the end of the day or if you plan to leave the monitor unused for an extended period, after turning off the power switch disconnect the power cord from the wall socket so that no power connections are made.
  • Page 8 PRECAUTIONS For users of the EIZO optional i ·Sound™ sound unit and i ·Station™ USB hub • When adjusting the viewing angle of the monitor, do not do so by handling the sound unit or USB hub. Adjusting the monitor in this way may break the unit or cause bodily injury.

  • Page 9: Introduction

    INTRODUCTION About This Manual This manual explains the precautions, features, specifications, and operation of your EIZO monitor. For convenience, a “ScreenManager Quick Reference” guide has been included which shows how to implement basic adjustments with the ScreenManager utility. Package Contents:...

  • Page 10: Controls & Connectors

    Off Timer Mode (Flashing) See page 34. Power Terminal Covers for the Optional i·Sound Sound Unit Maintenance port Allows EIZO optional utilities to be attached. USB Ports (Upstream port x 1, Downstream ports x 3) See page 36 for further details.

  • Page 11: Installation

    13W3 pin MD-C88 (enclosed) Using the monitor with Windows A monitor information file is saved in the EIZO CRT Utility Disk included in the package. It includes all the required information for best operation with Windows 95/98. Please install the enclosed utility and select your model name from the monitor list in Windows 95/98.

  • Page 12: Using The Auto-Sizing Button

    4) Plug the power cord into the power connector at the rear of the monitor. Then plug the other end of the cord into a power outlet. WARNING • The equipment must be connected to a grounded main outlet. 5) Turn on the monitor power first, then switch on the PC power. The monitor’s power indicator (LED) will light up (green).

  • Page 13: Setting The Resolution

    VESA. The best way to see if the monitor will work with a given resolution and rate, is to compare the vertical refresh rate of the graphics board to the monitor’s range (Refer to the graphics board...
  • Page 14 2) Connect one PC to the monitor’s D-Sub connector and another to the BNC connector securely. The BNC connection should be made with an EIZO BNC cable, available as an option. Contact EIZO dealers for information about optional cables. (Example)

  • Page 15: Adjustments & Settings Using The Screenmanager

    2 ADJUSTMENTS & SETTINGS USING THE SCREENMANAGER 2-1 About ScreenManager How to Use the ScreenManager Entering the ScreenManager Press the ENTER key to display the ScreenManager Main menu. Making the adjustments and settings 1) Select the desired icon using the Arrow keys, and then press the ENTER key to display the Sub menu.

  • Page 16: Screenmanager Menus

    ScreenManager Menus ScreenManager consists of a main menu and six sub menus: “Screen”, “Color”, “PowerManager”, “Others”, “Information” and “Language.” Animated icons on each menu allow for easy adjustment. Main menu • The menu message for the ScreenManager can be displayed in six languages: English, German, French, Italian, Spanish and Swedish.
  • Page 17 Menus <PowerManager> Power saving settings. <Others> • Degaussing • Input-signal priority selection for two signal connections • Beep On/Off • ScreenManager menu position • ScreenManager menu contrast • Signal filter setting 1 • Signal filter setting 2 • Off Timer •...

  • Page 18: Shortcut Keys

    See the diagram described below for adjustment directions. Adjustment Lock The ScreenManager operation can be disabled by holding down the AUTO-SIZING button while switching on the monitor’s power. This will disable (“lock”) the ScreenManager and AUTO-SIZING button, protecting from accidental changes. To unlock the buttons: switch the power off, then hold down AUTO-SIZING button once again and turn the power back on.

  • Page 19: Imaging Adjustment - Screen Menu

    2-2 Imaging Adjustment - Screen Menu - All of the icons shown in the ScreenManager “Screen” menu are described below. • Allow the monitor to stabilize for at least 30 minutes before making image adjustments. Contrast/ Brightness Size Position Side-...

  • Page 20: Parallelogram/Trapezoidal

    Adjusts: horizontal convergence Adjusts: vertical convergence What is convergence? Convergence is the monitor’s ability to precisely illuminate specific phosphors and line them up properly in order to produce pure color. • The convergence adjustment adjusts the entire screen. It is not possible to limit adjustment to specific screen areas.

  • Page 21: Color Adjustment - Color Menu

    2-3 Color Adjustment - Color Menu - Outline EIZO monitors have incorporated two color adjustment modes, standard and custom. The “Standard” mode allows the adjustment of the color spectrum. The “Custom” mode allows extensive controls over the colors of the displayed image on the screen.

  • Page 22: Adjusting The Standard Mode

    6,500K: Warm-white tone, similar to white paper or daylight. This temperature is good for video-image display. 9,300K: Slightly bluish white. This is the default setting for your EIZO monitor. Adjusts: Color Correction Because of the differences in video signal output...
  • Page 23 “OK” and “Error” blinks. 4) Press any adjustment button on the fron panel makes this message menu off. · Please allow 30 minutes for the monitor to warm up. · Approximately 20 to 30 seconds are needed to adjust Color Correction.

  • Page 24: Adjusting The Custom Mode

    Adjusting the Custom Mode Cutoff and Gain adjustments Monitors use red, green and blue (R, G, and B) to convey color information. They use an additive method to combine different amounts of the primary colors to produce a desired color. In other words, monitors start with no light (black) and add percentages of red, green and blue to make colors.
  • Page 25 Function Color Temperature Adjusts: (Custom Mode) a) Select the “Temperature” icon from the sub menu. b) Select the temperature as desired by moving the arrow keys in any direction. Cutoff Adjusts: Cutoff The Cutoff adjustment is the most powerful adjustment. It alters the starting point (the black level) and the ending point (the white level).

  • Page 26: Power-Save Setup - Powermanager Menu

    Complete energy use can only be stopped by disconnecting the monitor from the power supply. • When the monitor is in a power saving mode, the optional EIZO i·Sound speaker unit will turn off. • Even if the monitor is in a power saving mode, USB compliant devices function when they are connected to the monitor’s USB (both...

  • Page 27: Set-Up Procedure

    There are two power-save settings for the monitor. “VESA DPMS” system works with the VESA DPMS signal. “EIZO MPMS” system works with a screen saver software and Energy Saver for Macintosh which blanks the screen (totally black screen). Set the monitor to match the PC’s power saving software, as follows.
  • Page 28 1) First, make the appropriate settings for the PC. 2) Then select “VESA DPMS”. 3) Set the delay period, which is the interval that the monitor will wait after receiving a power saving signal from the PC, before entering into Mode 1 or Mode 2.
  • Page 29 Mode 1 operates for a user-definable period in “Duration” (in 0-60 minutes) before the monitor enters Mode 2. If the keyboard or the mouse are not in use during this period, the monitor will then enter PowerManager Mode 2. 15 W...
  • Page 30 What is EIZO MPMS? EIZO MPMS, "EIZO Monitor PowerManager Signaling", also enables to execute power saving at the monitor side. EIZO MPMS recognizes the video signals from the PC when the PC is in a power saving mode, and reduces energy consumption of the monitor.

  • Page 31: Other Settings - Others Menu

    “Input Priority” settings (see chart on next page). Once a priority is set, whenever a change of signal is detected at the selected input, the monitor will switch the input to that signal. D-Sub...

  • Page 32: Beep

    D-Sub or BNC as the active input at any time. turns: on/off the beeper If the beepr is ON, the monitor will generate beep signals as shown below. If the beeper is OFF, the monitor will not beep. Short beep ·...

  • Page 33: Signal Filter 1

    “On Period” expires. The energy consumption of the monitor in the “Off Timer Mode” is as low as the one of the monitor in “PowerManger Mode 2” although no setting PC to operate the Off Timer function is required. The...
  • Page 34 (2) Select “Enable” and press the enter button. (3) Press the right/left key to adjust how long (1 to 23 hours) the monitor should be in the “On Period”. Then, press the enter button to return to the “others” menu.

  • Page 35: Reset

    Function Reset Use this function to return all ScreenManager parameters (size, position, geometry, color, PowerManager, etc.) to their factory default settings. Default settings are as follows. Screen: Color PowerManager • VESA DPMS/5 sec. Others Language ADJUSTMENTS & SETTINGS USING THE SCREENMANAGER •...

  • Page 36: Getting The Most From Your Monitor

    The unit includes a microphone function and a headphone jack. For further details, please consult an authorized EIZO dealer near you. 3-2 Making use of USB (Universal Serial Bus) - For USB compliant system environments- This monitor provides a hub which supports the USB standard.
  • Page 37 • When connecting the USB cable, check that the shape of the connector at the USB cable side matches the shape at the connecting side. 2) “EIZO USB Hub” appears on the screen. Insert the Windows 98 CD- ROM and Click “OK” in the “Insert Disk” window.
  • Page 38 Connect the USB compliant peripherals to the downstream ports of the monitor: (Connection examples) EIZO USB Cable (MD-C93) Front port (Example) Downstream connector USB Specifications USB standard USB Monitor Control Class Standard Downstream power supply Communication speed USB ports GETTING THE MOST FROM YOUR MONITOR...
  • Page 39 ScreenManager Pro for USB (For Windows 98) The utility software “ScreenManager Pro for USB” is included in the enclosed utility disk. It is used for controlling the EIZO monitor from a PC using a mouse or keyboard. It allows control of the screen adjustment (size, position, distortion, color, contrast, moiré, etc.) from...

  • Page 40: Troubleshooting

    6) “No signal detected” error message appears. TROUBLESHOOTING Points to check with possible solutions The termination switch on the rear of the monitor should be set to 75 position (default) for connection to a single monitor. If it is set to the position when using a single monitor, some problems like 1) ~ 4) may occur.
  • Page 41 Adjust the contrast and brightness using the ScreenManager’s “Screen” menu. See page 19. Some signal timings can be the cause of this problem. To correct this, turn off the monitor, then hold down the AUTO-SIZING button and “down” arrow key while turning on the monitor again.
  • Page 42 • An unstable signal from the graphics board may be the cause of the imaging problem 4) when using the monitor with a high resolution or in a high refresh mode. (The video signal from the graphics board might be made irregular due to the use of a high speed dot clock.) Change the resolution or the refresh rate to another setting.
  • Page 43 Flicker will occur with interlaced scanning, or non-interlaced scanning with a low refresh rate. All EIZO monitors are capable of reproducing high refresh rates for non-interlaced scanning. If a problem occurs when using a non-interlaced signal, try adjusting the graphics board to increase the refresh rate (if possible).

  • Page 44: Color Problems

    (red, green, blue) Explanation of the Characteristics of CRTs When the monitor is not fully warmed up, the screen may look slightly colored, e.g. reddish or bluish. This phenomenon is due to the unstableness of the electron gun during its warm-up period. Please wait for about 30 minutes until the monitor stabilizes in order to gain its proper color.
  • Page 45 The monitor emits a humming noise when executing automatic degaussing at power-ON. This is not a problem. The monitor beeps at any time. This is not a problem. See page 31 for full details. The Adjustment Lock is probably on. To unlock:...
  • Page 46 • Keep liquids away from the monitor. Spillage into the cabinet may result in fire, electric shock, or equipment damage. If an object or liquid falls/spills into the cabinet, unplug the monitor immediately. Have the unit checked by a qualified service engineer before using it again.

  • Page 47: Specifications

    PC utilized. 100-120 VAC±10%, 50 Hz, 2.0 A 220-240 VAC±10%, 50/60 Hz, 0.9 A 140 W/200 W* (*with EIZO optional speaker & USB attached) D-Sub 13W3 and BNC × 5 (switchable) • H/V Separate, TTL, Positive/Negative • H/V Composite, TTL, Positive/Negative •...
  • Page 49 APPENDIX Pin Assignment Pin-Belegung Affectation des Broches D-Sub 13W3 Connector BNC Connector Connector Input signal Sync on green Composite sync Separate sync APPENDIX Signals Separate sync Composite sync Sync on Green Green Blue Ground V.Sync Data Clock (shorted with 9 pin) H.Sync Composite sync shorted with...
  • Page 50 Preset Timing Vordefinierte Timing-Werte Signaux prédéfinis 2 factory presets shown below have been registered in the monitor’s microprocessor. Der Monitor unterstützt 2 werkseitig vorgegebene Timing-Werte (siehe unten). Diese Werte sind im Mikroprozessor Ihres Monitors gespeichert. Les deux signaux ci-dessous ont été enregistrés en usine dans le microprocesseur du moniteur.
  • Page 51 Dimensions Abmessungen Dimensions (19.4) (15.8) (11.8) (19.1) 42.8 (12.0) (1.7) FRONT VIEW VORDERANSICHT VUE DE FACE APPENDIX 10° 4° 72.5 (5.0) (2.9) (20.5) SIDE VIEW SETENANSICHT VUE DE CÔTÉ (inches) 368.6 (14.5) 45° 45° TOP VIEW DRAUFSICHT VUE D'EN HAUT...

  • Page 52: Limited Warranty

    In the event of malfunction during the warranty period attributable directly to faulty material and/or workmanship, EIZO and EIZO’s authorizes distributors will, at their option, either repair or replace the faulty product with the same or similar model. EIZO and EIZO’s...

  • Page 53: Garantia Limitada

    Para obtener la prestación del servicio bajo esta garantía, el comprador original debe devolver el producto al distribuidor autorizado de EIZO, con los gastos de envío pagados, en su embalaje original o en otro que ofrezca igual grado de protección y asumiendo el riesgo de daño y/o pérdida durante el envío.

  • Page 54: Garanzia Limitata

    (10) giorni dalla data di acquisto. Nel caso in cui, nel periodo di garanzia, si verifichino dei malfunzionamenti imputabili ai materiali e/o alla manodopera, EIZO e i distributori autorizzati EIZO, potranno, a loro scelta, riparare o sostituire il prodotto difettoso con uno identico o analogo. EIZO e i distributori autorizzati EIZO non si assumono alcuna responsabilità...

  • Page 55: Why Do We Have Environmentally Labelled Computers

    Congratulations! You have just purchased a TCO’99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products.

  • Page 56: Environmental Requirements

    Environmental requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer casing can consist of flame retardant substances. Most flame retardants contain bromine or chloride, and those flame retardants are chemically related to another group of environmental toxins, PCBs.

  • Page 57: Declaration Of Conformity

    Röntgenstrahlung ist durch die eigensichere Kathodenstrahlroehre ausreichend abgeschirmt. Recycle Auskunft Die Rücknahme dieses Produktes nach Nutzungsende übernimmt EIZO in Deutschland zusammen mit dem Partner von Roll MBB Recycling GmbH. Dort werden die Geräte in ihre Bestandteile zerlegt, die dann der Wiederverwertung zugeführt werden.

  • Page 58: Fcc Declaration Of Conformity

    Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. -AC Cord -Signal Cable (D-SUB mini 15 pin - D-SUB 13W3, MD-C88) This Class B digital apparatus complies with Canadian ICES-003.
