Model: SBO22
__(1) Long leg assembly
__(1) Short leg assembly
__(1) Hardware pack
TOOLS NEEDED
- 7/16 wrench
- 4mm hex key, allen, t-handle
(incluided)
Qty.
Description
A-1/4-20 X 1-7/8 WAFER SHCS
6
B-1/4 FLAT WASHER
6
C-1/4-20 NYLOCK NUT
6
ASSEMBLY INSTRUCTIONS
Step 1
Attach long leg assembly to short leg assembly
with (6) 1-7/8" bolts, nuts and washers
HARDWARE IS COATED STAINLESS STEEL UNLESS OTHERWISE SPECIFIED
C
B
A
9/25/2012
