Summary of Contents for Particles Plus 8000 Series
- Page 1 8000 Series Handheld Particle Counters Quick Start Guide Version 1.0 31 Tosca Drive Stoughton, MA 02072...
-
Page 2: Important Safety Information
Instrument. 2. Registering Your Product It is important to register your product with Particles Plus to ensure that your warranty will be activated. To register your product, visit the Particles Plus Website and complete the form provided at: http://particlesplus.com/particles-plus-warranty-product-registration... - Page 3 7. Product Views and Connections Front View Rear View Left Side View – Input / Output Connections Connecting Ethernet Cable Connecting USB - B Client Cable Connecting USB - A Host...
- Page 4 8. Power Considerations and Connecting to AC Mains Power The Particles Plus Instrument comes with a power adapter line cord for AC mains powered operation and battery charging. The power adapter is designed to operate with line voltage from 100-240V. The correct plug adapter must be used to match your local AC power adapter standard.
-
Page 5: Turning The Unit On
10. Turning the Unit On The External one-touch power and sample button on the handle will power the instrument on and off and will turn sampling on and off. The one-touch external power button is conveniently located on the particle counter handle to allow for easy one touch operation. -
Page 6: Included Items
13. Included Items Along with your 8000 Series Particle Counter you will also receive the following items: Please check that all of the following items are included with your instrument. Included Accessories Description Part Number Image Isoprobe Threaded 0.1 CFM... - Page 7 Icon will be saved to the USB drive. If the Particles Plus Printer is connected to USB Port, the Printer Indication Home Screen Printer Icon will appear. When pressed from the home screen the current record on screen will be sent to the printer.
- Page 8 15. Control and Menu Icons (Continued) Function Name Location/Screen Description of Function When pressed the Real-Time Icon switches between the Real-Time Meter & Home Screen Real-Time Meter mode, graphing of pulse/seconds and the Graphing Icon Main Screen. When pressed, the Recorded Data Icon will display the Recorded Data Home Screen saved data records page.
- Page 9 15. Control and Menu Icons (Continued) Function Name Location/Screen Description of Function The Cycle Indication displays the number of count samples that will be taken at a location in automatic mode. The maximum number of possible cycles that can be set is Cycle Indication Home Screen 9,999.
- Page 10 16. Operational Flow Chart – Menu Map Print Shut Down Information Print Current Audio Volume Power Information Environment Date / Time Set Record Management Location & Zoom Recipes Main Location Real Time Advance Instrument Recorded Annotate Charts Reports Settings Data Record Print Records...
- Page 11 (in mass mode). This can be changed by pressing the icon, rotating through the data output indication options. For set-up menus instructions and detailed operations for your 8000 Series handheld particle counter please refer to your user manual.
