Thomasville Summer Silhouette 12256-002 Assembly Instructions

Chaise lounge

Advertisement

Page 1 of 4
Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts that may have come
loose inside the carton during shipment. Please read all instructions carefully before starting the assembly process.
CAUTION: Some items and/or the components are cumbersome and heavy. Therefore, the assistance of one or more people
is recommended in order to prevent personal injury and insure that the item and/or its components are not damaged during the
assembly process. Perform all assembly steps on a flat, soft, non-abrasive surface to avoid scratching the finish. Do not over-
tighten the screws or bolts.
No.
A
Left Arm
B
Right Arm
C
Seat Frame
D
Front Legs
E
Back Frame
F
Long Screws (M6x25)
G
Short Screws (M6x20)
Summer Silhouette
Hardware & Parts List
Description
! KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE !
Chaise Lounge
TM
Model # 12256-002/012
Qty
1
1
1
2
1
8
8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Summer Silhouette 12256-002 and is the answer not in the manual?

Questions and answers

Summary of Contents for Thomasville Summer Silhouette 12256-002

  • Page 1 Page 1 of 4 Assembly Instructions Summer Silhouette Chaise Lounge Model # 12256-002/012 Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts that may have come loose inside the carton during shipment. Please read all instructions carefully before starting the assembly process. CAUTION: Some items and/or the components are cumbersome and heavy.
  • Page 2 Page 2 of 4 Assembly Instructions Summer Silhouette Chaise Lounge Model # 12256-002/012 Hardware & Parts List (Cont.) Description Picture Washers (M6) Screw Covers (M6) Bolts (M8x55) Washers (M8) Plastic Washers (M8) Wheels Plastic Bushings Big Washers Bolts (M8x25) Bolt Covers (M8) Seat Cushion Back Cushion Hex Key...
  • Page 3 Page 3 of 4 Assembly Instructions Summer Silhouette Chaise Lounge Model # 12256-002/012 1. Carefully place the seat frame upside down on a flat, soft non-abrasive surface. Align the holes on one of the front legs (D) with the holes in the corner of the seat frame. From inside the rim of the seat frame, attach the leg by inserting the short screws (G) with washers (H) through the seat frame into the holes in the leg.
  • Page 4 Page 4 of 4 Assembly Instructions Summer Silhouette Chaise Lounge Model # 12256-002/012 2. Attach one wheel (M) to the right arm using a bolt (P), big washers (O), and two plastic bushings (N). Make sure that the parts are assembled in the correct order and that their orientation is as indicated in Figure 2.

This manual is also suitable for:

Summer silhouette 12256-012
