- Page 1 H.V.L.P. TOUCH-UP SPRAY GUN Item Number M705 OWNER'S MANUAL WARNING: READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS AND WARNINGS BEFORE OPERATING THIS TOOL. FAILURE TO DO SO MAY RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE AND WILL VOID WARRANTY.
- Page 2 SPECIFICATIONS Air Pressure: ........34 - 43 P.S.I. Avg. Air Consumption (CFM): ......3.1 Spray Pattern:..........3-4 in. Fluid Inlet (NPS): ........M14 x 1.0 Spray Head & Needle: .......1.2 mm Air Inlet (NPS):..........1/4 in. Cup Capacity: ..........200 cc Hose Size (ID): ..........3/8 in. Specifications are subject to change without notice SAFETY GUIDELINES / DEFINITIONS This instruction manual is intended for your benefit.
- Page 3 OPERATION Step 1: Inlet Air Pressure Regulation Inlet pressure is adjusted by turning the Pressure Regulator Control Knob. Knob must first be pulled out to unlock. Assemble components of spray gun and connect to clean air source as described above. Clean air source Turning knob clockwise increases pressure, turning knob is imperative to ensure peak performance.
- Page 4 REPLACEMENT PARTS LIST REPLACEMENT PARTS LIST Description Qty. Description Qty. Gun body ............1 O-ring 2.5 x 1.8 ..........1 O-ring 20 x 1.5 ..........1 Air Valve Control Stem ........1 Sealing Gasket ..........1 Air Flow Control Knob ........1 O-ring 2 x 1.5 ............
- Page 5 TROUBLESHOOTING mechanical device, periodic adjustments are necessary to Your spray gun was constructed with quality materials maintain a peak level of performance. Should your spray and workmanship and will give you many years of trouble gun be displaying any of the following symptoms, the free use when cared for as described in the "Care and simple procedures shown below will correct the problem.
- Page 6 1 YEAR WARRANTY PERFORMANCE TOOL® extends only the following warranties, and only to original retail purchasers. These warranties give specific legal rights. Except where prohibited by local law, the law of the State of Washington governs all warranties and all exclusions and limitations of warranties and remedies.
