HT904WA-AMP_DKENHL_ENG_0783
Model : HT934WA (HT934WA-AMP, SH94WA-F/L/R/C/W)
Full HD up-scaling (1080p)
(Go to page 7)
USB Direct Recording
(Go to page 19)
iPod is a trademark of Apple Inc., registered in the U.S. and other countries.
As an E
S
NERGY
TAR
®
LG has determined that this
product or product models meet
the E
S
®
guidelines for
NERGY
TAR
energy efficiency.
E
S
®
is a U.S. registered mark.
NERGY
TAR
P/NO : MFL60020783
3/20/09
6:24 PM
Page 1
HDMI In
(Go to page 8)
Made for iPod
(Go to page 20)
Partner,
Home theater Speaker ez Set-up
(Go to page 17)
Portable In
(Go to page 21)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HT934WA and is the answer not in the manual?

Questions and answers

Related Manuals for LG HT934WA

Summary of Contents for LG HT934WA

  • Page 1 HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 1 Model : HT934WA (HT934WA-AMP, SH94WA-F/L/R/C/W) Full HD up-scaling (1080p) HDMI In Home theater Speaker ez Set-up (Go to page 7) (Go to page 8) (Go to page 17) USB Direct Recording Made for iPod...
  • Page 2 European representative : CAUTION : This product employs a Laser System. LG Electronics Service Europe B.V. Veluwezoom 15, 1327 AE Almere, The Netherlands To ensure proper use of this product, please read this owner’s (Tel : +31-036-547-8940) manual carefully and retain it for future reference.

  • Page 3: Table Of Contents

    Area Codes ........22 • Controllable functions by LG TV’s remote control; Play, Pause, Scan, Skip, Stop, Power Off, etc.

  • Page 4: Setting Up

    HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 4 Setting up Connect the wires to the DVD receiver. Match each wire’s coloured band to the same coloured connection terminal on the rear of the DVD receiver. To connect the cable to the DVD The speakers are detached from the speaker stands.

  • Page 5: Initial Setting An Id Of Wireless System

    HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 5 LED indicator of Wireless speakers Initial setting an ID of Blue : The Wireless speakers are receiving the signal of the unit. Wireless system Off (No display) : The Wireless Receiver is switched to standby mode or the power cord of Wireless speaker is not conneced.

  • Page 6: Hooking Up The Unit

    HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 6 Hooking up the unit a Connect jacks on the unit and your TV (DVD player or Digital Device etc.) using the cables. Check the jacks of your TV, and choose the A, B or C connection. Picture quality improves in order from A to C. Component Video connection ( Connect the COMPONENT VIDEO (PROGRESSIVE...
  • Page 7 HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 7 Hooking up the unit Available resolution according to connection Displayed resolution in display window and outputted resolution may different Resolution Setting according to connection type. You can change the resolution for component video and HDMI output. [HDMI OUT]: 1080p, 1080i, 720p and 480p (or 576p) and 480i (or 576i) Press RESOLUTION repeatedly to select the desired resolution - 480i (or 576i), [COMPONENT VIDEO OUT]: 480p (or 576p) and 480i (or 576i)
  • Page 8 HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 8 Hooking up the unit Audio In connection The unit’s Audio jacks are colour coded (red for right audio and white for left audio). If your TV has only one output for audio (mono), connect it to the left (white) audio jack on the unit.

  • Page 9: Main Unit

    HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 9 Main Unit 1 Power (1 1 /` ` ) 3 4 5 Turns the unit on and off. 2 DVD/CD Disc Drawer 3 Open/Close (Z Z ) 4 Play/Pause(B B /X X ) 5 Stop (x x ) 6 TUNING (-/+) (.

  • Page 10: Remote Control

    ) : Selects programme of Radio. TUN. (-/+) : Tunes in the desired radio station. U U u u I I i i TV Control buttons : Controls the TV. (LG TV only) (up/ down/ left/ right) : Used to navigate on- screen displays.

  • Page 11: Osd Initial Language Settings - Optional

    HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 11 OSD Initial language settings - Optional Adjusting the general settings During the first use of this unit, the initial language setup menu ON REMOTE appears on your TV screen. You must complete initial language 1 Display setup menu : SETUP selection before using the unit.

  • Page 12: 5.1 Speaker Setup

    HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 12 Adjusting the display settings 5.1 Speaker Setup TV Aspect – Select which screen aspect to use based on the shape of your TV screen. ON REMOTE [4:3] : Select when a standard 4:3 TV is connected. 1 Open the settings menu: SETUP [16:9] : Select when a 16:9 wide TV is connected.

  • Page 13: Enjoying A Preprogrammed Sound Field

    HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 13 Adjusting the lock settings Enjoying a pre-programmed sound field To access the lock options, you must enter the 4-digit password. If you have not yet entered a password you are prompted to do so. Enter a 4-digit password This system has a number of pre-set surround sound fields.

  • Page 14: Displaying Disc Information

    HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 14 Displaying Disc Information Playing a Disc or file ON REMOTE ON REMOTE Z Z OPEN/CLOSE 1 Press DISPLAY : 1 Insert a disc on unit : DISPLAY 2 Select a DVD/CD : FUNCTION 2 Select an item : U U u u U U u u I I i i I I i i...
  • Page 15 HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 15 Fast forward or fast reverse Viewing the DVD MENU Press MENU to display the disc menu, if available. Press SCAN (m or M) to play fast forward or fast reverse during playback. You can change the playback speed by pressing SCAN (m or M) Changing the character set to display DivX ®...

  • Page 16: Viewing Photo Files

    HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 16 Creating your own program Viewing photo files You can play the contents of a disc in the order you want by arranging the order of the musics on the disc. To add a music(s) on the program list, press ON REMOTE PROG/MEMO to enter the program edit mode ( mark appears on the menu).

  • Page 17: Listening To The Radio

    HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 17 Home theater Speaker ez Set-up Listening to the radio Be sure that both FM and AM aerials are connected. Listen to sound from TV, DVD and Digital Device with 5.1(2.1 or 2)ch mode. Even in power off mode, if you press TVtHT SPK, then power is ON REMOTE on and automatically changed to AUX OPT mode.

  • Page 18: Using An Usb Device

    HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 18 Compatible USB Devices Using an USB device • MP3 Player : Flash type MP3 player. • USB Flash Drive : Devices that support USB2.0 or USB1.1. You can enjoy media files saved on an USB device by connecting the •...

  • Page 19: Recording To Usb

    HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 19 When you are recording, look out for the following Recording to USB • You can check the recording percentage rate for the USB record on the ON REMOTE screen during the recording.(AUDIO CD or MP3/ WMA CD only) •...

  • Page 20: Playing The Ipod

    HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 20 Playing the iPod - more you can do Playing the iPod Pauseing playback For detial refer to iPod guide. iPod mode: You can operate your iPod by using the supplied remote Press PAUSE/STEP (X X ) or PLAY (B B ) to pause playback. Press PAUSE/STEP control and directly control on your iPod.

  • Page 21: Listening To Music From Your Portable Player Or External Device

    HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 21 Other operations Listening to music from your portable player or external device Fall asleep while listening to your player Press SLEEP one or more times to select delay time between 10 and 180 The unit can be used to play the music from many types of portable player or minutes, after the player will turn off.

  • Page 22: Language Codes

    HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 22 Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Language Code Language Code Language Code Language Code Language Code Language Code Afar 6565 Croatian 7282...

  • Page 23: Troubleshooting

    HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 23 Troubleshooting PROBLEM CAUSE CORRECTION No power Plug the power cord into the wall outlet securely. The power cord is disconnected. No picture Select the appropriate video input mode on the TV so the The TV is not set to receive the DVD signal. picture from the DVD Receiver appears on the TV screen.

  • Page 24: Types Of Playable Discs

    LG players when formatting rewritable discs. When setting Manufactured under license under U.S. Patent #’s: 5,451,942; 5,956,674; the option to Live File System, you cannot use it on LG players. 5,974,380; 5,978,762; 6,487,535 & other U.S. and worldwide patents issued &...

  • Page 25: Specifications

    HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 25 Specifications Specifications General Speakers Power supply Refer to main label Front Rear Power consumption Refer to main label Speaker speaker Net Weight 3.9 kg External dimensions (W x H x D) 430 x 73 x 327 mm Type 2 Way 3 Speaker 2 Way 3 Speaker...
  • Page 26 HT904WA-AMP_DKENHL_ENG_0783 3/20/09 6:24 PM Page 26...
