- Page 1 EW-7811GLN 2.0A Quick Installation Guide 07-2019 / v1.0...
-
Page 2: Table Of Contents
Contents I. Product Information ................3 I-1. Package Contents ........................3 I-2. LED Status ..........................3 I-3. System Requirements ......................3 I-4. Safety ............................. 4 II. Installation .................... 5 III. Windows ....................6 III-1. Driver Installation ........................6 III-2. Driver Uninstallation ......................9 III-2-1. -
Page 3: Product Information
I. Product Information I-1. Package Contents EW-7811GLN 2.0A I-2. LED Status LED Status Description LED displays on for five seconds to indicate a successful WPS connection. Flashing Wireless activity: transmitting or receiving data. Fast Flashing WPS is active. (3 x per second) No wireless activity. -
Page 4: I-4. Safety
The wireless adapter is an electrical device and as such, if it becomes wet for any reason, stops using it immediately. Contact an experienced electrical technician for further help. Download product material here https://www.edimax.com/download... -
Page 5: Installation
Never use force to insert the USB adapter. Please download driver from https://www.edimax.com/download If a Hardware Wizard/Driver Installation window opens as shown to the left, please click “Cancel” or “Close”. Please follow the instructions in the appropriate chapter for your... -
Page 6: Windows
If the auto wizard didn’t run, please open the “AutoRun” folder and execute “Autorun.exe” file to start the setup wizard. Please wait for the InstallShield Wizard to guide the entire setup process. Click “Next” to install the drivers for your EW-7811GLN 2.0A. - Page 7 Please wait while the driver is installing. Before you can use the wireless adapter, you need to restart your computer. When the installation is complete you will be asked to choose whether you wish to restart your computer now or later. Click “Finish” to continue.
- Page 8 After you restart your computer, your EW-7811GLN 2.0A will be installed and fully functional. Please disable any other wireless adapters as described in V. Disabling Network Adapters. Then, Windows users can connect to an available Wi-Fi network as usual. For guidance on doing so,...
-
Page 9: Iii-2. Driver Uninstallation
III-2. Driver Uninstallation III-2-1. Windows 7 Go to Start > Programs > Edimax Wireless LAN > Uninstall Follow the on screen instructions. An uninstall wizard will guide you through the process. III-2-2. Windows 8/8.1 Right click anywhere on the “Start” screen and then click the “All apps”... -
Page 10: Windows 10
III-2-3. Windows 10 Open WinX menu by holding Windows and X keys together, and then click “Programs and Features”. Look for Edimax Wireless LAN Driver and Utility in the list, click on it and then click “Uninstall”. -
Page 11: Mac Os
Mac OS, click the Apple logo in the top left corner of your desktop and go to “About This Mac”. After downloading driver from https://www.edimax.com/download, open the “…_MacOS10.9_MacOS10.14_Driver_…” folder for your version of Mac OS X (10.9 - 10.14) and double click the “Install.pkg” file to open the driver installation wizard. - Page 12 Select a language and click “Continue” to install the driver.
- Page 13 To read the software license click “Read License” and then click “Agree” to confirm you agree to the terms. You must agree to the terms to continue installing the software. Click “Install” to install the driver.
- Page 14 You may be prompted to enter your system/administrative password before the installation can begin. Enter your password and click “Install Software”. You will be prompted that you must restart your computer when the installation is complete. Click “Continue Installation” to proceed. Please wait while the driver is installing.
- Page 15 When the installation is complete, you will see the following screen informing you that “The installation was successful”. Click “Restart” to restart your computer. When the adapter is connected to your computer (after your system has restarted) the wireless utility will open automatically. Next, please disable any other wireless adapters as described in V.
-
Page 16: Iv-2. Driver Uninstallation
IV-2. Driver Uninstallation Ensure you select the correct folder for your version of Mac OS. To check your version of Mac OS, click the Apple logo in the top left corner of your desktop and go to “About This Mac”. Open the “…_MacOS10.9_MacOS10.14_Driver_…”... -
Page 17: Disabling Network Adapters
V. Disabling Network Adapters To ensure that your USB wireless adapter can function correctly, it is recommended that you disable any other existing wireless network adapters installed on your computer. If you are unsure how to do so, you can refer to the user manual for your computer, or follow the guidance below. -
Page 18: Windows 10
V-3. Windows 10 Open Settings. The click on Network & Security > Status >Change adapter options. -
Page 19: Mac
Right-click the network adapter, and select the “Disable” option. V-4. Select “System Preferences” from the dock. In “System Preferences”, select “Network”. All of your network connections will be displayed, as shown below. Select “Wi-Fi” from the left panel. Click “Turn Wi-Fi” off in the main panel. -
Page 20: Using The Adapter
VI. Using The Adapter After you have installed the driver and if necessary disabled other wireless adapters (see V. Disabling Network Adapters), Windows users can connect to a Wi-Fi network as usual (see below). Mac users need to connect to a Wi-Fi network using the included utility software, as described in VI-2. - Page 21 After correctly entering your password, you will be successfully connected to your Wi-Fi network.
-
Page 22: Vi-2. Mac: Connecting To A Wi-Fi Network
VI-2. Mac: Connecting to a Wi-Fi network The wireless utility will open automatically when the adapter is connected to your computer. If the utility doesn’t open, you can open it from the “Applications” menu in your Mac. Click the “Available Network” tab in the wireless utility. Select a Wi-Fi network to connect to and click “Connect”. - Page 23 Enter the password (network key) for the Wi-Fi network, confirm the password (network key) again below and click “OK”. After entering your password, you will be successfully connected to your Wi-Fi network. A summary of the connection will be displayed on the “Link Status”...
-
Page 24: Vi-3. Mac: Wireless Utility
VI-3. Mac: Wireless Utility The wireless utility offers features to monitor and configure your connection. Navigate the wireless utility using the menu across the top of the window. VI-3-1. Link Status The “Link Status” page displays information about the current wireless connection. -
Page 25: Vi-3-2. Profiles
VI-3-2. Profiles The “Profiles” screen allows you to save different Wi-Fi connection settings as “Profiles”. Existing profiles are listed in the “Profile List”. Opens a new window to manually add a new profile. Edit Edit an existing profile. Remove Remove an existing (selected) profile. Duplicate Duplicate selected profile. - Page 26 Add a Profile When you select “Add”, a new window will open. Enter a profile name and SSID, along with security information, and then click “OK”. You can also add a new profile from the “Available Network” screen. AdHoc networks are also supported – check the box labeled “This is a computer-to-computer (AdHoc network)…”...
-
Page 27: Vi-3-3. Available Network
VI-3-3. Available Network The “Available Network” screen displays a list of all available Wi-Fi networks within range along with various categories of information about each network. Refresh Refresh the list of available wireless networks. Connect Connect to a selected wireless network. Add to Profile Use a selected wireless network to create a new profile (see VI-3-2. -
Page 28: Vi-3-4. Wps
VI-3-4. WPS Wi-Fi Protected Setup is a simple, alternative way to establish connections between WPS compatible devices. Most of the wireless router and access point feature a built-in WPS button, which activates WPS on that device. When WPS is activated in the correct manner and at the correct time for two compatible devices, they will automatically connect to each other. -
Page 29: Pbc: Push Button Configuration
PBC: Push Button Configuration The EW-7811GLN 2.0A does not feature a physical WPS button, but PBC WPS can be executed from this page by following the steps below: Press the WPS button on your wireless router/access point for the correct length of time to activate its WPS. - Page 30 Within two minutes, select your wireless/router/access point from the “SSID” list as shown below, and then click the “PIN” button in the bottom left of the “WPS” page. The wireless adapter will establish a connection with your wireless router/access point. Below is a general description of items on the “WPS”...
-
Page 31: Vi-3-5. Information
VI-3-5. Information The “Information” screen displays various information such as wireless utility version and driver version. - Page 32 COPYRIGHT Copyright Edimax Technology Co., Ltd. all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission from Edimax Technology Co., Ltd.
- Page 33 15.03 A simplified DoC shall be provided as follows: Article 10(9) Hereby, Edimax Technology Co., Ltd. declares that the radio equipment type N150 Wi-Fi Nano USB Adapter is in compliance with Directive 2014/53/EU The full text of the EU declaration of conformity is available at the following internet address: http://www.edimax.com/edimax/global/...
- Page 34 EU Countries Intended for Use The ETSI version of this device is intended for home and office use in Austria, Belgium, Bulgaria, Cyprus, Czech, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Turkey, and United Kingdom. The ETSI version of this device is also authorized for use in EFTA member states: Iceland, Liechtenstein, Norway, and Switzerland.
- Page 35 EU Declaration of Conformity English: This equipment is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU, 2014/35/EU. Français: Cet équipement est conforme aux exigences essentielles et autres dispositions de la directive 2014/53/EU, 2014/35/EU. Čeština: Toto zařízení je v souladu se základními požadavky a ostatními příslušnými ustanoveními směrnic 2014/53/EU, 2014/35/EU.
- Page 36 Declaration of Conformity We, Edimax Technology Co., Ltd., declare under our sole responsibility, that the equipment described below complies with the requirements of the European Radio Equipment directives. Equipment: N150 Wireless USB Adapter Model No.: EW-7811GLN 2.0A The following European standards for essential requirements have been followed:...
