INTRODUCTION
To the owner or user: The service manual
you are reading is intended to provide you,
and the maintenance or service technician,
with the information needed to install, start up,
clean, maintain, and service this ice system.
The FM1500R is a remote condenser modular
ice system that fits a variety of Scotsman ice
storage bins.
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Remote Condenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
For the Plumber . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Final Check List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Component Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Maintenance & Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Water Reservoir & Bin Controls . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Bearing & Breaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Auger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Gearmotor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Circuit Board Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Parts Lists and Wiring Diagrams are located in the center of this manual, printed on yellow
paper.
TABLE OF CONTENTS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
November, 1988
It features: front service for the freezer,
gearmotor, control box, water reservoir, and
bin control; stackable with kit KSTACK30; an
electronic circuit for monitoring ice and water
level; a thermostatic expansion valve; and
R-502 as the refrigerant.
Page 1
FM1500R
Advertisement
Table of Contents
Related Manuals for Scotsman FM1500R
Summary of Contents for Scotsman FM1500R
-
Page 1: Table Of Contents
R-502 as the refrigerant. The FM1500R is a remote condenser modular ice system that fits a variety of Scotsman ice storage bins. TABLE OF CONTENTS For the Installer Specifications . -
Page 2: For The Installer
FM1500R FOR THE INSTALLER The FM1500R is designed to fit the following Correct Condenser Scotsman storage bins: Correct Bin B590 and extensions (with bin top KBT18) Correct Ice Machine HTB500 or BH500 Correct Bin Top (if required) BH800 using bin top KBT15... - Page 3 They meet or exceed the standards of UL, NSF, and CSA. 6" Scotsman assumes no liability or responsibility of any kind for products manufactured by Scotsman 32" 5" that have been altered in any way, including the use of any part and/or other components not specifically approved by Scotsman.
- Page 4 BASIC MINIMUM CIRC. H" x W" x D" ELECTRICAL AMPACITY+ RC1051-32A 27.81" x 22" x 37.94" 1 FM1500R 208-230/60/1 RC1052-32A same 1 or 2 FM1500Rs same same + Included with minimum circuit ampacity for the icemaker. Use this valve to determine wire size and type between ice maker and fan motor.
-
Page 5: Location
FM1500R FOR THE INSTALLER LEVEL THE ASSEMBLY Location: After uncrating and inspection, the unit is ready for installation. It is important that the machine be installed in a location where it has enough space around it to be accessible for service, usually a minimum of 6 inches. -
Page 6: Remote Condenser
FM1500R FOR THE INSTALLER: Remote Condenser Installation Location: //////////////////////////////CAUTION//////////////////////////// Limited to a 40 foot or a 25 foot length of DO NOT KINK OR CRIMP REFRIGERANT precharged refrigerant tubing connecting the TUBING WHEN INSTALLING IT. icemaker to the remote condenser. The... - Page 7 FM1500R FOR THE INSTALLER COUPLING INSTRUCTIONS ///////////////////////////CAUTION////////////////////////////// The couplings on the sets of precharged lines are self sealing when installed properly. Carefully follow the instructions: ////////////////////////////////////////////////////////////////////////// 1. Remove the protector caps and plugs. SERVICE PORTS Wipe the seats and threaded surfaces with a clean cloth to be certain that no foreign matter remains on them.
- Page 8 FM1500R FOR THE INSTALLER: Stacking KSNM30 STACKING KIT INSTRUCTIONS 9. Unplug the "photo trans" ice level sensor from the connection on the ice machine circuit The purpose of the this kit is to connect the ice board, pull it out of the control box, and plug it level controls from the bottom machine to an into the "photo stack"...
-
Page 9: For The Plumber
FM1500R FOR THE PLUMBER CONFORM TO ALL APPLICABLE CODES Water Inlet Drains The recommended water supply is cold water. There is one 3/4" FPT drain at the back of the Use 3/8" O.D. copper tubing, connect to the cabinet, the drain line is of the gravity type, 3/8"... -
Page 10: For The Electrician
FM1500R FOR THE ELECTRICIAN CONFORM TO ALL APPLICABLE CODES The electrical power to the unit is supplied through the junction box at the rear of the machine. Check the nameplate (located on the back panel) for the voltage REMOTE CONDENSER... - Page 11 FM1500R FOR THE ELECTRICIAN FAN RELAY KIT To install the KCMR230 fan relay kit when 2. Attach a solid earth ground wire to the using (2) NM1250R icemakers and one 230 ground screw. volt, two circuit remote condenser. 3. Route connecting wires from the first ice...
- Page 12 FM1500R FOR THE ELECTRICIAN (Do this after Start Up) 6. Check phasing of the electrical circuit as 2. Test with a volt meter between terminals follows: #2 and #4, then between terminals #1 and #3. Compare the readings obtained to the ones in A.
- Page 13 FM1500R FOR THE INSTALLER: Completed Installation A typical installation should generally appear as illustrated below. The remote condenser must be located above the icemaker and the precharged lines installed per the instructions on page 6. ROOF CUT-AWAY INSULATED PRECHARGED REFRIGERANT TUBING...
-
Page 14: Final Check List
FM1500R FOR THE INSTALLER: Final Check List 1. Is the ice system installed indoors in a location where the air and water temperatures are controlled, and where they do not exceed the design limitations? 2. Is there an electrical service... -
Page 15: Start Up
10. Fill out the manufacturers registration 5. The remote condenser fan turns, and the card, and mail it to the Scotsman Factory. condenser begins to discharge warm air. 11. Fill out the field quality audit form, and mail 6. -
Page 16: Component Description
FM1500R COMPONENT DESCRIPTION Control Box: Contains the electrical controls Water Level Sensor: Senses if there is water that operate the machine. in the reservoir to make ice out of. Will shut the machine off it there is none. High Pressure Cut Out (control): A manual... - Page 17 FM1500R COMPONENT DESCRIPTION: Control Box Contactor: A definite purpose contactor Pump Down Control: A switch to control the connecting the compressor and the remote compressor, depending upon low side condenser fan motor to the power supply. pressure: closes at 18 PSIG, and opens at 8 PSIG.
- Page 18 FM1500R ELECTRICAL SEQUENCE Refer the wiring diagram as needed. Shut Down consists of: • • The liquid line solenoid relay opens, lowering the suction pressure. If the machine is switched off at the master • • switch, but is otherwise ready to go, switching The pump down pressure control opens.
-
Page 19: Operation
FM1500R OPERATION Water Water enters the machine through the 3/8" male flare at the rear of the cabinet, goes to the water reservoir which it enters through the float valve. The water then goes out the bottom of the reservoir tank to the bottom of the evaporator. - Page 20 FM1500R OPERATION: Beginning at the compressor, the refrigerant The thermostatic expansion valve meters 502 is compressed into a high temperature liquid refrigerant into the evaporator, the gas. The discharge line directs this gas to the volume of liquid refrigerant depending upon condenser and to the head pressure control the temperature of the evaporator;...
- Page 21 FM1500R OPERATION: Refrigeration LOW CONDENSING TEMPERATURE The refrigeration system under low condenser condenser (with a small amount of discharge air temperatures is much the same as it is gas going into the receiver to maintain under higher temperatures, with the exception...
- Page 22 FM1500R OPERATION: Refrigeration REMOTE CONDENSER LIQUID LINE DISCHARGE LINE LIQUID LINE VALVE (CLOSED) RECEIVER COMPRESSOR PUMP DOWN During the pump down cycle (usually initiated is stopped by the closed liquid line valve. This by the circuit board de-energizing the liquid...
-
Page 23: Maintenance & Cleaning
FM1500R MAINTENANCE AND CLEANING /////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////// A Scotsman Ice System represents a sizable investment of time and money in any company’s business. In order to receive the best return for that investment, it MUST receive periodic maintenance. It is the USER’S RESPONSIBILITY to see that the unit is properly maintained. It is always preferable, and less costly in the long run, to avoid possible down time by keeping it clean;... - Page 24 FM1500R ICEMAKER MAINTENANCE: ////////////////////////////WARNING///////////////////////////// ICE DISCHARGE Disconnect electrical power before begining. CHUTE ////////////////////////////////////////////////////////////////////////// 1. The bin control uses devices that sense SLIDE IN AND light, therefore they must be kept clean enough so that they can "see". At least twice...
- Page 25 FM1500R MAINTENANCE: Auger ////////////////////////////WARNING///////////////////////////// For more information on removal of these parts, see REMOVAL AND REPLACEMENT. Disconnect electrical power before begining. SHUT OFF WATER SUPPLY ////////////////////////////////////////////////////////////////////////// 1. To remove the auger, remove front and top In some areas the water supply to the panels.
-
Page 26: Service Diagnosis
FM1500R SERVICE DIAGNOSIS: Condition - No Ice Being Produced STATUS: NOTHING OPERATES A. Check: Voltage to the unit, restore it if there is none. Compare to the nameplate. B. Check: The master switch, switch ON if off. C. Check: The 2 reset switches (circuit board and high pressure): depress and release each switch. - Page 27 If the bin empty light is still OFF, check the circuit board. 1. Unplug "opto trans" and "LED" connectors from the circuit board. 2. Plug "opto trans" and "LED" connectors from the Scotsman Electronic Control Testor Model NM1 into the circiut board (see page 38).
- Page 28 FM1500R SERVICE DIAGNOSIS: Condition - No Ice Being Produced STATUS: GEARMOTOR OPERATES, COMPRESSOR DOES NOT A. Check the pump down control switch. 1. This pressure switch opens at 6-10 psig, and closes at 16-20 psig. If open check the low side pressure, if after running the machine the switch opens at a pressure higher than 10 psig, replace the switch.
- Page 29 FM1500R SERVICE DIAGNOSIS: Condition - No Ice Being Produced STATUS: GEARMOTOR OPERATES, COMPRESSOR DOES NOT B. Check the compressor relay. The relay is on the circuit board, if it does not supply power to the liquid line valve coil, the low pressure control will not close, and the compressor will not run.
- Page 30 FM1500R SERVICE DIAGNOSIS: Condition - Low Ice Production I. STATUS: EVERYTHING IS OPERATING A. Check the condenser for dirt. Clean as required. Check the head pressure. If the head pressure is very high: 1. Check for high air temperatures, or restrictive air flow. Correct as needed.
-
Page 31: Removal And Replacement
FM1500R REMOVAL AND REPLACEMENT WATER RESERVOIR 1. Shut off the water supply to the icemaker. 2. Remove front panel and reservoir cover. 3. To remove float only, pry the mounting flanges apart enough to lift one float pivot pin out of the flange hole, and pull float up and out of the reservoir. -
Page 32: Bearing & Breaker
5. The breaker may be removed from the a. Add food grade grease such as Scotsman auger and evaporator without disturbing the part number 19-0569-01 to the seal area auger. -
Page 33: Auger
FM1500R REMOVAL AND REPLACEMENT: Auger ////// /////////////////////////WARNING//////////////////////// a. Use spanner wrench and unscrew stainless breaker cover from breaker (left Disconnect Electrical Power hand threads) ////////////////////////////////////////////////////////////////////////// b. Unscrew auger stud from top of auger. To Remove the Auger: c. Unscrew 4 allen head cap screws holding Turn off the water to the machine, and unclip breaker to evaporator. -
Page 34: Water Seal
At the thermostatic expansion valve outlet. 4. Place a small bead of food grade silastic sealant (such as 732 RTV or Scotsman part //////////////////////////////CAUTION/////////////////////////// number 19-0529-01) on the area of the auger Heat sink the TXV body when unsweating where the water seal is to be mounted. - Page 35 FM1500R REMOVAL AND REPLACEMENT: Evaporator To Reassemble the Evaporator and Auger REPLACING THE WATER SEAL 1. After the gearmotor has been inspected, fasten the evaporator to the gear motor, be sure that the number of shims indicated on the gear case cover is in place between the gearcase cover and the drip pan gasket.
-
Page 36: Gearmotor
FM1500R REMOVAL AND REPLACEMENT: Gearmotor To Remove and Repair the Gearmotor If there is evidence of water in the oil (rusty Assembly: bearings and gears; the oil having a creamy white appearance; oil level too high) carefully (Assuming that the procedures through inspect the bearings and gears. - Page 37 FM1500R REMOVAL AND REPLACEMENT: Gearmotor WATER SHED OUTPUT CENTRIFUGAL SWITCH SHAFT SEAL DRIVE MOTOR GEARCASE COVER, OUTPUT SHAFT, OUTPUT GEAR, AND BEARINGS MOTOR BEARING SHAFT SEAL 1ST GEAR AND BEARINGS 2ND GEAR AND BEARINGS GASKET GEARCASE November, 1988 Page 37...
-
Page 38: Circuit Board Testing
FM1500R Circuit Board Testing ///////////////////////////////////////////////////////////////////////WARNING////////////////////////////////////////////////////////////////// These procedures require the machine to be connected to the power supply. The voltages of the electronic circuit are very low, but HIGHER VOLTAGES ARE PRESENT IN THE UNIT. Do not touch anything but the tester while the unit is being checked out. Make all connections to the circuit board with the ELECTRICAL POWER OFF. - Page 39 OFF. If not replace the circuit board. board. If the light does go off, replace the 2. Plug “water sen” connector from Scotsman water level sensor. tester into circuit board. If the Bin Empty light is ON, wait 10-20 a.
