  • Page 1 Video Intercom | User Manual - VUO2111D-WP V1.0.1...

  • Page 2: Table Of Contents

    Table of Contents Product Overview ..................1 Intro to Product....................1 Applicable Models ................... 1 Structure ...................... 2 Front Panel ..................... 2 Rear Panel ...................... 3 Networking Scene ..................4 Installation and Debug ................. 5 Device Wiring ....................5 Device Installation ................... 5 4.2.1 Screw ....................
  • Page 3 5.2.7 IPC ...................... 16 5.2.8 WIFI Info ..................... 17 Info Search ....................17 5.3.1 Call History ..................18 5.3.2 Alarm Record ..................18 5.3.3 Unlock Record ..................18 Status Statistics..................... 19 Basic Function Introduction ................ 20 Monitor ......................20 Call Function ....................20 Unlock ......................
  • Page 4 Important Safeguards and Warnings Please read the following safeguards and warnings carefully before using the product in order to avoid damages and losses. Note: Do not expose the device to lampblack, steam or dust. Otherwise it may cause  fire or electric shock. Do not install the device at position exposed to sunlight or in high temperature.
  • Page 5 of related regions. For detailed information, see the paper User's Manual, CD-ROM, QR code or our official website. If there is inconsistency between paper User's Manual and the electronic version, the electronic version shall prevail.  All the designs and software are subject to change without prior written notice.

  • Page 6: Product Overview

    1 Product Overview 1.1 Intro to Product Digital villa VUO has easy operation, simple installation and support:  WIFI  Mobile phone live preview  Call VUH, and perform video talk  Door unlock by card  One-click MGT center ...

  • Page 7: Structure

    2 Structure 2.1 Front Panel Device front panel is in Figure 2-1. Description of each component is in Chart 2-1. Figure 2-1 Port Name Note Audio input. Camera It monitors corresponding door region. Authorize IC card to unlock （card issuing）, Card Area swipe card to unlock.

  • Page 8: Rear Panel

    2.2 Rear Panel Device rear panel is in Figure 2-2. Description of each component is in Chart 2-2. Figure 2-2 Component Name Note Bracket Position Bracket used to fix device and wall. Vandal-proof When villa VUO is forced to leave wall, it will alarm and Switch send alarm to MGT center.

  • Page 9: Networking Scene

    3 Networking Scene Villa VUO networking scene is in Figure 3-1. Figure 3-1...

  • Page 10: Installation And Debug

    4 Installation and Debug 4.1 Device Wiring Device wiring is in Figure 4-1. Figure 4-1 4.2 Device Installation Warning:  Avoid installation in poor environment, such as condensation, high temperature, oil stain, dust, corrosion or direct sunlight.  Project installation and debugging must be done by professionals. Please do not open the device in case of failure, and please contact after sales service.

  • Page 11: Screw

    4.2.1 Screw For installation, please use screw according to Chart 4-1. Component Name Illustration Quantity M4×30 cross pan head machine screw Chart 4-1 4.2.2 Installation Step VUH installation is in Figure 4-2. Figure 4-2 Steps: Step 1. According to position of bracket, dig hole on installation surface (such as wall). Step 2.

  • Page 12: Debug Device

    Note: The recommended distance from device center to ground is 1.4m~1.6m. 4.3 Debug Device 4.3.1 Before Debugging Warning:  Debugging personnel shall be familiar with related materials, know device installation, wiring and usage.  Debugging personnel check whether circuit has short circuit or open circuit or not. Make sure circuit is normal, plug device to power.

  • Page 13: Debug Device

    After modification is finished, WEB page will restart and go to new IP address. 4.3.2 Debug Device Make VUH5221D an example here: Step 1. Plug device to power. Step 2. In homepage, long press Settings for 6 seconds. Device pops up Password Verification box.
  • Page 14 Figure 4-5 2. Enter VUH Local IP, Subnet Mask and Gateway. 3. Press OK. Now device interface shows at the upper right corner which means wired connection is successful. Note: You also can enable DHCP to auto gain VUH IP, subnet mask and gateway and press OK to complete wired connection.
  • Page 15 Figure 4-6  If you want to set this VUH to be extension VUH, then you shall select Extension. Fill in user config info for extension to auto sync with master, such as room no. and master IP. See Figure 4-7. Figure 4-7 4.

  • Page 16: Successfully Debug

    Telnet server is ON, debugging personnel can view VUH config via telnet+IP. Step 6. Press Network to config VUO info. Warning: Before config, please make sure VUO is plugged to power and is in the same segment with VUH. Fill in VUO name, master VUO IP address, set enable status to , see Figure 4-8.
  • Page 17 Figure 4-9 Icon Icon Name Note VUO config electric control lock, press Unlock 1 , unlock. If this VUO has 485 expansion interface, it can expand electric control lock or door Unlock 2 sensor lock, after successfully matching with VUH, press , unlock.
  • Page 18 Icon Icon Name Note if full, it overwrites from the earliest record. Note: When SD card is not installed, this button is grey. Volume Adjust call volume. 、 Accept Call Hang up...

  • Page 19: Web Config

    5 Web Config This chapter introduces VUO WEB interface and its parameters, and how to configure them. 5.1 WEB Login and Logout 5.1.1 Login Step 1. In PC browser, enter device default IP address 192.168.1.110. See Figure 5-1. Note: Default username is “admin”. Default password is “admin”. Please refer to Ch 5.2.4.1 for setup.

  • Page 20: System Config

    Figure 5-2 Step 2. Click Logout. System exits WEB interface, return to login interface. You can go to Logout>Reboot Device>Reboot Device interface, click Reboot Device to restart. 5.2 System Config 5.2.1 Local Config In Local Config interface, you can view VUO model, version info and etc. 5.2.1.1 Local Config In System Config>Local Config>Local Config interface, you can set light seneor, storage point, reboot date and etc.
  • Page 21 Please refer to Ch 5.2.4.2 for FTP setup. Device Type Display device type. Now it is “villa station”. Reboot Date On the set date, device will automatically reboot. Default is 2:00 a.m. Tuesday. Version Info Display device version info. Dial Rule There are serial and non-serial.
  • Page 22 unlock door; support up to 10000 IC cards. Please refer to Ch 5.2.1.3. Default Only restore A&C Manager page to default settings. Refresh Click Refresh to refresh current interface. Chart 5-2 5.2.1.3 Issue Card Note: Before you issue card, please add VUH first, refer to Ch 5.2.3.1.
  • Page 23 Parameter Note Select Enable, villa VUO calls VUH, no one answers, caller can leave a message on VUO. Message will be stored in SD card, and can be viewed on Leave Message VUH. Note: Upload If VUH sets message time to 0 seconds, then message is not allowed. If message time is set other than 0, when no one answer call from VUO, it will ask if you want to leave a message.
  • Page 24 Parameter Note DST Enable Check “DST Enable” box, to enable DST. DST Type If you locate in place using DST, you can set DST accordingly. You can Start Time select week mode or date mode to start and end DST. End Time NTP Enable NTP Server...

  • Page 25: Lan Config

    system, so if you want to restore card info or VUH info, you must operate within this time limit. Export Export config file（Config.backup） Import config file. Import Default Restore all parameters to default status. Chart 5-4 5.2.2 LAN Config Go to System Config>LAN Config>LAN Config, see Figure 5-8. Here you can register VUO to center and set how to call center.

  • Page 26: Indoor Manager

    Parameter Note Register to MGT Center MGT center” box. MGT Port No. Call VUS Time Set period of call button on device to call MGT center. Check “Call VUS or Not” box, to enable call MGT center function Call VUS or Not via button on villa VUO during the set period instead of calling VUH.
  • Page 27 Figure 5-9 Note: Parameters with * are mandatory. Parameter Note Family Name Set username and nick name of VUH. First Name Nick Name Known as VUH room no. Note: VUH short no. is composed of 4 digits of number. The first two digits have Short No.

  • Page 28: Network Config

    Parameter Note Card ID Card Show IC card number, username and VUH room no. Number Username Check “main card” box, set this IC card to be main card. Note: Main Card Main card has card authorization function, and this device does not support. Report When IC card is lost, click to report loss.
  • Page 29 Step 3. Click After you have modified IP address, WEB page will reboot and go to the new IP address page. Parameter Note IP Address Enter corresponding number to change IP address. According to actual condition, set subnet mask which prefix is Subnet Mask number, enter 1～255，subnet mask prefix has a specific network link, which includes one layer structure in general.

  • Page 30: Video Set

    Parameter Note IP Address IP address of host where FTP server is installed. Port No. Default is 21. Username Access FTP server username and password. Password Chart 5-9 Step 3. Click OK. 5.2.4.3 P2P Step 1. You can go to System Config>Network>P2P interface. See Figure 5-13. Figure 5-13 Step 2.
  • Page 31 Step 2. Adjust video parameter. See Figure 5-14. Note: If you cannot see video in window, please install plug-in first. Figure 5-14 Parameter Note Adjust video resolution，includes 720P, WVGA and D1. Video Format  720P： 1280×720.  WVGA： 800×480.  D1：...

  • Page 32: User Manager

    Parameter Note range is 0～100. Saturation Adjust color saturation, recommended value is 40～60, range is 0～100. Gain Gain limit of video basic parameter. Scene Mode Select mode: automatic, sunny, night and etc. Day/Night Mode Include：colorful, automatic and Black White . Back Light Mode Include：Disabled, backlight, WDR, HLC.
  • Page 33 Figure 5-16 Step 4. Click . SeeFigure 5-17. Only when you login as admin, you can add, modify, delete and view user info in User Manage interface. Current system supports two types of user:  Admin has higher right who can view, edit, delete configured right. ...

  • Page 34: Ipc

    Figure 5-18 Step 2. Check Change Password box. System shows Old Password, New Password and Confirm Password. Step 3. Configure interface parameter. Step 4. Click OK. 5.2.7 IPC If the VUH has configured with IPC info, you can view IPC video image via corresponding VUH.

  • Page 35: Wifi Info

    5.2.8 WIFI Info Note: Only some models support WIFI function. To configure WIFI: Step 1. Go to System Config>WIFI Info>WIFI Info. Step 2. Click Open WLAN, and system searches and displays available WIFI, see Figure 5-20. Figure 5-20 Step 3. Click of WIFI you want to connect.

  • Page 36: Call History

    5.3.1 Call History You can search VUO call history in Call History interface, it stores up to 1024 records. See Figure 5-22. Figure 5-22 5.3.2 Alarm Record Go to Info Search>Alarm Record>Alarm Record interface. See Figure 5-23. You can search VUO alarm in Alarm Record interface, and it stores up to 1024 records. Figure 5-23 Click Export Record button to export villa VUO alarm record.

  • Page 37: Status Statistics

    5.4 Status Statistics Warning: If the added VUH is not online, then you go to Status Statistics>VUH Status interface, view VUH connection status, monitor status port no. and etc. See Figure 5-25. In VUH status, you can view VUH connection status. ...

  • Page 38: Basic Function Introduction

    6 Basic Function Introduction Villa VUO supports unlock by card, one-click call MGT center and VUH, plus video talk with MGT center and VUH. 6.1 Monitor Download mobile phone App and sign up, you can remotely view video of VUO. Please refer to Ch 5.2.4.3.

  • Page 39: Appendix 1 Technical Specifications

    Appendix 1 Technical Specifications Model VUO2111D-WP System Main Process Embedded micro controller Embedded Linux os Video Video Compression H.264 Standard Audio G.711 Audio Standard Input Input Output Output Talk Talk Operation Mode Input Mechanical keypad Alarm Input 1-ch unlock button, 1-ch door sensor feedback Output 1-ch relay output Front Camera...
  • Page 40 Note:  This manual is for reference only. Slight difference may be found in user interface.  All the designs and software here are subject to change without prior written notice.  All trademarks and registered trademarks are the properties of their respective owners.
