USAGE AND MAINTENANCE MANUAL
1. Technical specification:
MODEL
CLWS-O8G
CLWS-08GO
CLWS-07G
CLWS-12OV
CLWS-09SSD
CLWS-09CSD
CLWS-09CRS
CLWS-09CRC
2. Installation:
-
the stove must not be placed near wooden or plastic furniture parts, nor near cooling
devices. Minimum distance between the stove and such elements must be 30 cm.
-
if the stove is placed on the floor made from combustible materials (wood, itison, floor
plastic, etc.) it is necessary to protect the floor with metal sheet 10 cm width from the sides
of the stove, and 50 cm from the front side of the stove.
-
the stove should be attached to a chimney with inner diameter of at least 120 mm and
height of 6 m. If multiple stoves are attached to a single chimney, the attachment distance
should be at least 2 m.
3. Usage:
-
the stove uses wood, wood briquettes or a coal with less calories (brown coal, lignite...) as
a fuel
-
the heating strength depends on the type and quality of fuel used
-
the initial heating of the stove should be gradual to avoid sudden stresses on the material.
Do not use the stove with capacity during the first 8-10 hours (1-2 days) of firing.
-
Thermoresistant color on the stove will be fully formed after the first firing of the stove
-
make sure that the air regulator (located on the front side of the stove) and stack valve
regulator (located at the chimney spout) are fully opened when starting a fire
-
the combustion intensity is regulated with the air regulator located at the front of the stove
by turning it left-right, and with stack valve regulator located at the chimney spout by
rotating it
www.colorato.net
FOR A SOLID FUEL STOVE
BULK DIMENSION
465 x 390 x 790 mm
465 x 390 x 990 mm
330 x 360 x 930 mm
500 x 450 x 1030 mm
450 x 490 x 930 mm
450 x 490 x 930 mm
450 x 490 x 930 mm
450 x 490 x 930 mm
NET
THERMAL
WEIGHT
POWER
54 kg
7-8 kW
57 kg
7-8 kW
39 kg
5-7 kW
98 kg
10-12 kW
55 kg
8-9 kW
66 kg
8-9 Kw
64 kg
8-9 kW
75 kg
8-9 kW
OUTER
DIAMETER OF
SMOKE PIPE
120 mm
120 mm
120 mm
120 mm
120 mm
120 mm
120 mm
120 mm
Advertisement
Table of Contents
Summary of Contents for COLORATO CLWS-O8G
- Page 1 1. Technical specification: OUTER THERMAL MODEL BULK DIMENSION DIAMETER OF WEIGHT POWER SMOKE PIPE CLWS-O8G 465 x 390 x 790 mm 54 kg 7-8 kW 120 mm CLWS-08GO 465 x 390 x 990 mm 57 kg 7-8 kW 120 mm...
- Page 2 some parts of the stove can reach high temperatures during use. Thus, it is recommended to use protecting glove while handling with controls of the stove (such as door handle, ash tray handle, air regulators handle..) 4. Maintenance: ash tray must be emptied regularly burning chamber should be emptied periodically from the ash and other types of fuel waste after each heating season the stove, pipes and the chimney must be thoroughly cleaned from the spout...
