INSTALLATION INSTRUCTION OF LED Wall Pack
Prior to Installation
Before installing light fixtures, read and understand all cautions, warnings, instructions, and product labels. Failure to do so could result in injury
and/or void the warranty.
Warning: Make sure power is OFF before installing or maintaining Fixture.
CAUTION
1. All work should be performed by a qualified electrician.
2. The wall should have the enough strength for installing the fixture; Its endurance must be more than the weight of fixture.
3. Failure to properly support the Fixture may cause damage or jnjury, for which the manufacturer is not responsible.
ASSEMBLY
1.Loosen the screws,Open the cover. See FIG.1
2. Mount the base to the wall by screws.See FIG.2
3.Assemble and lock the cover to base tightly with screws.
+-
