CAR710W
QUICK START GUIDE
Multimedia Receiver with Wireless and Wired CarPlay™ and Android Auto™
featuring a
7" digital TFT Display
This Quick Start Guide gives you the basics to
start using your CAR710W. Please visit
https://www.jensenmobile.com/user-manuals.html
to download a complete owner's manual or call customer
service at 1-888-921-4088 (Monday-Friday, 9AM-5PM EST).
Designed and Engineered in USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SiriusXM CAR710W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jensen SiriusXM CAR710W

Summary of Contents for Jensen SiriusXM CAR710W

  • Page 1 CAR710W QUICK START GUIDE Multimedia Receiver with Wireless and Wired CarPlay™ and Android Auto™ featuring a 7" digital TFT Display This Quick Start Guide gives you the basics to start using your CAR710W. Please visit https://www.jensenmobile.com/user-manuals.html to download a complete owner’s manual or call customer service at 1-888-921-4088 (Monday-Friday, 9AM-5PM EST).
  • Page 2 Wiring Diagram - Inputs/Outputs Note: Works for CarPlay and Android Auto only. Note: When replacing a fuse, make sure to use the correct type and amperage. Using an incorrect fuse could cause damage. The unit uses (1) 15 amp ATC mini style fuse located on the power connector. Wiring Notes: Subwoofer output The Subwoofer preamp audio output (Blue jacket with Black RCA) is active in all audio modes.
  • Page 3 Installation Before You Start • Disconnect negative battery terminal. Consult a qualified technician for instructions. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
  • Page 4 Control Locations The radio display features the following functions and displays: RESET SOURCE VOICE ACTIVATION BUTTON VOL- VOL+ Power/Mute Main Menu In main menu, press the desired icon to enter the corresponding mode: Radio/USB/SXM/BT Phone/ Android Auto/CarPlay/AV In/BT Audio/Equalizer/Settings.

  • Page 5: Tuner Operation

    Tuner Operation Main Menu Current Mode Indicator Preset Stations Local/Distance AS/PS Keypad Seek Tune Up Seek Tune Down Audio Operation Press the Settings icon on the main menu screen to adjust Fader and Balance controls, Equalizer (8-Band Tone Control and 8 Presets EQ Settings).

  • Page 6: Usb Operation

    USB Operation From the main menu, touch the USB icon on the main screen. Main Menu Current Mode Indicator List Repeat Random Search Track Up Play/Pause Track Down Note: Video playback is enabled only when the vehicle is in park and the parking brake engaged.

  • Page 7: Siriusxm ® Satellite Radio Operation

    ® SiriusXM Satellite Radio Operation From the main menu, touch the SXM icon on the main screen. Main Menu Band Current Mode Indicator Program Information Search Preset Channel List Additional Options Preset Buttons Direct Channel Down Channel Up Tune / Track Down Play / Pause Tune / Track Up...

  • Page 8: General Operation

    General Operation From the Main Menu screen, select Setup to access the Settings menu and select from nine categories represented by the icons on the top of the screen: General, Audio, Display, Others. Select the category, and adjust any of the available options using the touch screen. Sync GPS Time: Synchronizes the clock time with the GPS.
  • Page 9 Wired & Wireless CarPlay Operation Wired connection 1. Connect an Apple CarPlay compatible device to this unit via USB. 2. Press the Apple CarPlay icon. The Apple CarPlay home screen appears. Wireless connection Before using Apple CarPlay wirelessly, turn on the Bluetooth/Wifi function on the Phone.
  • Page 10 Wired & Wireless Android Auto™ Operation Wired connection 1. Connect an Android Auto™ compatible device to this unit via USB. 2. Press the Android Auto icon. The Android Auto home screen appears. Wireless connection Before using Android Auto wirelessly, turn on the Bluetooth/Wifi function on the Android device.

  • Page 11: Bluetooth Operation

    Bluetooth Operation Before using Bluetooth Before you can use a Bluetooth device to make hands-free calls or stream audio. it must be authenti- cated. This is also referred to as "pairing" a device. Pairing a New Device The unit broadcasts the pairing signal constantly when no devices are currently connected. Complete the pairing sequence from your Bluetooth device.
  • Page 12 Warranty Coverage Limited 1-year warranty when purchased from an authorized Jensen dealer. *Limited 2-year warranty when purchased from and professionally installed by an authorized Jensen dealer. (Proof of purchase and Installation required) What to do? 1.

  • Page 13: Fcc Compliance

    FCC Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
