Summary of Contents for Sunquest SQ-2220-ID
- Page 1 Model # SQ-2220-ID INSTALLATION & OPERATION MANUAL Read all the instructions before installing your solar heating system.
- Page 2 How does a solar heating system work? 1. Connect your existing pool pump to the solar panel. Your pool pump sends cold water to the solar panel. 2. The sun heats the water in the solar panel. 3. Warm water is then returned to your swimming pool. How well does solar heating work? A solar heating system if sized and installed properly will raise your pool water temperature up to 10...
-
Page 3: Box Contents
Box Contents: Part # Description Part # Description SK-1220 SunQuest solar panel 2ft x 20ft SK-FTG-D Threaded combination hose adapter SK-FTG-I "O" rings SK-FTG-F Threaded cap SK-FTG-J Rubber hose 7.5" SK-FTG-L Metal collar (Hose clamp) SK-FTG-E Roll of Teflon tape... -
Page 4: Installation
Reducer Adapter 1.5" to 0.75" Diverter Kit (SQ-DK) System Kit (SQ-SK) A diverter kit is already included with your SunQuest System Everything needed to connect 3 SQ-2220 systems This kit in not necessary. Includes add-on kits, vacuum relief kit, high wind kits & diverter kit... -
Page 5: Panel Assembly
PANEL ASSEMBLY 1. Choose placement for your solar panel(s). Make sure that it will be in the sun for most of the day. The area should be clear of sharp objects. Take the panel out of the box, remove the strap from panel and let the panel sit in the sun for approximately 30 minutes so it will become flexible. - Page 6 b) Installation: one system on rack or roof. (Horizontal only) 1 - Mounting kit (part # SQ-RMK5) is required A Minimum of 2 inch fall per 10 feet Outlet Inlet Diagram Step 3b The integrated by-pass valve (SK-INT-V needs to be accessible in order to turn the •...
- Page 7 3. c) Installation: two systems on ground. Add-on kit (part # SQ-ADDON) is required. Outlet Inlet Diagram Step 3c Using a utility knife or a hand saw, cut both rubber hose (SK-FTG-J ) in half. Make sure you cut it as straight •...
- Page 8 d) Installation: two systems on rack or roof. (Horizontal only) 2 Mounting kit (part # SQ-RMK5) are required. 1 System kit (part # SQ-SK) is required. A Minimum of 2 inch fall per 10 feet Outlet Inlet Diagram Step 3d The integrated by-pass valve (SK-INT-V needs to be accessible in order to turn the solar heating system On •...
- Page 9 d) Cont. Apply Teflon on reducer adapter (SK-FTG-M) included in the system kit (SQ-SK) sold • separately. Thread reducer adapter into the panel as per diagram Step 3d. Do not over tighten. See Fig 3d-3. Apply Teflon on vacuum relief valve (SK-VRV). Thread vacuum relief valve into •...
-
Page 10: Swimming Pool
CONNECTING TO POOL System with integrated diverter To Panel From Panel Inlet Outlet Filter Pump Pool Outlet Pool Inlet Swimming Pool Diagram C-1 1. Turn off your pool pump. Block the inlet and outlet of your pool so that the water won't empty when you are connecting your panel(s). - Page 11 System with diverter near pump To Panel From Panel Inlet Outlet Diverter Kit Filter Pump Pool Outlet Pool Inlet Swimming Pool Diagram C-2 1. Assemble a diverter kit by installing the integrated by-pass valve (SK-INT-V) as shown in Diagram C-2 and Fig C2-1. (Tees and adapters not supplied) 2.
- Page 12 System with system kit (part # SQ-SK) To Panel From Panel Inlet Outlet Three Way PVC Tee Valve Filter Pump Pool Outlet Pool Inlet Swimming Pool Diagram C-3 1. Turn off your pool pump. Block the inlet and outlet of your pool so that the water won't empty when you are connecting your panel(s).
-
Page 13: Operation And Maintenance
Once completely drained, the panels can be left on the roof or rack. The SunQuest panels are designed to withstand the harshest winters. -
Page 14: Warranty Registration
SunQuest Solar Panel Five Year Limited Warranty Five year limited warranty from date of purchase with one full year. After the first year, the claimant shall pay the list price at the date of the claim less one-sixtieth ( 1/60 ) of the price for each full month remaining in the warranty period. Sunsolar Energy Technologies Inc. warrants to the...
