- Page 1 8-port 10/100/1000Base-T Switch Quick Installation Guide...
-
Page 2: Table Of Contents
Connecting the Switch System Making a Connection to an RJ-45 Port Powering On the Switch Verifying Port Status Verifying System Operation Applications Configuring the Switch from the Console Port Required Connections Log-in Screen Main Menu Displaying System Information Configuring Port Parameters... -
Page 3: Introduction
To manage the switch, you can make a direct connection to the console port on the switch’s rear panel. You can configure the switch’s wide array of advanced features, such as: •... -
Page 4: Installing The Switch
Installing the Switch Before installing the switch verify that you have all the items listed under “Package Contents.” If any of the items are missing or damaged, contact your local distributor. Also be sure you have all the necessary tools and cabling before installing the switch. Note that this switch can be installed on any suitably large flat surface or in a standard EIA 19-inch rack. -
Page 5: Mounting The Switch
• Power requirements: 100 to 240 VAC (± 10%) at 50 to 60 Hz (± 3Hz). The switch's power supply automatically adjusts to the input voltage level. • The switch should be located in a cool dry place, with at least 10 cm (4 in.) of space on the sides for ventilation. -
Page 6: Connecting The Switch System
Powering On the Switch Plug the power cord into the power socket on the rear of the switch, and the other end into a power outlet. (If you have purchased a redundant power supply, plug it into the “DC INPUT”... -
Page 7: Verifying Port Status
Verify that all attached devices have a valid connection. The switch monitors the link status for each port. If any device is properly connected to the switch, the Link indicator will light up for the corresponding port. If the Link indicator fails to light when you connect a device to the switch, check the following items: •... -
Page 8: Applications
Gigabit Ethernet-compliant device, such as another switch or a server’s network adapter. All switch ports can operate at 1000 Mbps full duplex, providing 2 Gbps of bandwidth to the attached device. -
Page 9: Configuring The Switch From The Console Port
Required Connections Attach a VT100 compatible terminal or a PC running a terminal emulation program to the serial port on the switch’s rear panel. Use the null-modem cable provided with this package, or use a null-modem connection. When attaching to a PC, set terminal emulation type to VT100, specify the port used by your PC (i.e., COM 1~4), and then set communications to 8 data bits, 1 stop bit, no parity, and 38400 bps. -
Page 10: Log-In Screen
Log-in Screen Once a direct connection to the serial port is established, the log-in screen for the onboard configuration program appears as shown below. Smart Switch User Interface v1.04 (c) Copyright 2002 Mototech Inc. Password : If this is your first time to log into the configuration program, then the default password is “admin.”... -
Page 11: Main Menu
With the system configuration program you can display system parameters and manage and control the switch and all its ports. The screen below of the configuration Main Menu and the table following it briefly describe the selections available from this program. -
Page 12: Displaying System Information
Displaying System Information Use the System Configuration screen to display the administator’s password and the current settings of the system. Smart Switch : System Configuration ============= Password Aging time Logout time Auto refresh time :12 Use arrow keys to move. <Enter> to make changes. -
Page 13: Configuring Port Parameters
Used to enable or disable flow control. Flow control can eliminate frame loss by “blocking” traffic from end stations or segments connected directly to the switch when its buffers fill. When enabled, back pressure is used for half duplex, and IEEE 802.3x for full duplex. Note that flow control should not be used if a port is connected to a hub. -
Page 14: Configuring Port Trunks
You can configure trunks between any two ES4008A switches. The ports on this switch can be grouped into a trunk consisting of two, three or four ports, creating an aggregate bandwidth up to 4, 6, or 8 Gbps. Besides balancing the load across each port in the trunk, the additional ports provide redundancy by taking over the load if another port in the trunk fails. - Page 15 You can use the Port Trunking Configuration screen to set up port trunks as shown below: Smart Switch: Port Trunking Configuration ============ List Current Link Aggregates Port Count Port Number Trunk1 port 1 to 2 Trunk2 port 3 to 4...
-
Page 16: Using A Mirror Port For Analysis
VLAN as the source port. You can use the Mirror Configuration Port screen to mirror one or any ports to the port 8 as shown below. The default is that port mirroring is disabled. Smart Switch : Mirror Port Configuration ============= Monitored Port:... -
Page 17: Configuring Virtual Lans
Configuring Virtual LANs You can use the VLAN configuration menu to assign any port on the switch to any of up to 32 LAN groups. In conventional networks with routers, broadcast traffic is split up into separate domains. Switches do not inherently support broadcast domains. This can lead to broadcast storms in large networks that handle traffic such as IPX or NetBeui. -
Page 18: Priority Configuration
Priority Configuration This switch supports Quality of Service (QoS) by using four priority queues from 0 (lowest priority), to 3 (highest priority). Inbound frames that do not have priority tags are tagged with the input port’s default priority tag, and then placed in the appropriate priority queue at the output port. -
Page 19: Displaying Port Statistics
Displaying Port Statistics. Port Statistics display standard statistics on network traffic from the Interfaces Group and Ethernet-like MIBs. Smart Switch: Port Statistic ============ Interfaces In Octets In Unicast Pkts In Non-Unicast Pkts In Discards In Errors Alignment Errors Ethernet Single Collisions... - Page 20 Parameter Description Out Discards The number of outbound packets which were chosen to be discarded even though no errors had been detected to prevent their being transmitted. One possible reason for discarding such a packet could be to free up buffer space.
-
Page 21: Resetting The System
Resetting the System Select the System Restart Menu under the Main Menu to reset the switch. The reset screen includes options as shown in the following figure and table. Smart Switch : System Restart ============= <Factory default> <Restart> Use arrow keys to move. <Enter> to confirm. -
Page 22: Product Specifications
Product Specifications Physical Characteristics Access Method CSMA/CD Standards Conformance IEEE 802.3ab 1000BASE-T Communication Rate RJ-45 Ports: 1000, 100, 10 Mbps Communication Mode Full and half duplex Number of Ports 1000BASE-T/GBIC: 8 RJ-45 ports Indicator Panel System: Power Ports: Link, ACT, FDX Dimensions 440 x 285 x 64 mm (17.37 x 11.22 x 2.53 in.) Weight... -
Page 23: Troubleshooting
Troubleshooting Diagnosing Switch Indicators The switch can be easily monitored through panel indicators to assist the network manager in identifying problems. The table below describes common problems you may encounter and possible solutions. Symptom Cause Link indicator does Network interface (e.g., a... -
Page 24: Port And Cable Assignments
DO NOT plug a phone jack connector into any RJ-45 port. Use only twisted-pair cables with RJ-45 connectors that conform with FCC standards. The RJ-45 ports on the 1000BASE-T switch operate at 10 Mbps, 100 Mbps, and 1000 Mbps, full and half duplex, with support for auto-negotiation of speed, duplex mode and flow control. -
Page 25: 1000Base-T Cable Requirements
1000BASE-T Cable Requirements All Category 5 UTP cables that are used for 100BASE-TX connections should also work for 1000BASE-T, providing that all four wire pairs are connected. However, it is recommended that for all critical connections, or any new cable installations, Category 5e (enhanced Category 5) cable should be used. -
Page 26: Emi Certification
EMI Certification FCC Class A Certification (USA) This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause interference to radio communications. It has been tested and found to comply with the limits for a Class A computing device pursuant to Subpart A of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment. - Page 27 • Surge immunity test according to EN 61000-4-5:1995 (AC/DC Line to Line: ±1 kV, AC/DC Line to Earth: ±2 kV) • Immunity to conducted disturbances, Induced by radio-frequency fields: EN 61000-4-6:1996 (0.15 - 80 MHz with 1 kHz AM 80% Modulation: 3 V/m) •...
