1. Lay the shelf as shown in the picture on
right. Remove the six nuts from inside the
Shelf Platform (red arrows).
2. Attach the Left and Right Support Brackets, and fasten
the nuts back on. Make sure the brackets are oriented
correctly.
3. Using a screw driver, remove the screws (red arrows
from the Support Post.
4. Secure the Triangular Back Brace to the support
post so the outside corners face away from the
leveling mount. Replace the screws.
A01 Cubetainer Shelf Installation
A2000/A2000I
2052 O'Neil Rd Macedon, NY 14502 PH: (315) 986-8090 FAX: (315) 986-809
service@ankom.com
AS024
Service Procedure
Rev. B Date: 09/13/2017
6/25/19
C
Advertisement
Table of Contents
Summary of Contents for Ankom A01
- Page 1 AS024 A01 Cubetainer Shelf Installation Service Procedure Rev. B Date: 09/13/2017 6/25/19 A2000/A2000I 1. Lay the shelf as shown in the picture on right. Remove the six nuts from inside the Shelf Platform (red arrows). 2. Attach the Left and Right Support Brackets, and fasten the nuts back on.
- Page 2 AS024 A01 Cubetainer Shelf Installation Service Procedure Rev. B Date: 09/13/2017 6/25/19 A2000/A2000I 5. With the inside facing up, attach the Support Post into the center of the Shelf Platform (red arrows). 6. Remove six nuts from the back of the A2000 (red arrows).
