Breas iSleep HA 20 Quick Start Manual

HA 20 – Heated Humidifier
The HA 20* is an integrated heated humidifier,
especially designed for use with the iSleep* and
Vivo* 30/40 devices. To meet increasing demands of
customers regarding comfort and security, the HA 20
has now been further enhanced.
The HA 20 is truly integrated with the iSleep and Vivo 30/40 devices,
both in design and function. When connected to an iSleep or Vivo
30/40 device, all HA 20 operations are set and monitored through
the menu of the device. The HA 20 consists of a heating unit and a
separate water chamber. The water chamber is easy to connect and
to remove through the quick-release handle. No separate power cords
are required because power is provided through the iSleep or Vivo
30/40 device.
What's new?
The current enhancements help further increase handling comfort and
reducing the risk of water entering the device.
1. A smart water trap has been inserted into the lid to reduce the risk
of water entering the device
2. A clear indication of the maximum water level has been added to
the container
3. A new filling hole is added to facilitate filling the HA 20.
4. A simple leaflet with instructions for use is provided in the HA 20
(remove before use).
Please remember to always remove the HA 20 from the device and use
the filling hole to fill it. Do not surpass the maximum indicated water
level and remove / empty the HA 20 before transporting the device.
Part numbers
The part numbers for the HA 20 have remained unchanged:
• 2220XX Complete HA 20 White (where XX is the country code)
• 2230XX Complete HA 20 Silver (where XX is the country code)
• 004861 Water chamber
• Heated humidification
• Accessory to iSleep and Vivo 30/40
• Activated and controlled through the iSleep and Vivo
30/40 device
The HA 20 is operated through
the iSleep/Vivo 30/40 device
• No separate power cable required
• Smart water trap
• Convenient filling hole and clear water indication
• Easy to connect and to remove
• Easy to clean
