Summary of Contents for dentalfarm CF-2
- Page 1 FUME EXHAUST FAN FOR BURN-OUT FURNACES MOD. CF-2...
- Page 2 INSTALLATION 1. Insert the horizontal pipe on the manifold protruding from the rear wall of the furnace and fix in place by means of the four self-threading screws previously uloosened (use a cross-section screwdriver). 2. Connect the plug of the feeding cable to the socket at the bottom of the furnace, thus allowing the software system to start or stop automatically according to the preset temperatures.
- Page 3 EXPLODED DRAWING AND SPARE PART LIST ITEM DESCRIPTION 1211001 Exhaust pipe 1211002 Connection plate 1211003 Centrifugal fan 1211004 Cable with socket...
- Page 4 WIRING DIAGRAM POS. DESCRIZIONE Cable with socket Motor DENTALFARM s.r.l. Via Susa, 9/a - 10138 TORINO - ITALY TECHNICAL-COMMERCIAL SERVICE - (+39) 011/4346588 AFTER-SALE ASSISTANCE - (+39) 011/4346632 FAX 011/ 4346366 – Email: info@dentalfarm.it Website: www.dentalfarm.it...
