- Page 1 Liftlog 1000 Fork Lift Truck Weighing System Installation and Calibration User Guide Title...
- Page 2 Service and Technical Support PLEASE CONTACT YOUR NEAREST DISTRIBUTOR or if unknown, contact the factory for further information. RDS Technology Ltd, Cirencester Road, Minchinhampton, Stroud, Glos, GL6 9BH, United Kingdom Ph: +44 (0)1453 733300 : Fax: +44 (0) 1453 733311 : EMAIL: info@rdstec.com Our policy is one of continuous improvement and the information in this document is subject to change without notice.
- Page 3 LIFTLOG 1000 – INSTALLATION AND CALIBRATION Information on Disposal for Users of Waste Electrical & Electronic Equipment This symbol on the product(s) and / or accompanying documents means that the electronic component(s) of this product should not be mixed with general household waste at end of life.
-
Page 4: Table Of Contents
LIFTLOG 1000 – INSTALLATION AND CALIBRATION INTRODUCTION Important Information Important Safety Precautions ! System Overview Parts List : Ref. Kit P/LIFTLOG/1000 Hydraulic Fitting Kits (standard unless otherwise specified) Hydraulic Fitting Kits (options) INSTALLATION Drop Valve / Pressure Sensor 2.1.1 Flow Rate Adjustment................................14 Reference Sensor 2.2.1... - Page 5 LIFTLOG 1000 – INSTALLATION AND CALIBRATION CALIBRATION Setup Menu “Full Setup Wizard” Technician Level Settings 3.3.1 Home Screen Functions ................................24 3.3.2 Logging Options ..................................24 3.3.3 Port Setup ....................................27 3.3.4 Language / Keyboard region ..............................27 3.3.5 Instrument ID .................................... 27 3.3.6...
-
Page 6: Introduction
RDS Service and Support Department at the factory. RDS Technology Ltd does not accept responsibility for faulty operation of the system or consequential damage, as a result of poor workmanship of installation, or any aspect of component installation that does not comply with the requirements for correct operation as stated in this manual. -
Page 7: System Overview
System Overview The Liftlog 1000 is a weighing system designed for use principally on counterbalance fork lift trucks. It measures, displays and records the net or gross weight lifted, normally based on sensing the lift system hydraulic pressure. Normally, a weighing start point is established by use of a magnetic Reference position sensor fitted on the lift mast. -
Page 8: Parts List : Ref. Kit P/Liftlog/1000
LIFTLOG 1000 – INSTALLATION AND CALIBRATION Parts List : Ref. Kit P/LIFTLOG/1000 Item Part No. Description Standard K/DROP/VALVE Kit - Drop Valve K/G-CAN/SCR/PRT Kit - Touchscreen Protection K/INSTRUMENT Kit - Power Supply K/LIFTLOG/REF Kit - Reference Sensor K/LOAD/COMP/250 Kit - 250 bar Pressure Sensor K/RAM/MOUNT/KIT Kit - “RAM”... -
Page 9: Hydraulic Fitting Kits (Standard Unless Otherwise Specified)
LIFTLOG 1000 – INSTALLATION AND CALIBRATION Hydraulic Fitting Kits (standard unless otherwise specified) Unless specified otherwise, the following kits are supplied as standard with the main kit (ref. fig.1 overleaf) Item Part No. Description Pressure Circuit (Cylinder Return circuit – Feed to Drop Valve) K/VHL/INST/053 3/8”... - Page 10 LIFTLOG 1000 – INSTALLATION AND CALIBRATION Fig 1: Hydraulic Components Fit as required for either LP Tank Return ‘P’ or ‘T’ ports Lift Cylinder return line...
-
Page 11: Hydraulic Fitting Kits (Options)
LIFTLOG 1000 – INSTALLATION AND CALIBRATION Hydraulic Fitting Kits (options) Pressure Circuit (Cylinder Return circuit – Feed to Drop Valve) The correct tee fitting kit should have been specified and supplied for the particular machine. Unless otherwise specified, the system is supplied with kit K/VHL/INST/005 to drill and tap a 1/8” BSP port at a suitable point in the lift cylinder return circuit. -
Page 12: Installation
LIFTLOG 1000 – INSTALLATION AND CALIBRATION Installation Drop Valve / Pressure Sensor Before mounting the valve, fit the pressure sensor to the valve body using the ¼” “Dowty” seal washer supplied. Solenoid 4-20mA Pressure Sensor Wherever possible, choose a mounting position where it will be afforded the best protection from the elements. - Page 13 LIFTLOG 1000 – INSTALLATION AND CALIBRATION Typical Drop Valve installation Drop valve Tee - lift cylinder return line to pressure port 'P' Tee - return port 'T' to tank return line...
-
Page 14: Flow Rate Adjustment
LIFTLOG 1000 – INSTALLATION AND CALIBRATION Route the pressure sensor lead and solenoid lead back to the Terminator. Cable tie at regular intervals following the existing wiring loom where possible. Ref. 2.4.4 for wiring connections. 2.1.1 Flow Rate Adjustment The drop rate may need to be adjusted depending on the particular machine. With the solenoid connected and the head unit powered up, press the weigh button to energize the solenoid and observe the rate of drop. -
Page 15: Reference Sensor
LIFTLOG 1000 – INSTALLATION AND CALIBRATION Reference Sensor The Reference sensor kit automatically enables the weigh button when the load reaches the weighing position. Assemble the sensor to the bracket allowing it to project at least 15mm from the face of the bracket. -
Page 16: Weighing Height Without Reference Sensor
LIFTLOG 1000 – INSTALLATION AND CALIBRATION Cable-tie the sensor lead to the bracket where shown. Connect the sensor extension lead and route in conduit back to the Terminator. Cable tie at regular intervals and following the existing wiring loom where possible. -
Page 17: Head Unit
LIFTLOG 1000 – INSTALLATION AND CALIBRATION Head Unit Mount the head to the front panel with the RAM mount as shown. NOTE: The head unit can also be mounted off the ROPS pillar using a “U” Clamp kit (optional The head unit is dust-tight and splash-resistant, however it is not rated for constant outdoor use. -
Page 18: Electrical
LIFTLOG 1000 – INSTALLATION AND CALIBRATION Electrical 2.4.1 Junction Box The Junction Box or "Terminator" as it is also known, provides for connecting the 18-core head unit cable, all sensors and the power supply. The Terminator is not sealed. It must be located where it will be protected from EXCESSIVE MOISTURE AND DIRT Cable-tie the cables entering the end of the box to the PCB. -
Page 19: Power Supply
LIFTLOG 1000 – INSTALLATION AND CALIBRATION 2.4.2 Power Supply NOTE: The Weightroller Precise operates from an 8 to 30VDC supply, however the solenoid on the drop valve is 12V. Therefore a suitable voltage dropper must be fitted on vehicles using supply voltages above 12V. -
Page 20: Electrical Connections
LIFTLOG 1000 – INSTALLATION AND CALIBRATION 2.4.4 Electrical Connections Route sensor leads inside conduit back to the junction box. Cable-tie the conduit securely to existing hydraulic lines or conduits. Connect the wires according to the label on the junction box lid :... -
Page 21: Diagnostics
LIFTLOG 1000 – INSTALLATION AND CALIBRATION Diagnostics Press and select the “Diagnostics” screen from the “P1” = Pressure Sensor output in mA and Setup menu corresponding pressure (1 bar = 14.9psi) The diagnostics screens provide a visual indication of the system inputs and status. -
Page 22: Calibration
LIFTLOG 1000 – INSTALLATION AND CALIBRATION Calibration Setup Menu Press to access the Setup menu. There are three calibration levels. Operator Units Ref. Op. Manual Time and Date “ Brightness “ Volume “ Calculator “ Nudge “ Diagnostics Press and enter PIN (default = 4084) to access Technician Level UK796-300.JPG... -
Page 23: Full Setup Wizard
LIFTLOG 1000 – INSTALLATION AND CALIBRATION Press and enter PIN (default = 4084) to access Factory Level. Factory Full Setup Wizard Calibration 3.4.1 Sensor Setup 3.4.4 Overload 3.4.5 Error Log 3.4.6 3.4.7 Software Reset 3.4.8 UK796-320.JPG “Full Setup Wizard” The “Full Setup Wizard” routine appears if the instrument is being setup for the first time, e.g. on installation, or if the software has been updated. -
Page 24: Technician Level Settings
LIFTLOG 1000 – INSTALLATION AND CALIBRATION Technician Level Settings Select then to access the Technician Level Menu (default PIN = 4084). 3.3.1 Home Screen Functions Select the functions that you wish to appear on the main operating screen. UK796-330.JPG 3.3.2 Logging Options Setup for logging output to any of the following: ... - Page 25 LIFTLOG 1000 – INSTALLATION AND CALIBRATION Printing Printer COM Port ---- Printing deactivated COM 1 Select the Com Port to which the printer is connected. If connecting a printer other than an RDS "ICP300" printer, check the COM 2 settings in "Port Setup" match the printer specification.
- Page 26 LIFTLOG 1000 – INSTALLATION AND CALIBRATION Output to Data Logging device Data COM Port ---- COM port deactivated – no data output. COM 1 Select the Com Port to which the datalogger is connected. Check the settings in "Port Setup" match those required by the COM 2 datalogging device.
-
Page 27: Port Setup
LIFTLOG 1000 – INSTALLATION AND CALIBRATION 3.3.3 Port Setup Press to edit RS232 Port settings. The default settings are suitable for the RDS "ICP300" printer. The default settings for "COM 1" and "COM 2" are: Status: Enabled / Disabled Baud Rate:... -
Page 28: Job No. / Ticket No
LIFTLOG 1000 – INSTALLATION AND CALIBRATION 3.3.6 Job No. / Ticket No. Edit the Job No. (the number incrementing with each load cleared). The instrument will then increment from that number until it is edited again. Edit the Ticket No. (the number incrementing with each printout made). The instrument will then increment from that number until it is edited again. -
Page 29: Load From Usb
LIFTLOG 1000 – INSTALLATION AND CALIBRATION “All text” This saves the Store descriptions, Store references for all Stores and the “Instrument ID” text. This file does not include calibration settings. The default file name is "Strings.txt". Press and rename the file if desired. Press "Ent" on the screen keyboard to download the data (or "Esc"... -
Page 30: Overload Log
LIFTLOG 1000 – INSTALLATION AND CALIBRATION Load Calibration Settings only Calibration settings are contained in a .HEX file with the default name "Al10Nvm.HEX". These settings include calibration settings, Sensor setup and most user settings made in the 'Setup' menu. NOTE: Calibration settings do not include store names, store references and “Instrument ID”, which can be uploaded separately from... -
Page 31: Factory Level Settings
LIFTLOG 1000 – INSTALLATION AND CALIBRATION Factory Level Settings Select then to access the Factory Level Menu (default PIN = 4084). 3.4.1 ‘Auto’ Weight Calibration 1. From the “Calibration“ screen, select ‘Auto’ and press 2. Zero weigh – Lift the empty forks to the weighing position and press The zero point is calculated and displayed as a % of maximum pressure. -
Page 32: Calibration Factors
LIFTLOG 1000 – INSTALLATION AND CALIBRATION 3.4.2 Calibration Factors 1. From the “Calibration“ screen, select ‘Manual’ and press ‘Zero’ This value is the % of full pressure at zero weight. ‘Cal Factor’ This value enables the calculation of weight from the % pressure. -
Page 33: Sensor Setup
LIFTLOG 1000 – INSTALLATION AND CALIBRATION “Correct from Weight” - “Wf” on graph. “Correct to Weight” - “Wt” on graph. The range over which the correction factor is applied. “% Correction” - Correction applied between 'Wf' and 'Wt' on graph. -
Page 34: Overload Alarm Setup
LIFTLOG 1000 – INSTALLATION AND CALIBRATION “Secure >0< Key” If enabled, PIN entry is required to access the zero routine on the main operating screen (the PIN is the current factory level PIN as displayed on the “PIN” screen). “Enable Nudge”... -
Page 35: Error Log
LIFTLOG 1000 – INSTALLATION AND CALIBRATION 3.4.6 Error Log Logs the time and date of all error faults e.g. “P1” pressure sensor. This information can be cleared, printed, or saved to SD card / USB stick. 3.4.7 PIN You can change the factory default “Technician” menu PIN , and the “Factory” menu PIN. - Page 36 LIFTLOG 1000 – INSTALLATION AND CALIBRATION Issue Ref. Date Description 4.8.15 Original issue 29.9.15 Ref. CRQ 6658...
