Summary of Contents for Aircraft AIRBOY 186 OF E
- Page 1 Operating Instructions Mobile Compressor AIRBOY 186 OF E AIRBOY 206 OF E AIRBOY 186 OF E AIRBOY 206 OF E...
-
Page 2: Table Of Contents
Indications regarding the operating instructions 10.1 Ordering spare parts ........14 10.2 Spare parts drawing ........15 Copyright © 2019 AIRCRAFT Kompressorenbau und 11 EC-Declaration of Conformity ......17 Maschinenhandel GmbH, Hohenzell, Austria. The contents of these operating instructions is the sole property of the company AIRCRAFT Kompressorenbau und Maschinenhandel GmbH. -
Page 3: Introduction
Introduction Germany: Stürmer Maschinen GmbH Dr.-Robert-Pfleger-Str. 26 You have made a good choice by purchasing the com- D-96103 Hallstadt pressor made by AIRCRAFT. Repair service: Fax: 0049 (0) 951 96555-111 Please thoroughly read the operating instructions befor com- E-Mail: service@stuermer-maschinen.de missioning. -
Page 4: Symbol Explanations
Safety 2.1 Symbol explanations 2.2 Operator responsibility Safety instructions Operator The safety notes in these operating instructions are Operators are defined as the persons who operate the highlighted by symbols. The safety notes are introduced machine for commercial or profit-based purposes or by signal words which exoress the concern of the risk. -
Page 5: Operating Staff Qualification
Safety 2.3 Operating staff qualification 2.4 Personal protective equipment Personal protective equipment is intended to protect the Qualifications health and safety of persons at work. Staff must wear the personal protective equipment indicated in individual The different tasks described in these operating instruc- sections of these operating instructions when carrying tions require different levels of skills in terms of the qual- out the different tasks on the machine. -
Page 6: Verification Of Operational Safety
Safety Check Inspection periods Inspection organisa- CAUTION! RISK OF INJURY tion Strength test** Once every 10 Qualified person - Never direct compressed air to persons or animals. years - Grab the end of the compressed air hose with your PS x V </=1000 hand before opening the quick coupling in order to *Once every 10 Approved inspec-... -
Page 7: Safety Marking On The Compressor
Intended use above 50% of its capacity, and not to have it run in con- 2.7 Safety marking on the compressor tinuous operation for more than 15 minutes. The following safety symbols are attached to the com- Furthermore, many accessories can be connected to pressor: the compressor beyond pneumatic tools, which can be used for blowing, washing and spray-painting. -
Page 8: Residual Risks
Check whether the compressor is complete and whether all parts included in the scope of delivery are Technical data present. AIRBOY 186 OF E AIRBOY 206 OF E Transport Maximum volume 180 l/min 180 l/min... -
Page 9: Description Of The Device
Before commissioning, the following must be obser- ved. - The mains voltage must correspond to the voltage Fig. 3: AIRBOY 186 OF E (above) and AIRBOY 206 OF E (below) specifications on the rating plate. 1 Safety valve - The ON / OFF switch must be in the OFF position. -
Page 10: Assembly And Installation
Operation 7.1 Assembly and installation NOTE! Mount the suction cups as shown in fig. 4. The compressor is designed for interval operation. For trouble-free operation, the duty cycle S3-25 must not be exceeded. If you e.g. 10 min. paint, the com- pressor must not last longer than 2.5 min. -
Page 11: Switch On
Maintenance, care and servicing/ repair 7.2 Switch on ATTENTION! Step 1: Check whether the mains voltage corre- If the condensation is not drained, the tank can cor- sponds to the voltage indicated on the name- rode. This limits its capacity and compromises plate. -
Page 12: Maintenance
Maintenance, care and servicing/ repair Step 1: Before performing any maintenance, turn off 8.2 Maintenance the compressor, disconnect the power plug, and drain all air from the reservoir. DANGER! Daily: All work on electrical and pneumatic systems may Step 2: Before starting work, check the compressed only be carried out by qualified personnel who have air lines for damage and replace them if... -
Page 13: Function Test Of The Safety Valve
Maintenance, care and servicing/ repair The company AIRCRAFT Kompressoren does not take 8.3 Function test of the safety valve responsibility nor does it guarantee for damages and failures resulting of non-observance of this operating Monthly check of the safety valve manual. -
Page 14: Disposal, Recycling Of Used Devices
No. and year of construction on the type plate which is fixed on the compressor. 10 Spare parts Example The Safety valve for the compressor AIRBOY 186 OF E DANGER! must be ordered. The Safety valve has the number 110 Risk of injury due to the use in the spare parts drawing 1. -
Page 15: Spare Parts Drawing
Spare parts drawing AIRBOY 186 OF E Fig. 7: Spare parts drawing AIRBOY 186 OF E Spare parts drawing AIRBOY 206 OF E Fig. 8: Spare parts drawing AIRBOY 206 OF E... - Page 16 Spare parts Spare parts drawing compressor AIRBOY 186 OF E and AIRBOY 206 OF E Fig. 9: AIRBOY 186 OF E and AIRBOY 206 OF E AIRBOY | Version 1.07...
-
Page 17: Ec-Declaration Of Conformity
EC-Declaration of Conformity 11 EC-Declaration of Conformity According to Machinery Directive 2006/42/EG attachment II 1.A AIRCRAFT Kompressorenbau und Maschinenhandel GmbH Manufacturer/distributing company: Gewerbestraße Ost 6 A-4921 Hohenzell herewith declares that the following product AIRCRAFT® Compressed air technology Product group: Piston compressor... - Page 18 www.aircraft.at...
