Summary of Contents for Abra AK-50
- Page 1 AK-50...
- Page 2 Parts List: Please ensure you have the following materials included in your kit. Component Quantity Remarks PCB Reference Number 10kΩ Resistor Brown, Black, Orange, Gold R1, R5, R3 1kΩ Resistor Brown, Black, Red, Gold R2, R4, R6 2.2kΩ Resistor Red, Red, Red, Gold 2N9014 NPN Epitaxial Transistor Q1, Q2, Q3...
- Page 3 Installation: Ensure you all the parts that were provided to you in your kit. Begin the process by taking B1 and soldering the 2N9014 Transistors into their respective PCB Ref number, indicated in the parts list above. Cut any excess leads on the back after soldering the components.
- Page 4 Solder for the base the push button and dc socket to the base board. Ensure for the Push button that the trapezoid cut is facing outwards. This ensures the following statement to be correct: “When the LEDs are pressed it will turn on, when pressed to be released the LEDs will turn off.” If soldered the other way this logic is reversed.
