Page 1
Go to the Sony Computing Support hardware specifications and preinstalled software information. For Sony software information, click Start and select Welcome to VAIO life. computer, and welcome to the online VAIO ® Web site to view the VAIO Computer Specifications, which list your computer's ®...
Page 2
Ergonomics and Caring for Your Computer This section provides information on how to safely use your Sony computer. Page 2...
Applying Ergonomics Your computer is a portable device and can be used in a variety of environments. Whenever possible, you should apply the following ergonomic considerations: Position of your computer — Place the computer directly in front of you as you work. Keep your forearms horizontal, with your wrists in a neutral, comfortable position while using the keyboard, touch pad, or external mouse.
If the computer is brought directly from a cold location to a warm one, moisture may condense inside your computer. In this case, allow at least one hour before turning on your computer. If any problems occur, unplug your computer, and contact your Sony Service Center. ...
Using Cables and Connections Use only specified peripheral equipment and interface cables. Do not use cut or damaged connection cables. If the telephone company makes a service call to your home or office and determines that your computer is responsible for a problem, the telephone company may bill you for the service call.
Cleaning Your Computer Clean the computer with a soft, dry cloth or a soft cloth lightly moistened with a mild detergent solution. Do not use any type of abrasive pad, scouring powder, or solvent such as alcohol or benzine, as these may damage the finish of your computer.
Handling the LCD Screen Direct sunlight can damage the LCD. Be careful when using the computer near a window. Do not scratch the LCD or exert pressure on it. This can cause a malfunction. Using the computer in low temperature conditions may produce a residual image on the screen. This is not a malfunction.
6 Battery indicator 12 Wireless switch Wireles s LA N and Bluetooth c apabilities are available on s elec ted models only. Front VAIO computer. Sony has combined leading-edge technology in audio, ® ® Hard disk drive indicator media indicator ®...
S1 and S2 programmable buttons Num lock indicator Caps lock indicator and manual eject hole Scroll lock indicator Speakers 10 Air vent Left Touch pad Optical drive Optical drive eject button Memory Stick media slot ® Page 9...
Page 10
Network (Ethernet) port 5 Modem jack PC Card slot Microphone jack 7 PC Card eject button Headphone jack Gently pull the protective tab away from the computer to find the Ethernet port and modem jack. Only connect 10BASE-T or 100BASE-TX cables to the other type of network cable or any telephone line to this port.
Page 11
i.LINK (IEEE 1394) S400 port ® USB 2.0 ports DC IN port Gently pull the protective tab away from the computer to find the i.LINK S400 and USB 2.0 ports. Back Battery connector Bottom Reset button Port replicator connector Air Vent Page 11...
About the Indicator Lights Indicator Function Power Turns on when the power to the computer is on, blinks in Standby mode, and turns off when the computer is in Hibernate mode or off. Battery Turns on when the computer is using battery power, blinks when the battery is running out of power, double-blinks when the battery is charging.
Page 14
Using S1 and S2 Buttons The S1 and S2 buttons are pre-programmable buttons that enable you to quickly enter a power saving mode, switch between displays, launch an application, alter the sound, or increase the screen's brightness. Page 14...
Page 15
About the S1 and S2 buttons The following information shows where the S1 and S2 buttons are located, and briefly describes their functionality. Page 15...
Page 16
Using the S1 and S2 buttons To assign a function to the button Click Start, and point to All Programs and then Sony Notebook Setup. From the Sony Notebook Setup submenu, click Sony Notebook Setup. Click to select the S Button tab.
Page 17
Using the Touch Pad Describing the Touch Pad A pointing device called a touch pad is located in front of the keyboard. You can point to, select, drag, and scroll objects on the screen using the built-in touch pad. Page 17...
Page 18
Using the Touch Pad Describing the Touch Pad A pointing device called a touch pad is located in front of the keyboard. You can point to, select, drag, and scroll objects on the screen using the built-in touch pad. Page 18...
Page 19
Locating and using the touch pad Locating the Touch Pad Touch Pad Action Description Sliding one finger Equivalent to using a mouse to place the pointer on an item. Tapping once Equivalent to pressing the left button once. Tapping twice Equivalent to pressing the left button twice.
Page 20
Customizing the touch pad Sony Notebook Setup lets you customize, enable, or disable the touch pad. Open the Mouse Properties dialog box to set your touch pad and mouse preferences, such as changing pointers, enabling or disabling the tapping feature, clicking both buttons simultaneously, and adjusting the touch pad speed.
Using Memory Stick Media Your VAIO computer is equipped with a Memory Stick media slot that supports certain types of Memory Stick media. ® ® ® Page 21...
Page 22
MagicGate Memory Stick media — Provides copyright protection with authentication and encryption, using Sony MagicGate technology. Authentication ensures that protected content is only transferred between compliant devices and media. Protected content can be recorded and transferred in an encrypted format to prevent unauthorized duplication or playback.
Page 23
Inserting Memory Stick media Before using Memory Stick media, back up important data. The media slot accommodates only one Memory Stick media at a ® time. To insert Memory Stick media Insert the Memory Stick media with the arrow facing up and toward the Memory Stick media slot. Do not insert more than one Memory Stick media into the Memory Stick media slot.
Page 24
From this window, you can choose to view, print, copy or organize your images or data stored on the Memory Stick media. If the Sony Memory Stick window does not appear when you insert your Memory Stick media, then follow these...
Page 25
Protecting data on Memory Stick media Some Memory Stick media are equipped with a write-protect tab ® information recorded on your Memory Stick media. When you slide the write-protect tab to the LOCK position, your Memory Stick media is write-protected. You cannot delete, copy, or save information on the media while the write-protect tab in the LOCK position.
Page 26
Formatting Memory Stick media Memory Stick media is formatted for immediate use when you purchase it. If you need to reformat Memory Stick media, use ® the Memory Stick Formatter that is provided with the media. For more information about using Memory Stick Formatter, refer to Formatter Help.
Page 27
Removing Memory Stick media If the Memory Stick media is removed prematurely, a blue screen with a message may appear prompting you to continue or ® exit. Reinsert the media into the slot and press Enter to continue. This enables the media to finish reading or writing data. To remove Memory Stick media Wait a minimum of 10 seconds after the Memory Stick media finishes reading or writing data before removing the media.
Page 28
Mice and Keyboards Using the Keyboard Although your computer's keyboard is very similar to a typewriter's keyboard, you can use the additional keys on the computer's keyboard to perform specific computer-related tasks. Page 28...
Page 29
Mice and Keyboards Using the Keyboard Although your computer's keyboard is very similar to a typewriter's keyboard, you can use the additional keys on the computer's keyboard to perform specific computer-related tasks. Page 29...
Page 30
Key descriptions Description Numeric keypad Contains the keys found on a typical calculator. Use the numeric keypad area to type numbers or to perform mathematical calculations, such as addition and subtraction. Numbers appear on the front beveled edge of the numeric keys.
Page 31
(Ctrl, Alt, Shift keys) Several keys are always used with at least one other key: Ctrl, Alt, and Shift. When held down with another key, the Ctrl (Control) and Alt (Alternate) keys offer another way to give commands. For example, in many programs, instead of choosing the Save command from a menu, you can hold down Ctrl and press S (referred to as Ctrl+S ).
Page 32
Combinations and functions with the Windows key Combination Function Displays the VAIO Help and Support Center window. +Tab Switches the selected button on the taskbar. Displays the desktop. Displays the Windows Explorer window. Displays the Search Results window, where you can find a file or folder. This is the equivalent of selecting Search from the Start menu.
Page 33
Combinations and functions with the Fn key Feature Function Fn+F2 Toggles the headphones and built-in speakers off and on. An on-screen display appears notifying you when a change occurs. Fn+F3 Decreases the speaker volume. An on-screen display appears notifying you when a change occurs. Fn+F4 Increases the speaker volume.
Page 34
Connecting a Mouse and Keyboard Your computer is compatible with many popular mice and keyboards. To function properly, the device you connect must be compatible with the Microsoft Windows operating system installed on your computer. For information about your ® ®...
Page 35
Connecting a mouse or keyboard Your computer can be on or off when connecting a universal serial bus (USB) mouse or keyboard. If you connect the mouse or keyboard when the computer is on, you may need to restart the computer for it to recognize the device. See do if the computer doesn't recognize the mouse? To connect a USB mouse or keyboard to your computer Plug the USB cable into the USB port...
Page 36
Disconnecting a mouse or keyboard You can disconnect a USB mouse or keyboard when the computer is on or off. Disconnecting the mouse or keyboard when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction. To disconnect a mouse or keyboard ...
Using the Multilingual User Interface Language Option (Microsoft Windows XP Professional only) After you have initially setup your new VAIO ® ® language displayed in Microsoft Windows ® option changes the text controlled by Windows XP Professional operating system. Menus, help files, and icons generated by Windows XP Professional are shown in your selected language.
Page 38
Changing Numbers, Currency, Time, and Date Formats You can change your operating system's number, currency, time, and date formats to coordinate with your chosen country or language settings. To change these formats Click Start on the Windows taskbar, and then click Control Panel. Click Date, Time, Language and Regional Options, and click Regional and Language Options.
Click << or >> to view the designs. Click Apply to select a design that appears in the center window. The UI Design Selector window design changes. The window design for your Sony software will match the UI Design Selector window. Click OK.
Powering Your Computer Your VAIO computer comes with a battery and an AC adapter. This chapter explains how to install and use these supplied ® accessories to power your computer. It also describes ways you can efficiently utilize the battery as a power source. Page 40...
Using AC Power The supplied battery is not charged when you receive your computer. To charge the battery and begin using the computer immediately, insert the battery into the computer and use the supplied AC adapter as a power source. The computer automatically charges the installed battery while it uses AC power.
Page 42
Connecting the AC adapter To connect the AC adapter Plug the AC adapter cable into the DC IN port. Connecting the AC Adapter to the Com puter Plug the power cord into the AC adapter and an AC outlet. Use only the supplied AC adapter with your computer. Page 42...
Page 43
Turning on the computer To turn on the computer Hold the bottom of the computer firmly with one hand, and lift the LCD screen lid with the other hand. Opening the Com puter Press the power button until the power indicator turns on. Turning on the Com puter If you press and hold the power button, the computer turns off.
When operating your computer on battery power, your computer's CPU speed is reduced. The battery that comes with your computer is not fully charged at the time of purchase. This computer is designed to operate only with genuine Sony batteries. Conserving Battery...
Conserving Battery Power. When operating your computer on battery power, your computer's CPU speed is reduced. This computer is designed to operate only with genuine Sony batteries. Page 45...
Page 46
Inserting a battery To insert a battery Turn the computer over, and slide the UNLOCK/LOCK latch on the bottom of the battery to the UNLOCK position. Align the grooves on the battery with the tabs on the back of the computer. Inserting the Battery Slide the battery into the computer until it clicks into place.
Page 47
Removing a battery If you are not using the computer for an extended period of time, remove the battery from the computer to avoid damaging the battery. To remove a battery Make sure the computer is turned off. Turn the computer over, and slide the UNLOCK/LOCK latch on the bottom of the battery to the UNLOCK position.
Page 48
Charging a battery You will need to charge the battery if battery power drops below 10 percent or you have not used the battery for a long time. The lithium-ion battery supplied with your computer may be recharged at any time, whether you wait until the battery is completely or partially discharged.
Page 49
Do not expose the battery to any mechanical shock. Battery life is shorter in a cold environment because of decreased battery efficiency at low temperatures. This computer is designed to operate only with genuine Sony batteries. Page 49...
Conserving Battery Power You may use the power saving modes and power schemes to conserve battery power. Conserving battery power may significantly extend your computing time, depending on how you use your computer. Page 50...
Page 51
Using power saving modes In addition to the normal operating mode, which allows you to turn off specific devices to save power, your computer has two distinct power saving modes: Standby and Hibernate. Use the Standby and Hibernate power saving modes to override a power profile setting and initiate immediate action.
Page 52
Using power schemes You can use the preset power schemes or you can customize the power profiles to conserve power. By using the power schemes and power profiles, you control the power supplied to different devices, such as the computer screen (LCD) and the hard disk drive, in your computer.
Page 53
For information about VAIO Power Management, click the Help button located toward the bottom of the VAIO Power Management tab. Alternately, click Start, select All Programs, then select VAIO Power Management, and click VAIO Power Management Help. The Help for VAIO Power Management file appears. To set your battery alarm You can change your computer settings to notify you when the battery power reaches a certain level.
Page 54
Locating power status information Displaying the power status provides useful information, such as remaining battery life. To view the Power Meter window Double-click the Power icon. The Power Meter window appears. You can also rollover the Power icon to view the remaining battery charge.
Connection Wizard guides you through the process of connecting to the Internet and choosing an Internet service provider (ISP) or setting up an existing account. When you connect to the Internet, you can register your VAIO computer, use online ® services, and gain access to Sony Computing Support. Page 55...
Page 56
Connection Wizard guides you through the process of connecting to the Internet and choosing an Internet service provider (ISP) or setting up an existing account. When you connect to the Internet, you can register your VAIO computer, use online ® services, and gain access to Sony Computing Support. Page 56...
Page 57
Setting up a dial-up Internet connection Before you can connect to the Internet, you need to connect your computer to a telephone line via a telephone cable (not supplied). Once you set up your telephone cable, you're ready to connect to the Internet. To connect a telephone cable Locate the Modem jack on your computer.
Page 58
Click Next. If the Location Information dialog box appears, follow the on-screen instructions. If it is not already selected, click to select Connect to the Internet, and click Next. Follow the on-screen instructions. Page 58...
Page 59
Setting up an Ethernet Internet connection Your computer accommodates both 10BASE-T and 100BASE-TX Ethernet connections, with data transfer speeds of between 10 and 100 Mbps. To connect an Ethernet cable Locate the Ethernet port on your computer. For location information, see Connecting an Ethernet Cable Plug one end of the Ethernet cable into your computer's Ethernet port connection.
Page 60
Click Next. If the Location Information dialog box appears, follow the on-screen instructions. If it is not already selected, click to select Connect to the Internet, and click Next. Follow the on-screen instructions. Page 60...
Page 61
Customizing your Internet connection The Internet Properties dialog box enables you to change the way you view the Internet. You can change your home page, fonts, language, and colors. You can also regulate content and set browsing preferences. To open the Internet Properties dialog box Click Start on the Windows ®...
Network Connections With a Sony computer, you can easily set up or connect to a variety of networks. The New Connection Wizard and Network Setup Wizard make it easy to gain access to networks (LANs) using wireless, Ethernet, or dial-up connections.
Page 63
Using Ethernet and dial-up connections For setting up local area networks (LANs), Ethernet is a widely installed technology. Your computer accommodates both 10BASE-T and 100BASE-TX Ethernet connections, with data transfer speeds of between 10 and 100 Mbps. To connect to a local area network using a telephone or Ethernet cable Connect an Ethernet or telephone cable to your computer.
Page 64
Click Next. If you are prompted to the Local Information dialog box, follow the on-screen instructions. Only connect 10BASE-T and 100BASE-TX cables to the Ethernet port of network cable or any telephone cable. Connecting cables other than those listed above may result in an electric current overload and could cause a malfunction, excessive heat, or fire in the port.
Page 65
A wireless local area network (LAN) is a network in which you can connect to a LAN through a wireless (radio) connection. You can opt to purchase a Sony Wireless LAN Access Point to set up a LAN. The wireless LAN access point is designed for building a wireless LAN environment. Because a wireless LAN configuration requires no wiring, you can operate multiple computers more freely than ever before.
Page 66
Click Start, Control Panel, Network and Internet Connections, and then click Network Connections. The Network Connections window appears. In the right panel under LAN or High-Speed Internet, right-click Wireless Network Connection Enabled, and select View Available Wireless Networks. The Wireless Network Connection window appears. Wireless Network Connection From the Available wireless networks list, select the name of the network in which you want to connect.
Page 67
Type the name of the network (access point) you want to connect to in the Network name (SSID) box. The following steps are for networks that require a network key. If you do not know the network key or are not sure a network key is required, see the network administrator or the guide that accompanied your access point for more information.
Page 69
Type the name of the network you want to connect to in the Network name (SSID) box. If available, make sure the Data encryption (WEP enabled) check box is selected. If the Data encryption (WEP enabled) check box is not available: Select an authentication method from the Network Authentication menu.
Page 70
Checking your network connection status Whether you have a wireless, Ethernet, or dial-up connection, you can check the status of that connection. To check your network connection status Click Start on the taskbar, and click Control Panel, Network and Internet Connections, and Network Connections.
Page 71
Bluetooth Connections Bluetooth wireless technology provides short-range connectivity without the need for cabling. When the Bluetooth ® functionality is turned on, your computer can exchange data and images with other compatible Bluetooth devices within a range of up to 32 feet. With Bluetooth technology, your computer transmits a radio frequency of 2.4 GHz.
Page 72
Using Bluetooth technology Using Bluetooth technology, your computer can communicate with: ® Compatible devices with integrated Bluetooth functionality, such as computers, mobile telephones, personal digital assistants (PDAs), mice, and keyboards. Compatible devices with an installed Bluetooth adapter, such as computers, printers, mice, and keyboards. Some Bluetooth devices may not work with your computer, depending on the type of equipment, software version, and other factors.
Page 73
Establishing wireless connections The Wireless Device Switch window enables you to select a wireless connection: Bluetooth, Wireless LAN, or Bluetooth and Wireless LAN function. Bluetooth technology is designed for a short-range connection of up to 32 feet (10 meters), while Wireless LAN technology ®...
Page 74
The BlueSpace NE window appears. You can also click the Bluetooth-Standing by icon window. BlueSpace NE Click Device Discovery. The Device Discovery window appears and searches for other nearby Bluetooth devices. Dev ice Discov ery When a device is detected, it appears in the The device currently found window next to the New icon BlueSpace NE —...
Page 75
If the device to which you want to connect has not already been authenticated, a window prompt may ask if you want to authenticate the device. Follow the on-screen instructions. For more information, see Authenticating devices. BlueSpace NE — Serv ice Discov ery List Page 75...
Page 76
Authenticating devices Authentication is a security feature, which prevents unauthorized communication between Bluetooth Bluetooth devices attempt to communicate with each other, a common passkey must be entered before the two devices are allowed to exchange data. If the detected device has the same passkey as your computer, then authentication is successful, and your computer can communicate with the Bluetooth device.
Page 77
In the Passkey text box, type your own passkey or use the passkey that is provided. Click Next. On the Bluetooth device in which you are trying to connect, a message may appear, stating that a Bluetooth device requires authentication. If this message appears, follow the on-screen instructions. On the Bluetooth device, type the same passkey as the one entered on your computer.
Page 79
Renaming the Bluetooth USB Device The Bluetooth device installed on your computer has an assigned name that you may not recognize. Renaming this device ® makes it easy for you to identify your computer during authentication. To rename the Bluetooth USB device From the Start menu, click Control Panel.
Page 80
Sending data and image files When a connection is made between your computer and another Bluetooth You can click Service Discovery for a list of available services that can be performed during your connection. If the File Push and Image Push icons appear, then your computer can send and receive data and image files. For information about services, see To send data files Establish a connection with another Bluetooth device.
Page 81
Using connection services When a connection is made between your computer and another Bluetooth of available services that can be performed during your connection. When clicked, the purple Service Discovery icons search for a connection method. For more information about the different services, see the BlueSpace NE help guide: On the BlueSpace NE window, click Help.
Page 82
Setting Bluetooth preferences The Bluetooth Options feature enables you to set hardware preferences for discovery, connection, and authentication. To access Bluetooth Options Click Start, Control Panel, Printers and Other Hardware, and Wireless Link. The Wireless Link window appears. On the Bluetooth tab, click Options. The Bluetooth Options window appears.
Page 83
Setting BlueSpace NE preferences The BlueSpace NE Settings feature enables you to set software preferences for changing folder location, responding to device discovery, displaying windows, and more. To set BlueSpace NE settings Verify that your computer is not connected to another Bluetooth device. From the BlueSpace NE window, click Setting, and then click BlueSpace NE settings.
Page 84
Adding a Bluetooth device Your computer can connect to several compatible Bluetooth dial-up Internet connections, digital cameras, and personal digital assistants (PDAs). For specific device connection information, see the documentation that accompanied the device. You can also get connection information in the Bluetooth and BlueSpace NE help guides To access the Bluetooth help guide From the Start menu, click Control Panel.
Page 85
Disconnecting a Bluetooth device To disconnect or remove a device If the BlueSpace NE window is not already open, click the Bluetooth - Standing by icon Notification area. In the Devices currently found window, select the device you want to disconnect or remove. From the BlueSpace NE window, click Device.
Page 86
Additional information The data transfer rate varies, depending on the following conditions: Obstacles, such as walls, located between devices Distance between devices Material used in walls Proximity to microwaves and cordless telephones Radio frequency interference and other environmental conditions ...
CDs and DVDs Inserting and Ejecting CDs or DVDs Avoid using adhesive labels to identify your CDs or DVDs. Adhesive labels may damage the optical drive if they come off while the disc is in the drive. To insert a disc Turn on the computer or exit a power saving mode (Standby or Hibernate) if one is active.
Page 88
Turn on the computer or exit a power saving mode (Standby or Hibernate) if one is active. For more information, Using power saving modes. Close all programs that access the optical drive, and wait for the Busy indicator on the drive cover to turn off. Press the Eject button on the drive cover to open the drive tray.
Page 89
CDs and DVDs Inserting and Ejecting CDs or DVDs Avoid using adhesive labels to identify your CDs or DVDs. Adhesive labels may damage the optical drive if they come off while the disc is in the drive. To insert a disc Turn on the computer or exit a power saving mode (Standby or Hibernate) if one is active.
Page 90
Turn on the computer or exit a power saving mode (Standby or Hibernate) if one is active. For more information, Using power saving modes. Close all programs that access the optical drive, and wait for the Busy indicator on the drive cover to turn off. Press the Eject button on the drive cover to open the drive tray.
Page 91
Copying and Playing CDs and DVDs Your computer plays and records CDs and DVDs, depending on the model you purchased. Check your specifications for the type of optical drive installed on your computer and use the table below to see which types of media your optical drive supports.
Page 92
Playing CDs Before you play an audio CD, you may need to enable your computer's audio feature. To enable the audio feature Click Start on the Windows ® The System Properties dialog box appears. As a shortcut, you can press Fn + the Windows key Select the Hardware tab, and in the Device Manager box, click Device Manager.
Page 93
Copying files to a CD-RW or CD-R You can copy files to CD-R or CD-RW discs if your VAIO Before you write data to a CD-RW or CD-R disc, read the following notes to avoid a computer malfunction and ensure the best writing results: ...
Page 94
Do not strike or move the computer while writing data to a disc. T he read/write drive letter des ignation may vary, depending on your s ys tem's hardware c onfiguration. Page 94...
Playing DVDs You can play DVDs in your computer's optical drive and view the video on a multimedia display. To play a DVD Close all open programs. Insert the DVD into the optical drive. Open a preinstalled DVD program, such as InterVideo WinDVD Click Start on the taskbar, and point to All Programs.
Page 96
Writing files to DVDs (on selected models only) Use the table shown on Copying and Playing CDs and DVDs You can copy data or video files to DVD-R or DVD-RW discs if your VAIO you write data to a DVD-RW or DVD-R disc, read the following notes to avoid a computer malfunction and ensure the best writing results: ...
Printer Connections Printing With Your Computer Your computer is compatible with many popular printers. However, to ensure the best performance, printers must be compatible with the Microsoft Windows operating system installed on your computer. ® ® Page 97...
Page 98
Printer Connections Printing With Your Computer Your computer is compatible with many popular printers. However, to ensure the best performance, printers must be compatible with the Microsoft Windows operating system installed on your computer. ® ® Page 98...
Page 99
Connecting a printer You can easily connect a printer to your computer or port replicator (if applicable). The New Hardware Wizard enables you to easily install the printer software, but some printers require separate driver software installation. See the instructions that accompanied your printer for more information.
Page 100
Restart your computer by clicking Start, Turn Off Computer, and Restart. If the New Hardware Wizard appears, follow the on-screen instructions. Make sure the computer recognizes the printer. Follow these steps: Click Start, Control Panel, Printers and Other Hardware, and then Printers and Faxes. If the computer recognizes the printer, it will be listed in the Printers and Other Hardware window.
Page 101
Disconnecting a printer You can disconnect the printer cable when the computer is on or off. Disconnecting a printer when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction. To disconnect a printer Make sure all printing jobs are completed.
Floppy Disk Drives Using a Floppy Disk Drive You can connect an external floppy disk drive (not supplied) to your computer. The floppy disk drive enables you to read or write data to a floppy disk. Page 102...
Page 103
Floppy Disk Drives Using a Floppy Disk Drive You can connect an external floppy disk drive (not supplied) to your computer. The floppy disk drive enables you to read or write data to a floppy disk. Page 103...
Page 104
Connecting a floppy disk drive You can connect a floppy disk drive when your computer is on or off. Connecting the drive when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction. To connect a USB floppy disk drive Close any active programs to prevent data loss.
Page 105
Inserting and removing floppy disks To write data to a disk, use one that is not write-protected or disable the write-protect feature. The floppy disk drive cannot write data to a disk if it is inserted into the drive improperly. To insert a floppy disk Hold the floppy disk with the label facing up.
Page 106
Protecting floppy disks Do not open the shutter manually or touch the surface of the floppy disk. Keep floppy disks away from magnets, direct sunlight, and heat sources. Page 106...
Page 107
Disconnecting a floppy disk drive You can disconnect a USB floppy drive when the computer is off by disconnecting the USB cable from the computer. Disconnecting the drive when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction.
Page 108
Storing a floppy disk drive Fold the floppy disk drive cable and connector into the side compartment on the floppy disk drive. Storing a Floppy Disk Driv e Page 108...
PC Cards Using PC Cards Your computer includes one PC Card slot. A PC Card enables you to connect devices such as an optical drive or floppy disk drive. See your VAIO Computer Specifications for the type of PC Card that is compatible with your computer. The slot is ®...
Page 110
PC Cards Using PC Cards Your computer includes one PC Card slot. A PC Card enables you to connect devices such as an optical drive or floppy disk drive. See your VAIO Computer Specifications for the type of PC Card that is compatible with your computer. The slot is ®...
Page 111
Inserting PC Cards To insert a PC Card Make sure the front label of the PC Card is facing up. Push the PC Card gently into the slot. The system automatically detects the PC Card. Do not force a PC Card into the slot; this may damage the connector pins. When a PC Card is inserted, do not place your computer in a bag or case.
Page 112
Removing PC Cards You can remove PC Cards while the computer is on or off. PC Cards draw power from the computer when they are inserted into the PC Card slot, whether or not you use the card. If you are not using your PC Card and you are using a battery as a power source, remove the PC Card from the PC Card slot to conserve battery power.
Page 113
The PC Card drive enables you to read data stored on a DVD or CD. Your computer may come with an external PC Card drive, depending on the model you purchased. If you wish to purchase a PC Card drive, shop Sony online at http://www.sonystyle.com/vaio...
Page 114
A port replicator is a device that attaches to your computer and contains additional ports. One may come with your computer, depending on the model you purchased. If you wish to purchase a port replicator, shop Sony online at http://www.sonystyle.com/vaio or contact your local retailer.
Page 115
Locating Ports and Jacks The printer port on this port replicator is intended for printer connections only. Port Replicator (Back Panel) 1 USB ports 4 Monitor (VGA) port 2 Printer port Network (Ethernet) port (10BASE-T/100BASE-TX) 3 DVI-D port 6 DC IN port Page 115...
Connecting the Port Replicator When using the port replicator, always use the AC adapter to power the port replicator; otherwise, the port replicator will be without power and will not function properly. Also, take precautions to avoid disconnecting the AC power supply when moving the computer with the port replicator attached.
Page 117
Gently push the computer onto the port replicator until it clicks into place. Make sure the port replicator is securely fastened to the computer. Securing the Port Replicator Plug the AC adapter into the DC IN port on the port replicator, and plug the power cord into the AC adapter and an AC outlet.
Page 118
Connecting a Flat-Panel Display The port replicator includes Digital Visual Interface (DVI) and Monitor (VGA) ports to which you can connect your computer to a flat-panel display. You must have a DVI-D or DVI-D/I display cable to use the DVI port or a display cable to use the Monitor port.
Page 119
Disconnecting a Port Replicator Disconnecting a port replicator when the computer is in a power saving mode (Standby or Hibernate) or the battery power is low may result in data loss or a computer malfunction. You can disconnect a port replicator when the computer is on or off.
N K is a trademark of Sony us ed to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tor. T he i.LI...
Page 122
Connecting an i.LINK digital video recorder You can connect an i.LINK digital video (DV) recorder when the computer is on or off. Connecting the DV recorder when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction. Before you connect an i.LINK digital video recorder ...
Page 123
Disconnecting the i.LINK digital video recorder You can disconnect the digital video recorder while the computer is on or off. Simply unplug the i.LINK cable from the i.LINK port on the computer. Disconnecting the cable when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction.
Page 124
Using a digital video camera recorder Your computer comes with preinstalled driver software that is compatible with most Sony digital video camera recorders. If you purchased a camera that comes with its own driver software, install these drivers before you use the camera.
Page 125
Using Computer Monitors and Projectors You can connect an external display (such as a computer monitor or a projector) to your computer. Page 125...
Page 126
Connecting a computer monitor Your computer can display images to the computer screen (LCD), to an external computer monitor, or to both the LCD and external monitor while your computer is on. If you purchased a port replicator, you can connect your computer to a flat-panel display. See Display for more information.
Page 127
Connecting a multimedia projector You can use a projector to display the actions and images from the computer screen (LCD). To connect a multimedia projector Plug the projector's power cord into an AC outlet. Plug the display cable (not supplied) into the projector and the Monitor (VGA) port To locate the Monitor port, see Connecting a Multim edia Projector Plug the audio cable (not supplied) into the projector and the Headphones jack on your computer.
Page 128
Click the red button next to Monitor or Panel. Click Apply. The ATI Property Page message box appears. launches Sony Notebook Setup, where you can customize the Plug and Display Using S1 and S2 Buttons taskbar, and then click Control Panel and Appearance and Themes.
Page 129
Click Yes. Click OK. For more information, click Help. If you cannot see your movie or DVD on the external display, change the monitor setting by clicking on the Primary icon on the display panel of your choice. You may not be able to display the computer screen (LCD) and an external display or projector at the same time, depending on the types of computer displays and projectors you are using.
Page 130
Disconnecting a computer monitor or projector You can disconnect the external computer monitor or projector by unplugging the monitor (VGA) cable from your computer's port. Disconnecting the external display when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction.
Your computer comes with built-in stereo speakers. If you wish to enhance the sound quality of your computer, you can purchase and connect external speakers. If you want to purchase speakers, make sure the speakers are designed for computer use. You can shop Sony online at http://www.sonystyle.com/vaio or contact your local retailer.
Page 132
Connecting speakers You can connect external speakers to your computer to enhance the sound quality of your computer. Do not place floppy disks on the speakers. The speakers' magnetic field may damage the data stored on the floppy disks. To connect speakers to your computer Turn down the volume of the speakers.
Page 133
Disconnecting speakers You can disconnect external speakers when the computer is on or off. Simply unplug the speaker cable from the Headphone jack on the computer. Page 133...
Page 134
Adjusting the sound You can adjust the volume by using the following shortcut keys. An on-screen display appears notifying you when a change occurs. Fn+F2 Toggles the headphones and built-in speakers off and on. Fn+F3 Decreases the speaker volume. Fn+F4 Increases the speaker volume. Alternatively, you can use the Volume icon To adjust the volume of your speakers Right-click the Volume icon...
Page 135
Enabling the sound If you do not hear sound when playing a CD or DVD, you may need to enable the audio feature. To enable the audio feature Click Start on the Windows ® Click Performance and Maintenance, and click System. The System Properties window appears. Select the Hardware tab, and click Device Manager.
Using Microphones You can connect an external microphone to your computer to enable the sound input to your computer. Make sure your microphone is designed for computer use. If you wish to purchase a microphone, shop Sony online at http://www.sonystyle.com/vaio or contact your local retailer.
Page 137
Connecting a microphone Plug the microphone cable into the Microphone jack on the computer. Connecting a Microphone See the guide that accompanied your microphone for more information on its installation and use. A protruding dot loc ated next to the M ic rophone jac k dis tinguis hes this jac k from the H eadphone jac k. Page 137...
Page 138
Disconnecting a microphone You can disconnect an external microphone when the computer is on or off. Simply unplug the microphone cable from the Microphone jack on the computer. Page 138...
Page 139
Using a microphone to record sound You can record messages, memos, etc. by connecting a microphone to the Microphone jack To record from a microphone Double-click the Volume icon From the Options menu, click Properties. The Properties dialog box appears. Click to select the Recording option in the Adjust volume for box.
Memory Upgrades Before you upgrade your computer's memory, read the safety information in module and amount of memory installed on your computer, refer to the VAIO Precautions and Procedures. For the type of Computer Specifications. ® Page 140...
Precautions and Procedures Sony recommends that memory upgrades be performed by an authorized Sony Service Center. To find the nearest center or agent, go to: http://www.sony.com/pcsupport. The procedures described below assume familiarity with the general terminology associated with personal computers and with the safety practices and regulatory compliance required for using and modifying electronic equipment.
Removing and installing memory modules Make sure you read the safety information in When installing a memory module, do not open the module package until you are ready to install it. The package protects the module from Electrostatic discharge (ESD). To remove a memory module Turn off the computer and all attached devices.
Page 143
Push the module down until it snaps into the slot. When the module is correctly seated in the slot, close the memory bay. Replace the fastening screw(s) on the memory bay. Make sure the system recognizes the new memory module. See information.
Click Start on the Windows ® Select Sony Notebook Setup from the submenu. The Sony Notebook Setup dialog box appears. On the About This Computer tab, make sure the System Memory displayed in the System Information box matches the amount of memory installed.
Use a thin, straight object (such as a paper clip) to press the reset button on the bottom of the computer. For location information, see Locating Controls and Ports. Reinsert the power cord and the battery. Turn on the computer. For further instructions, contact Sony Computing Support (http://www.sony.com/pcsupport). Page 145...
Page 146
Use a thin, straight object (such as a paper clip) to press the reset button on the bottom of the computer. For location information, see Locating Controls and Ports. Reinsert the power cord and the battery. Turn on the computer. For further instructions, contact Sony Computing Support (http://www.sony.com/pcsupport). Page 146...
Page 147
Use a thin, straight object (such as a paper clip) to press the reset button on the bottom of the computer. For location information, see Locating Controls and Ports. Reinsert the power cord and the battery. Turn on the computer. For further instructions, contact Sony Computing Support (http://www.sony.com/pcsupport). Page 147...
Page 148
Select Exit (Save Changes), and press Enter. The Setup Confirmation window appears. Select Yes, and press Enter. The computer restarts. If this occurs on a regular basis, contact Sony Computing Support (http://www.sony.com/pcsupport). to select System Time, and then set the time (hour: minute: second). Press...
Page 149
Turn off the computer. Remove any peripheral devices connected to the computer. Restart the computer. Press the F2 key when the Sony logo appears. The BIOS Setup window appears. Press the Right Arrow key Press the Down Arrow key SETUP items. appears.
Page 150
What do I do if my computer stops responding? It is best to turn off your computer using the Turn Off Computer option on the Microsoft the taskbar. Using other methods, including those listed below, may result in loss of unsaved data. ...
Page 151
Why won't my computer enter Standby or Hibernate mode? Your computer may become unstable if the operating mode is changed before the computer completely enters Standby or Hibernate. To restore the computer to normal operating stability: Close all open programs. Restart the computer.
Page 152
Why is the sound of my computer's fan so loud? The computer's fan may be running at a high speed to cool the CPU. By lowering the CPU speed, you also lower the speed and noise level of the computer's fan. To lower the CPU speed using the power schemes: Click Start on the Windows ®...
Page 153
Why does the System Properties dialog box display a slower CPU speed than the maximum? This is normal. Because your computer's CPU utilizes a type of CPU speed controlling technology for power conservation purposes, System Properties may display the CPU's current speed instead of the maximum speed. Page 153...
Page 154
Why don't my changes appear on the computer screen (LCD)? You may need to refresh the computer screen. Press and hold the Windows key , and press D twice. Page 154...
System Security How can I protect my system against security threats, such as viruses? The Microsoft Windows operating system is preinstalled on your computer. The best way to protect your computer against ® ® security threats, such as viruses, is to download and install the latest Windows updates regularly. You can get important Windows updates by doing one of the following: ...
Page 156
System Security How can I protect my system against security threats, such as viruses? The Microsoft Windows operating system is preinstalled on your computer. The best way to protect your computer against ® ® security threats, such as viruses, is to download and install the latest Windows updates regularly. You can get important Windows updates by doing one of the following: ...
Page 157
Using the ICF feature may interrupt the file and print sharing features for preinstalled networking software programs, such as VAIO Media software. As an alternative, Sony suggests installing a router as a hardware-based firewall solution. A router box protects your computer and allows your network to run without interruption.
Page 158
How do I keep my preinstalled antivirus software updated? You can keep the preinstalled Norton Internet Security Corporation. To download and install the latest security update Double-click the Norton Internet Security icon If you have not previously registered the antivirus software, a series of information wizards appear. Follow the on-screen instructions to complete each wizard Double-click the Norton Internet Security icon again.
Page 159
Battery How do I know when the battery is charged? To determine the remaining battery charge, see Locating power status information. Page 159...
Page 160
Battery How do I know when the battery is charged? To determine the remaining battery charge, see Locating power status information. Page 160...
Page 161
When is the computer using AC power? When the computer is directly connected to the AC adapter, it uses AC power, even if a battery is installed. Page 161...
Page 162
When should I recharge the battery? When the battery level falls below 10 percent. When both the battery and power indicators blink. When you have not used the battery for a long time. Page 162...
Page 163
When should I replace the battery? If the battery power is still low after charging it, the battery may be reaching the end of its life and should be replaced. Page 163...
Page 164
Should I be concerned that the installed battery is warm? No, it is normal for the battery to be warm when it is powering the computer. Page 164...
Page 165
Can my computer enter Hibernate mode while using battery power? Your computer can enter Hibernate mode while using battery power, but some software programs and peripheral devices prevent the system from entering Hibernate mode. If you are using a program that prevents the system from entering Hibernate mode, save your data frequently to avoid losing data.
Page 166
Why doesn't my computer enter Hibernate mode? You may first need to enable Hibernate mode. Follow these steps: Click Start on the Windows ® Click Performance and Maintenance, and click Power Options. The Power Options Properties window appears. Select the Hibernate tab. Click to check the box next to Enable hibernation.
Page 167
Make sure the telephone cable is working. Plug the cable into an ordinary telephone and listen for a dial tone. Make sure the telephone number the program is dialing is correct. Make sure the software you are using is compatible with the computer's modem. (All preinstalled Sony programs are compatible.) Page 167...
Page 168
Make sure the telephone cable is working. Plug the cable into an ordinary telephone and listen for a dial tone. Make sure the telephone number the program is dialing is correct. Make sure the software you are using is compatible with the computer's modem. (All preinstalled Sony programs are compatible.) Page 168...
Page 169
Why is my modem connection slow? Your computer is equipped with a V.90 compatible modem. Many factors may influence modem connection speed, including telephone line noise or compatibility with telephone equipment, such as fax machines or other modems. If you think your modem is not connecting properly to other PC-based modems, fax machines, or your Internet Service Provider (ISP), follow these steps: ...
Page 170
Networking Why can't my computer connect to a wireless LAN access point? Connection availability is affected by distance and obstructions. You may need to move your computer away from obstructions or closer to any access point you may be using. ...
Page 171
Networking Why can't my computer connect to a wireless LAN access point? Connection availability is affected by distance and obstructions. You may need to move your computer away from obstructions or closer to any access point you may be using. ...
Page 172
Why can't I access the Internet? Check the access point settings. Refer to the instructions supplied with the access point. Make sure your computer and the access point are connected to one another. Move your computer away from obstructions or closer to any access point you may be using. ...
Page 173
Why is the data transfer speed slow? The wireless LAN data transfer speed is affected by distance and obstructions between devices and access points. Other factors include device configurations, radio conditions, and software compatibility. To maximize the data transfer speed, move your computer away from obstructions or closer to any access point you may be using. ...
Page 174
Why is the communication speed interrupted or slowed down when MPEG2 data is transferred? The typical effective data transfer speed via an access point is 4-5 Mbps when adhering to the IEEE 802.11b standard or both the IEEE 802.11b and IEEE 802.11g standards (selected models only). High-rate stream transfers with MPEG2 data may lower this rate.
Page 175
How do I avoid data transfer interruptions? When your computer is connected to an access point, data transfer interruptions may occur when using large files or if the computer is in close proximity to microwaves and cordless telephones. Move the computer closer to the access point.
Page 176
Can I connect to an IEEE 802.11a device? Computers with built-in wireless LAN support only the IEEE 802.11b and IEEE 802.11g standards (selected models only). Devices connecting to a wireless LAN using the IEEE 802.11a standard cannot connect to devices using the IEEE 802.11b/g standards.
Page 177
Wireless LAN communication occurs on divided frequency bands known as channels. Third-party wireless LAN access point channels may be preset to different channels from Sony devices. If you are using a wireless LAN access point, refer to connectivity information contained in your access point instructions.
Page 178
When I change the encryption key, the network connection stops. What do I do? Two computers with built-in wireless LAN may loose a peer-to-peer network connection if the encryption keys of both computers no longer match. You can either change both the encryption keys back to the original profile or, if you have not saved changes to the original profile, you can restart both computers.
Bluetooth Technology Why can't other Bluetooth devices discover my computer? Make sure both devices have the Bluetooth Your computer and the device may be too far apart. Wireless Bluetooth technology works best when the devices are within 32 feet (10 meters) of each other. ...
Page 180
Bluetooth Technology Why can't other Bluetooth devices discover my computer? Make sure both devices have the Bluetooth Your computer and the device may be too far apart. Wireless Bluetooth technology works best when the devices are within 32 feet (10 meters) of each other. ...
Page 181
Why can't other Bluetooth devices connect to my computer? Make sure the other device is authenticated. For more information, see Your computer may not allow connections from other devices. To enable Bluetooth device connections, follow these steps: On the BlueSpace NE window, click Setting, and then click BlueSpace NE settings. Click to open the Security tab.
Page 182
How will I know when another Bluetooth device is requesting authentication? A notification prompt appears on the Windows From the Start menu, click Control Panel. Click Printers and Other Hardware, and then click Wireless Link. The Wireless Link window appears. On the Bluetooth tab, click Options.
Page 183
Why is my Bluetooth connection slow? The 2.4 GHz radio frequency used by Bluetooth and wireless LAN devices is also used by other devices. Bluetooth devices incorporate technology that minimizes interference from other devices using the same wavelength, however, communication speed and connection range may be reduced. Interference from other devices may also stop communication altogether.
Page 184
Can I use a device equipped with Bluetooth technology on airplanes? With Bluetooth technology, your computer transmits a radio frequency of 2.4 GHz. Sensitive locations, such as hospitals and airplanes, may have restrictions on the use of Bluetooth devices, due to radio interference. Check with facility staff to verify that use of the Bluetooth feature on your computer is permitted.
Page 185
CDs and DVDs How do I maintain CDs and DVDs? Avoid touching the surface of the disc with your fingers. Fingerprints and dust on the surface of the disc may cause reading errors. Try using canned compressed air to clean dusty discs. ...
Page 186
CDs and DVDs How do I maintain CDs and DVDs? Avoid touching the surface of the disc with your fingers. Fingerprints and dust on the surface of the disc may cause reading errors. Try using canned compressed air to clean dusty discs. ...
Page 187
Why does my computer freeze when I try to read a disc? The disc your computer is trying to read may be dirty or damaged. Follow these steps: Restart the computer by clicking Start, Turn Off Computer, and Restart. Eject the disc from the optical drive.
Page 188
What do I do if the drive tray won't open? Make sure the computer is on. Press the Eject button on the optical drive. If the Eject button does not work, click Start on the Windows drive icon, and select Eject from the shortcut menu. ...
Page 189
What do I do if the optical drive isn't playing my CD or DVD properly? Make sure the disc was inserted into the drive with the label facing up. Make sure the necessary program(s) is installed according to the manufacturer's instructions. ...
Page 190
Why did the computer screen (LCD) go blank? Your computer screen may go blank if the computer has lost power or has entered a power saving mode (Standby or Hibernate). If the computer is in LCD (Video) Standby mode, press any key to activate the computer screen. See Using power saving modes for more information.
Page 191
Why can't I view the entire DVD video display on the external display? The display resolution may not be properly set. To adjust the display resolution, see Selecting a display for more information. It is recommended that you adjust the display resolution to 1024 x 768 or smaller, depending on the size of the external display screen.
Page 192
How do I adjust the image on the external display? Use the controls on your external display to adjust the image. See the help guide that accompanied your display for more information. Page 192...
Page 193
How do I change the video resolution on the external display? The video may not appear on the entire screen if your computer resolution is set larger than 1024 x 768. Adjust the video resolution to 1024 x 768 or smaller. To change the video resolution, follow these instructions: Right-click the desktop, and select Properties from the shortcut menu.
Page 194
Printing Why can't I print a document? Make sure the printer is on, and the printer cable is securely connected to the ports on your printer and computer. Make sure the printer is compatible with the Microsoft You may need to install the printer driver software before you use the printer.
Page 195
Printing Why can't I print a document? Make sure the printer is on, and the printer cable is securely connected to the ports on your printer and computer. Make sure the printer is compatible with the Microsoft You may need to install the printer driver software before you use the printer.
Page 196
Microphone Why doesn't my microphone work? If you are using an external microphone, make sure the microphone is turned on and is properly plugged into the Microphone jack on the computer. See Connecting a microphone for more information. If the microphone is battery-powered, make sure the batteries are correctly installed.
Page 197
Microphone Why doesn't my microphone work? If you are using an external microphone, make sure the microphone is turned on and is properly plugged into the Microphone jack on the computer. See Connecting a microphone for more information. If the microphone is battery-powered, make sure the batteries are correctly installed.
Page 198
Mouse What do I do if the computer doesn't recognize the mouse? Make sure the mouse is securely plugged into the port. Restart the computer with the mouse connected to the computer. Page 198...
Page 199
Mouse What do I do if the computer doesn't recognize the mouse? Make sure the mouse is securely plugged into the port. Restart the computer with the mouse connected to the computer. Page 199...
Page 200
What do I do if the pointer doesn't move when I use the mouse? Make sure another mouse is not installed. If you are playing a disc, press the Ctrl+Alt+Delete keys simultaneously to stop playback and restart the computer. ...
Speakers Why won't my speakers work? Make sure the speakers are properly connected and the volume is turned up loud enough to hear sound. Make sure the speaker volume is not muted and is loud enough to hear sound. Use the Fn+F2 keys to toggle the mute option on and off, and use the Fn+F4 keys to increase the volume.
Page 202
Speakers Why won't my speakers work? Make sure the speakers are properly connected and the volume is turned up loud enough to hear sound. Make sure the speaker volume is not muted and is loud enough to hear sound. Use the Fn+F2 keys to toggle the mute option on and off, and use the Fn+F4 keys to increase the volume.
Page 203
Why can't I hear sound from my speakers? If the computer is using battery power, make sure the battery is properly inserted and is charged. Make sure the speaker volume is not muted and is loud enough to hear sound. Use the Fn+F2 keys to toggle the mute option on and off, and use the Fn+F4 keys to increase the volume.
Page 204
Why don't the Fn+F2, Fn+F3, or Fn+F4 key combinations work? The Fn+F2 keys toggle the headphones and built-in speakers on and off. The Fn+F3 keys decrease the built-in speaker volume and the Fn+F4 keys increase the built-in speaker volume. The computer may not recognize the Fn+F2, Fn+F3, and Fn+F4 keys if the correct speakers are not selected.
Touch pad What do I do if the touch pad does not work? Try restarting your computer. Follow these steps: Press the Windows key Press U. The Turn off computer window opens. Press R to restart the computer. If the computer does not restart, follow these steps: Press the Ctrl+Alt+Delete keys simultaneously.
Page 206
Touch pad What do I do if the touch pad does not work? Try restarting your computer. Follow these steps: Press the Windows key Press U. The Turn off computer window opens. Press R to restart the computer. If the computer does not restart, follow these steps: Press the Ctrl+Alt+Delete keys simultaneously.
Page 207
How do I change the left and right button assignments? If your computer is interpreting a single-click as a double-click, you may want to change the button assignments. Follow these steps: Click Start on the Windows ® Mouse. The Mouse Properties dialog box appears with the Buttons tab selected. Select your preferences in the Button Selection box, and then click Apply to install your settings.
Floppy Disks Why doesn't the Safely Remove Hardware icon The computer does not recognize the floppy disk drive. First, make sure the USB cable is properly connected to the USB port. If you need to secure the connection, wait a few moments for the computer to recognize the drive. If the icon still does not appear, follow these steps: Close all programs that were accessing the floppy disk drive.
Page 209
Floppy Disks Why doesn't the Safely Remove Hardware icon The computer does not recognize the floppy disk drive. First, make sure the USB cable is properly connected to the USB port. If you need to secure the connection, wait a few moments for the computer to recognize the drive. If the icon still does not appear, follow these steps: Close all programs that were accessing the floppy disk drive.
Page 210
Why is the drive unable to write data to a floppy disk? Make sure the floppy disk is properly inserted in the drive. See Inserting and removing floppy disks for instructions on how to insert the disk properly. If the disk is inserted properly and you are still unable to write data to it, the disk may be full or write-protected. You can either use a floppy disk that is not write-protected or disable the write-protect feature by moving the write-protect tab on the bottom of the disk to the close position.
Page 211
Make sure the PC Card is compatible with the Microsoft See the instructions that accompanied your PC Card. You may need to install driver software if you are not using a Sony PC Card. Inserting PC Cards for more information.
Page 212
Make sure the PC Card is compatible with the Microsoft See the instructions that accompanied your PC Card. You may need to install driver software if you are not using a Sony PC Card. Inserting PC Cards for more information.
Page 213
Why doesn't my computer recognize attached devices? For some PC Cards, if you alternate between normal power operation and the Standby or Hibernate modes while the card is inserted into the PC Card slot, the computer may not recognize the PC Card or the connected device. Restart your computer.
Page 214
Why can't I insert my PC Card? Make sure you are inserting the card correctly. See You may not be able to use some PC Cards or some functions of the PC Card with this computer. Check the guide that accompanied your PC Card for more information on its use.
Page 215
N K is a trademark of Sony us ed only to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tion. T he i.LI...
Page 216
N K is a trademark of Sony us ed only to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tion. T he i.LI...
Memory Stick Media Why can't I open my image files? You may need to reformat your Memory Stick Formatting Memory Stick media erases all data, including music data, previously saved to it. Before you reformat Memory Stick media, back up important data and confirm that the media does not contain files you want to keep.
Page 218
Memory Stick Media Why can't I open my image files? You may need to reformat your Memory Stick Formatting Memory Stick media erases all data, including music data, previously saved to it. Before you reformat Memory Stick media, back up important data and confirm that the media does not contain files you want to keep.
Page 219
Copyright protected music cannot be checked out to any Memory Stick media other than MagicGate media. Using recorded music requires permission of the copyright holders. Sony is not responsible for music files that cannot be recorded from a CD or downloaded from other sources. Memory Stick Page 219...
Page 220
Can I copy images from a digital video camera using Memory Stick media? Yes, and you can view video clips that you have recorded with Memory Stick media-compatible video camera recorders. Page 220...
Page 221
How do I prevent damage to the Memory Stick media? Do not use the media in locations that are subject to static electricity or electrical noise. Do not touch the media connector with your finger or metallic objects. ...
Page 222
How do I extend the life of the Memory Stick media? Use the supplied storage case. See the instructions that came with your media for more information on its use. Do not use or store the media in a location that is subject to: ...
Support Options The section contains information on where to go for answers to questions about your VAIO computer and the preinstalled ® software. Page 223...
Sony Computing Support This service provides instant access to information on commonly encountered problems. Type a description of the problem and the Knowledge Database searches for the corresponding solutions online. You can visit Sony Computing Support at: http://www.sony.com/pcsupport. VAIO Update When your computer is connected to the Internet, VAIO Update automatically notifies you when critical software and security information is posted on the support Web site.
Telephone 888-4-SONY-PC (888-476-6972) CLIÉ Converter Sony Electronics Inc. CLIÉ Converter software is a plug-in program that converts Giga Pocket playback on your Sony CLIÉ handheld. After converting your Video Capsules, you can use CLIÉ Converter software to ® ® transfer them to Memory Stick media or to save them to your hard disk drive for transfer to your CLIÉ...
Page 226
888-4-SONY-PC (888-476-6972) Giga Pocket Personal Video Recorder ® Sony Electronics Inc. Giga Pocket Personal Video Recorder is a unique set of hardware and software components that provide you with excellent ® TV viewing, recording, and playback experiences. You can watch and record your favorite TV programs from your computer, create custom playlists, and play your Video Capsules on other compatible computers.
Page 227
VAIO Product Registration is an integrated registration program for both Sony Electronics and Microsoft Corporation. By registering with Sony, you enable Sony to notify you of software and hardware issues that may affect your user experience. Microsoft directs the data to Sony Electronics. Sony uses the registration data for warranty and product support purposes and the analysis of customer feedback on Sony computer features.
Page 228
Telephone 888-4-SONY-PC (888-476-6972) WinDVD for VAIO ® ® InterVideo, Inc. Web site http://www.intervideo.com/jsp/Support.jsp Telephone 510-651-0888 Premiere software that provides maximum compatibility and video ® ® computer up to date by regularly checking the Sony Online Support Web ® Page 228...
