Summary of Contents for Aigis Mechtronics HS9385 Series
- Page 1 XTRA ARGE UTDOOR OUSINGS M4 Screws Camera Spacer Spacer Bushing Rails Screw Ground Wire Power Cable Terminal Lug HS9385 S ERIES Rail Assembly M4 Screws Mounting Holes N S T A L L A T I O N A N D P E R A T I N G N S T R U C T I O N S W W W...
-
Page 2: Important Safeguards
Important Safeguards 1. Read, Follow, and Retain Instructions - All safety 10. Power Sources - Operate the unit only from the type and operating instructions should be read and of power source indicated on the label. If unsure of followed before operating the unit. Retain instructions the type of power supply to use, contact your dealer for future reference. -
Page 3: Safety Precautions
UNPACKING 4.1.1 NEMA-3R and IP54 This electronic equipment should be unpacked and The HS9385 Series housings include a breather hole in handled carefully. the front face plate. The breather hole prevents the accumulation of moisture inside the housing when Check for the following items: installed in areas of high humidity. -
Page 4: Installation
INSTALLATION 5.4 Cable Requirements This installation should be made by a Video Transmission (Coaxial) qualified service person and conform to all Cable Type RG-59/U (Runs < 1000ft) local codes. RG-11/U (Runs < 2000ft) Cable Size Outside diameter between 4.6mm Model Designation and 7.9mm (0.181in. -
Page 5: Camera/Lens Installation
Lens Control Cable 4. Attach the housing to an appropriate mount or pan/tilt. Use the instructions provided with the Cable Type Jacketed Multiconductor Cable mount or pan/tilt. The base assembly has three Cable Size Outside diameter between 4.3mm clearance holes for mounting. Use three M6 and 11.9mm (0.170in. -
Page 6: Camera/Lens Wiring
4.3mm (0.170in.) to 11.9mm 5.8.1 Supply Power Connections (0.470in.). See FIGURE 6. The HS9385 Series housings offer the user one of three Be sure to securely tighten all fittings to ensure voltage configurations. The suffix to the housing model a liquid-tight seal. - Page 7 Power connection into the housings is to be supplied 4. Connect both the line and neutral wires of the through a minimum type UL Standard SJ cord power cord to the terminal block. Make sure acceptable for outdoor use. Installation must conform the line and neutral wires are connected to the to applicable NEC and local codes.
-
Page 8: Video Coax Connection
HS9385-2 Housings Video Coax Connection These housings are to be connected to 24VAC, and WARNING: Only use the cables specified are designed for use where site power is 24volts. The under INSTALLATION, Cable Requirements for HS9385-2 housings should only be used with 24volt wiring of the video coax connection. -
Page 9: Camera/Lens Orientation
Wire the functions as described above, or as needed. 5.11 Camera/Lens Orientation Small Fitting A unique feature of the HS9385 Series housing is Video Coax Cable CCD Camera BNC Connector the ability to rotate the mounting base 360 º around the rail assembly. -
Page 10: Final Assembly
5.13 Final Assembly 3. Insert the long end of the pull seal into the breather hole starting from the front side of the 5.13.1 Pull Seal Installation face plate. See FIGURE 16. If the breather hole is open, do NOT mount the housing in a position where the front face plate is pointed upward. - Page 11 5.13.2 Housing Assembly 1. The lens support screw is provided to support 3. Align the cover holes with the base assembly the rail assembly. Adjustment will only be holes and replace the two M4 screws and necessary if the rail assembly is rotated at angle washers.
- Page 12 ©2005 Aigis Mechtronics 1124 Louise Road, Winston-Salem, NC 27107-5450 Tel: 336.785.7740 Fax: 336.785.7744 100 0100 002 AIG 07/05 Data subject to change without notice. Printed in U.S.A.
