MotoTech eG4TR User Manual

10/100 mbps broadband gateway
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Broadband Gateway
10/100 Mbps Broadband Gateway
User's Guide
IRS405

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eG4TR and is the answer not in the manual?

Questions and answers

Summary of Contents for MotoTech eG4TR

  • Page 1 Broadband Gateway 10/100 Mbps Broadband Gateway User’s Guide IRS405...
  • Page 3 FCC - Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with instructions, may cause harmful interference to radio communications.

  • Page 4: Industry Canada - Class B

    Immunity: * Product family standard according to EN 55024:1998 * Electrostatic Discharge according to EN 61000-4-2:1995 (Contact Discharge: ±4 kV, Air Discharge: ±8 kV) * Radio-frequency electromagnetic field according to EN 61000-4-3: 1996 (80 - 1000MHz with 1kHz AM 80% Modulation: 3V/m) * Electrical fast transient/burst according to EN 61000-4-4:1995(AC/DC power supply: ±1kV, Data/Signal lines: ±0.5kV) * Surge immunity test according to EN 61000-4-5:1995(AC/DC Line to Line:...

  • Page 5: Table Of Contents

    Introduction ........1-1 About the Broadband Gateway ....... . 1-1 Features and Benefits .
  • Page 6 ABLE OF ONTENTS Wan Setting ........4-13 LAN .
  • Page 7 Configuring Your Computer with Windows NT 4.0 ..5-18 Step 1. Configure TCP/IP Settings ....5-18 Step 2.
  • Page 8 ABLE OF ONTENTS...

  • Page 9: Introduction

    HAPTER NTRODUCTION Congratulations on your purchase of the Broadband Gateway. We are proud to provide you with a powerful yet simple communication device for connecting your local area network (LAN) to the Internet. For those who want to surf on the Internet at the lowest possible cost, this Broadband Gateway provides a convenient and powerful solution.

  • Page 10: Features And Benefits

    EATURES AND ENEFITS Features and Benefits • Internet connection to xDSL or Cable modem via a 10/100 Mbps WAN port • Local network connection via 10/100 Mbps Ethernet ports • DHCP for dynamic IP configuration, and DNS for domain name mapping •...

  • Page 11: Applications

    Applications Many advanced applications are provided by the Broadband Gateway, such • LAN Access The Broadband Gateway provides connectivity to 10/100 Mbps devices, making it easy to create a network in small offices or homes. • Internet Access This device supports Internet access through an xDSL, Cable, connection.
  • Page 12 PPLICATIONS • User-Definable Application Sensing Tunnel You can define special applications that require multiple connections such as Internet gaming, videoconferencing, and Internet telephony. The Broadband Gateway can then sense the application type and open a multi-port tunnel for it. • DMZ Host Support Allows a networked computer to be fully exposed to the Internet.

  • Page 13: Installation

    Before installing the Broadband Gateway, verify that you have all the items listed under “Package Contents.” If any of the items are missing or damaged, contact your local distributor. Also be sure that you have all the necessary cabling before installing the Broadband Gateway. After installing the Broadband Gateway, refer to the Web-based configuration program in Chapter 4 for information on configuring the router.

  • Page 14: Description Of Hardware

    ROADBAND ATEWAY Description of Hardware The Broadband Gateway can be connected to the Internet or to a remote site using its RJ-45 WAN port. It can be connected directly to your PC or to a local area network using any of the Fast Ethernet LAN ports. Access speed to the Internet depends on your service type.
  • Page 15 • 4/8 RJ-45 ports for connection to a 10BASE-T/100BASE-TX Ethernet Local Area Network (LAN). These ports can auto- negotiate the operating speed to 10/100 Mbps, and the mode to half/full duplex. • One RJ-45 port for connection to an xDSL or Cable modem. This port is fixed at 10/100 Mbps, full duplex.
  • Page 16 ROADBAND ATEWAY Fast Ethernet ports (RJ-45). Connect devices on your local area Ports network to these ports (such as a PC, hub or switch). WAN port (RJ-45). Connect your Cable modem, xDSL modem, or Port an Ethernet router to this port. Power Connect the included power adapter to this inlet.

  • Page 17: System Requirements

    System Requirements You must have an ISP that meets the following minimum requirements: • Internet access from your local telephone company or Internet Service Provider (ISP) using an xDSL modem, Cable modem. • A PC using a fixed IP address or dynamic IP address assignment via DHCP, as well as a Gateway server address and DNS server address from your service provider.

  • Page 18: Basic Installation Procedure

    ROADBAND ATEWAY You should also remember to turn off the power, remove the power cord from the outlet, and keep your hands dry when you install the Broadband Gateway . Basic Installation Procedure 1. Connect the LAN: You can connect the Broadband Gateway to your PC, or to a hub or switch.
  • Page 19 network device. Each port on Broadband Gateway contains a built-in wiring crossover (MDI-X) that allows for the use of straight-through twisted-pair cable for connections to devices without built-in crossover ports. (See Appendix B for details on wiring.) Use twisted-pair cable to connect any of the 4 LAN ports on the Broadband Gateway to an Ethernet adapter on your PC.

  • Page 20: Attach The Broadband Gateway To The Internet

    ROADBAND ATEWAY Attach the Broadband Gateway to the Internet If Internet services are provided through an xDSL or Cable modem, use unshielded or shielded twisted-pair Ethernet cable (Category 3 or greater) with RJ-45 plugs to connect the broadband modem directly to the WAN port on the Broadband Gateway .

  • Page 21: Verify Port Status

    Verify Port Status Check the power and port indicators as shown in the following table. Condition Power (Green) (Green) Flashing Link/Act (Green) Flashing ROADBAND ATEWAY Status Broadband Gateway is receiving power. The WAN port has established a valid network connection. The WAN port is transmitting or receiving traffic.

  • Page 22: Configuring Client Pcs

    ONFIGURING TCP/IP Configuration To access the Internet through the Broadband Gateway, you must configure the network settings of the computers on your LAN to use the same IP subnet as the Broadband Gateway. The default network settings for the Broadband Gateway are: IP Address: 192.168.1.1 Subnet Mask: 255.255.255.0 Note: These settings can be changed to fit your network requirements,...
  • Page 23 TCP/IP C ONFIGURATION...

  • Page 24: Configuring The Broadband Gateway

    HAPTER ONFIGURING THE ROADBAND ATEWAY After you have configured TCP/IP on a client computer, you can use a Web browser to configure the Broadband Gateway. The Broadband Gateway can be configured by any Java-supported browser including Internet Explorer 5.0 or above, or Netscape Navigator 4.71 or above. Using the Web management interface, you can configure the Broadband Gateway and view statistics to monitor network activity.

  • Page 25: Navigating The Web Browser Interface

    AVIGATING THE Navigating the Web Browser Interface The Broadband Gateway’s management interface includes two key menus – Setup wizard, and Advanced Setup. The setup wizard menus provide general information on the current settings and how to configure the Broadband Gateway. The Advanced Setup menu is used to configure the LAN and WAN interface, as well as other advanced functions such as reset the Broadband Gateway, restore the factory settings, or upgrade firmware.

  • Page 26: Main Menu

    Main Menu Using the Web management interface, you can define system parameters, manage and control the Broadband Gateway and its ports, or monitor network conditions. The following table briefly describes the selections available from this program. Menu Setup Wizard Advanced Setup Setup Wizard Manu Time Zone WAN Type...
  • Page 27 Menu System Menu System Time Administrator Settings Firmware Upgrade Configuration Tools Status Security Log Reset WAN Menu Dynamic IP Static IP PPPoE PPTP LAN Menu LAN Settings DHCP Client List NAT Menu Special Application Description Sets the local time zone. Sets the password and Remote Management for administrator access.

  • Page 28: Time Zone

    Menu Virtual Server Firewall Menu Block WAN Ping Client Filtering MAC Control Time Zone Set the time zone for the Broadband Gateway. This information is used for log entries and client filtering. ONFIGURING THE Description You can configure the Broadband Gateway as a virtual server so that remote users accessing services such as the Web or FTP at your local site via public IP addresses can be automatically...

  • Page 29: Wan Type

    WAN Type Specify the WAN connection type required by your Internet Service Provider. Specify a Cable modem(Dynamic IP), Fixed-IP xDSL, PPPoE xDSL, or PPTP. WAN Setting Cable Modem (Dynamic IP) Set Cable moden host name and MAC address.

  • Page 30: Fixed-Ip Xdsl

    ONFIGURING THE ROADBAND ATEWAY Fixed-IP xDSL Enter the IP address, subnet mask, and gateway provided to you by your ISP in the appropriate fields. Dial-Up xDSL(PPPoE) Enter the User Name and Password required by your ISP in the appropriate fields. If your ISP has provided you with a Service Name, enter it in the Service Name field, otherwise, leave it blank.

  • Page 31: Pptp

    PPTP Enter the Account Name, Account Password, Host Name, Service IP Address, Your IP Address, Your Subnet Mask required by your ISP in the appropriate fields. If your ISP has provided you with a connection ID, enter it in the Connection ID field, otherwise, leave it as zero. Domain Name Servers are used to map an IP address to the equivalent domain name.

  • Page 32: Advanced Setup

    Advanced Setup The Broadband Gateway supports advanced functions like hacker attack detection, client filtering, virtual servers, special application access, and a virtual DMZ host. We recommends you keep the default settings. System Setting System Time Connecting to a Simple Network Time Protocol (SNTP) server allows the Broadband Gateway to synchronize the system clock to the global Internet.

  • Page 33: Administrator Settings

    DVANCED ETUP Administrator Settings Use this menu to restrict management access based on a specific password. Anyone can access the Status and Help menus, but you must enter a password to access the configuration options provided by the Setup and Tools menus.

  • Page 34: Firmware Update

    ONFIGURING THE ROADBAND ATEWAY Firmware Update Enter the path and name of the upgrade file then click the APPLY button below. You will be prompted to confirm the upgrade. Configuration Tools Use the "Backup Settings" tool to save the IP Gateway's current configuration to a file named "config.bin"...

  • Page 35: Status

    DVANCED ETUP Status You can use the Status screen to see the connection status for the Broadband Gateway WAN/LAN interfaces, firmware and hardware version numbers, and the number of connected clients to your network. Security Log View any attempts that have been made to gain access to your network. Reset In the event that the Broadband Gateway stops responding correctly or in 4-12...

  • Page 36: Wan Setting

    some way stops functioning, you can perform a reset. Your settings will not be changed. To perform the reset, click on the "Reset" button below. You will be asked to confirm your decision. The reset will be complete when the power light stops blinking. WAN Setting Specify the WAN connection type required by your Internet Service Provider, then click “More Configuration”...

  • Page 37: Dynamic Ip

    DVANCED ETUP Dynamic IP The Host Name is optional, but may be required by some ISPs. The default MAC address is set to the WAN’s physical interface on the Broadband Gateway. Use this address when registering for Internet service, and do not change it unless required by your ISP. You can use the “Clone MAC Address”...

  • Page 38: Pppoe

    ONFIGURING THE ROADBAND ATEWAY PPPoE Enter the PPPoE user name and password assigned by your ISP. The Service Name is normally optional, but may be required by some providers. PPTP The acronym of Point to Point Tunnelling Protocol, PPTP encapsulates the packet for transmission over the Internet.

  • Page 39: Dns

    DVANCED ETUP Domain Name Servers are used to map an IP address to the equivalent domain name. Your ISP should provide the IP address for one or more domain name servers. Enter those addresses on this screen. LAN Settings Configure the gateway address of the Broadband Gateway. To dynamically assign the IP address for client PCs, enable the DHCP Server, set the lease time, and then specify the address range.

  • Page 40: Dhcp Client

    ONFIGURING THE ROADBAND ATEWAY DHCP Client List The DHCP client list allows you to see which clients are connected to the Broadband Gateway via IP address, host name, and MAC address. NAT Setting Special Application Some applications require multiple connections, such as Internet gaming, videconferencing, Internet telephone and others.

  • Page 41: Virtual Server

    DVANCED ETUP Virtual Server If you configure the Broadband Gateway as a virtual server, remote users accessing services such as Web or FTP at your local site via public IP addresses can be automatically redirected to local servers configured with private IP addresses.

  • Page 42: Block Wan Ping

    ONFIGURING THE ROADBAND ATEWAY Block WAN Ping When you "Block WAN Ping", you are causing the public WAN IP address on the Elle to not respond to ping commands. Pinging public WAN IP addresses is a common method used by hackers to test whether your WAN IP address is valid and supports a network.

  • Page 43: Mac Control

    DVANCED ETUP MAC Control You can block certain client PCs accessing the Internet based on MAC addresses. DMZ(Demilitarized Zone) The DMZ Host aplication allows unrestricted 2-way communication between a single LAN PC and other Internet users or servers. This application is useful for supporting special-purpose services such as video-conferencing and gaming, that require proprietary client software and/or 2-way user communication.

  • Page 44: Hardware Reset

    ONFIGURING THE ROADBAND ATEWAY Hardware Reset If you forget your password, you can use hardware reset to force the IP Gateway to restore the oritional factory setting. You need power off the IP Gateway and get a ehternet cable, insert to WAN port and LAN port. Power on and wait the LED flash three times.

  • Page 45: Configuring Client Tcp/Ip

    HAPTER ROADBAND ATEWAY TCP/IP ONFIGURING LIENT If you have not previously installed the TCP/IP protocol on your client PCs, refer to the following section. If you need information on how to configure a TCP/IP address on a PC, refer to “Setting TCP/IP to Work with the Broadband Gateway”...
  • Page 46 TCP/IP P NSTALLING 5. Select the Microsoft item in the manufacturers list. And choose TCP/IP in the Network Protocols. Click the OK button to return to the Network window. 6. The TCP/IP protocol will be listed in the Network window. Click OK to complete the install procedure and restart your PC to enable the TCP/IP protocol.

  • Page 47: Setting Tcp/Ip To Work With The Broadband Gateway

    Setting TCP/IP to Work with the Broadband Gateway 1. Click the Start button and choose Settings, then click Control Panel. 2. Double click the Network icon. Select the TCP/IP line that has been assigned to your network card in the Configuration tab of the Network window.

  • Page 48: Configuring Your Computer With Windows 95/98/Me

    TCP/IP ETTING Configuring Your Computer with Windows 95/98/ME You may find that the instructions here do not exactly match your version of Windows. This is because these steps and screenshots were created from Windows 98. Windows 95 and Windows Millennium Edition are very similar, but not identical, to Windows 98.
  • Page 49 ROADBAND 2. From "Control Panel," double-click the "Network" icon. 3. In the "Network" window, under the "Configuration" tab, double-click the "TCP/IP" entry that is listed with your network card. ATEWAY ONFIGURING TCP/IP LIENT...

  • Page 50: Step 2. Disable Http Proxy

    TCP/IP ETTING 4. Select the "IP Address" tab. If "Obtain an IP address automatically" is already selected, your computer is already configured for DHCP. Click "Cancel" to close each window, and skip to Step 2 "Disable HTTP Proxy." 5. Locate your IP address and Subnet Mask.
  • Page 51 ROADBAND 7. Click the "DNS Configuration" tab. Locate the DNS servers listed under "DNS Server Search Order." Record the listed addresses. 8. After writing down your settings, check to make sure you have recorded them correctly. Click the "IP Address" tab and then click "Obtain an IP address automatically."...
  • Page 52 TCP/IP ETTING Internet Explorer 1. Open Internet Explorer and click the stop button. Click "Tools," then "Internet Options." 2. In the "Internet Options" window click the "Connections" tab. Next, click the "LAN Settings..." button. 3. Clear all the checkboxes. 4. Click "OK," and then click "OK"...

  • Page 53: Step 3. Obtain Ip Settings From Your Broadband Gateway

    ROADBAND Netscape 1. Open Netscape and click the stop button. Click "Edit," then click "Preferences..." 2. In the "Preferences" window, under "Category" double-click "Advanced," then click "Proxies." Select "Direct connection to the Internet." Click "OK." 3. Repeat these steps for each Windows 95/98/Me computer connected to your Broadband Gateway.
  • Page 54 TCP/IP ETTING 1. Click "Start," then "Run..." 2. Type "WINIPCFG" and click "OK." It may take a minute or two for the "IP Configuration" window to appear. 3. From the drop-down menu, select your network card. Click "Release" and then "Renew."...

  • Page 55: Configuring Your Computer With Windows 2000

    Configuring Your Computer with Windows 2000 Step 1. Configure TCP/IP Settings After you have completed the hardware setup, you need to configure your computer to connect to your Broadband Gateway. You also need to determine how your ISP issues your IP address. Many ISPs issue these numbers automatically, using a networking technology known as Dynamic Host Control Protocol, or DHCP.
  • Page 56 TCP/IP ETTING 3. Double-click the icon that corresponds to the connection to your Broadband Gateway. 4. Click "Properties." 5. Double-click "Internet Protocol (TCP/IP)." 5-12 ORK WITH THE ROADBAND ATEWAY...

  • Page 57: Step 2. Disable Http Proxy

    ROADBAND 6. All the information that you need to record is on the "Internet Protocol (TCP/IP) Properties" dialog box. Use the spaces below to record the information. If "Obtain an IP address automatically" and "Obtain DNS server address automatically" are already selected, your computer is already configured for DHCP.

  • Page 58: Internet Explorer

    TCP/IP ETTING Internet Explorer 1. Open Internet Explorer and click the stop button. Click "Tools," then "Internet Options." 2. In the "Internet Options" window click the "Connections" tab. Next, click the "LAN Settings..." button. 3. Clear all the checkboxes. 4. Click "OK," and then click "OK"...
  • Page 59 ROADBAND Netscape 1. Open Netscape and click the stop button. Click "Edit," then click "Preferences..." 2. In the "Preferences" window, under "Category" double-click "Advanced," then click "Proxies." Select "Direct connection to the Internet." Click "OK." ATEWAY ONFIGURING TCP/IP LIENT 5-15...

  • Page 60: Step 3. Obtain Ip Settings From Your Broadband Gateway

    TCP/IP ETTING Step 3. Obtain IP Settings From Your Broadband Gateway Now that you have configured your computer to connect to your Broadband Gateway, it needs to obtain new network settings. By releasing any old IP settings and renewing them with settings from your Broadband Gateway, you will also verify that you have configured your computer correctly.
  • Page 61 ROADBAND 2. In the "Command Prompt" window, type "IPCONFIG /RELEASE" and press the <ENTER> key. 3. Type "IPCONFIG /RENEW" and press the <ENTER> key. Verify that your IP address is now 192.168.1.xxx (2-255), your Subnet Mask is 255.255.255.0 and your Default Gateway is 192.168.1.1. These values confirm that your Broadband Gateway is functioning.

  • Page 62: Configuring Your Computer With Windows Nt 4.0

    TCP/IP ETTING Configuring Your Computer with Windows NT 4.0 Step 1. Configure TCP/IP Settings After you have completed the hardware setup, you need to configure your computer to connect to your Broadband Gateway. You need to determine how your ISP issues your IP address. Many ISPs issue these numbers automatically using a networking technology known as Dynamic Host Control Protocol, or DHCP.
  • Page 63 ROADBAND 3. Select the "Protocols" tab. 4. Double-click "TCP/ IP Protocol." 5. Select the "IP Address" tab. 6. In the "Adapter" drop-down list, be sure your Ethernet adapter is selected. If "Obtain an IP address automatically" is already selected, your computer is already configured for DHCP.
  • Page 64 TCP/IP ETTING 7. In the "TCP/IP Properties" dialog box, click the IP address tab to locate your IP address, subnet Mask, and default gateway. Record these values in the space provided below. 8. Click the "DNS" tab to see the primary and secondary DNS servers.

  • Page 65: Step 2. Disable Http Proxy

    ROADBAND Step 2. Disable HTTP Proxy You will need to verify that the "HTTP Proxy" feature of your Web browser is disabled. This is so that your Web browser will be able to view the configuration pages inside your Broadband Gateway. The following steps are for Internet Explorer and for Netscape.

  • Page 66: Step 3. Obtain Ip Settings From Your Broadband Gateway

    TCP/IP ETTING 3. Clear all the checkboxes. 4. Click "OK," and then click "OK" again to close the "Internet Options" window. Netscape 1. Open Netscape and click the stop button. Click "Edit," then click "Preferences..." 2. In the "Preferences" window, under "Category"...
  • Page 67 ROADBAND releasing any old IP settings and renewing them with settings from your Broadband Gateway, you will also verify that you have configured your computer correctly. 1. From the Windows desktop, click the "Start" button, then "Programs," and then select "Command Prompt."...

  • Page 68: Configuring Your Macintosh Computer

    TCP/IP ETTING values confirm that your Broadband Gateway is functioning. 4. Type "EXIT" and press <ENTER> to close the "Command Prompt" window. Configuring Your Macintosh Computer You may find that the instructions here do not exactly match your screen. This is because these steps and screenshots were created using Mac OS 8.5.
  • Page 69 ROADBAND 1. Pull down the Apple Menu. Click "Control Panels" and select TCP/IP. 2. In the TCP/IP dialog box, make sure that "Ethernet" is selected in the "Connect Via:" field. If "Using DHCP Server" is already selected in the "Configure" field, your computer is ATEWAY ONFIGURING...

  • Page 70: Step 2. Disable Http Proxy

    TCP/IP ETTING already configured for DHCP. Close the TCP/IP dialog box, and skip to Step 2 "Disable HTTP Proxy." 3. All the information that you need to record is on the "TCP/IP" dialog box. Use the space below to record the information. 4.
  • Page 71 ROADBAND Internet Explorer 1. Open Internet Explorer and click the stop button. Click "Edit" and select "Preferences." 2. In the Internet Explorer Preferences window, under Network, select Proxies. 3. Uncheck checkboxes and click Netscape 1. Open Netscape and click the stop button. Click "Edit"...

  • Page 72: Step 3. Obtain Ip Settings From Your Broadband Gateway

    TCP/IP ETTING 2. In the "Preferences" dialog box, In the left-hand column labeled "Category," select "Advanced." Under the "Advanced" category, select "Proxies." 3. Select "Direct Connection to the Internet" and click OK. Step 3. Obtain IP Settings From Your Broadband Gateway Now that you have configured your computer to connect to your Broadband Gateway, it needs to obtain new network settings.
  • Page 73 ROADBAND 1. Pull down the Apple Menu. Click "Control Panels" and select TCP/IP. 2. In the TCP/IP window, your new settings will be shown. Verify that your IP address is 192.168.1.xxx, your Subnet Mask is 255.255.255.0 and your Default Gateway is 192.168.1.1.

  • Page 74: Dynamic Ip Allocation Via A Dhcp Server

    TCP/IP ETTING Dynamic IP Allocation via a DHCP Server Select Obtain an IP address automatically in the IP Address tab. Do not input any values under the Gateway tab, and choose Disable DNS in the DNS Configuration tab. These settings will be automatically configured by the DHCP server.

  • Page 75: Manual Ip Configuration

    Manual IP Configuration 1. Select Specify an IP address in the IP Address tab. Select an IP address based on the default network 192.168.1.X (where X is between 2 and 254), and use 255.255.255.0 for the subnet mask. 2. In the Gateway tab, add the IP address of the Broadband Gateway (default: 192.168.1.1) in the New gateway field and click Add.

  • Page 76: Verifying Your Tcp/Ip Connection

    TCP/IP ETTING Verifying Your TCP/IP Connection After installing the TCP/IP communication protocol and configuring an IP address in the same network with the Broadband Gateway, you can use the Ping command to check if your computer is successfully connected to the Broadband Gateway. The following example shows how the Ping procedure can be executed in an MS-DOS window.
  • Page 77 ROADBAND This appendix describes common problems you may encounter and possible solutions. The Broadband Gateway can be easily monitored through panel indicators to identify problems. If you cannot resolve any connection problems after checking the indicators, then refer to the other sections in the following table.
  • Page 78 ROADBAND ATEWAY Symptom LED Indicators Link LED is Off Network Connection Problems Cannot Ping the Broadband Gateway from the attached LAN, or the Broadband Gateway cannot Ping any device on the attached ROUBLESHOOTING Troubleshooting Chart Action • Verify that the Broadband Gateway and attached device are powered on.

  • Page 79: Troubleshooting

    Symptom Management Problems Cannot connect using the Web browser ROADBAND Troubleshooting Chart Action • Be sure to have configured the Broadband Gateway with a valid IP address, subnet mask and default gateway. • Check that you have a valid network connection to the Broadband Gateway and that the port you are using has not been disabled.
  • Page 80 ROADBAND ATEWAY ROUBLESHOOTING...

  • Page 81: Cables

    Ethernet Cable Specifications Cable 10BASE-T 100BASE-TX Cat. 5 100-ohm UTP Twisted-pair Cable Caution: DO-NOT plug a phone jack connector into any RJ-45 port. Use only twisted-pair cables with RJ-45 connectors that conform with FCC standards. For 10BASE-T/100BASE-TX connections, a twisted-pair cable must have two pairs of wires.

  • Page 82: Straight-Through Cable

    ROADBAND ATEWAY Figure B-1 illustrates how the pins on the RJ-45 connector are numbered. Be sure to hold the connectors in the same orientation when attaching the wires to the pins. Figure B-1. RJ-45 Connector Pin Numbers Straight-through Cable Straight-Through RJ-45 Pin Assignments End 1 1 (TD+) 2 (TD-)

  • Page 83: Rj-45 Port Pin Assignments

    RJ-45 Port Pin Assignments All LAN ports on the Broadband Gateway support automatic MDI/ MDI-X configuration. This means that the pin signals in use will depend on whether the LAN port is operating in MDI or MDI-X mode. However, the WAN port is configured only for MDI-X mode. MDI Signal Name* Transmit Data (TD+) Transmit Data (TD-)

  • Page 84: Specifications

    WAN Interface 10BASE-T/100BASE-TX, 1 RJ-45 port Management Web management Advanced Features Dynamic IP Address Configuration – DHCP, DNS Firewall – Client privileges, hacker prevention and logging Virtual Private Network – PPTP, L2TP, IPSec pass-through Internet Standards ARP (RFC 826), IP (RFC 791), ICMP (RFC 792), UDP (RFC 768), TCP (RFC 793), Telnet (RFC 854-859), MD5 (RFC 1321), BOOTP Extension (RFC 1497), PPP LCP Extension (RFC 1570), PPPoE (RFC 2516), NAT (RFC 1631), PPP (RFC 1661), HTML (RFC 1866), HTTP (RFC 1945),...
  • Page 85 PECIFICATIONS Immunity EN 61000-3-2/3 EN 61000-4-2/3/4/5/6/8/11 LAN Interface 10BASE-T/100BASE-TX 4 RJ-45 ports Indicator Panel LAN (Link, Activity), WAN (Link, Activity), Power Dimensions 103.4 x 83.5 x 26.2 mm (4.07 x 3.27 x 1.02 inch) (IRS405 R01) 146.6 x 83.5 x 26.2 mm (5.79 x 3.27 x 1.02 inch) (IRS405 R02) Weight 0.55 lbs (0.25 kg) (IRS405 R01) 0.7 lbs (0.315 kg) (IRS405 R02)

  • Page 86: Broadband Gateway

    PPENDIX ROADBAND ATEWAY RDERING NFORMATION Broadband Gateway Products Broadband Gateway 4-port Internet Gateway - WAN/LAN...

  • Page 87: Ordering Information

    ROADBAND ATEWAY RDERING NFORMATION...
