Emerson SmartSet ER100103 Owner's Manual

®
SmartSet Clock Radio
With Auto Date-Time Setting System,
1.4" Blue Jumbo Display,
Dual Alarms, PLL FM Radio,
USB Charging and
Red Projection Clock
(SmartSet Patent No. 6,567,344)
OWNER'S MANUAL
ER100103
1
,
4

Package Contents

ER100103 Clock Radio x 1
Read This Sheet
YEAR
AL1 AL2 DATE TIME AL MODE - TUNE / SET +
TIME
VOL VOL+ STORE MEM.
ZONE
SLEEP
5

Location of Controls and Indicators

1
2
3
4
5
6
7
13
14
15
16
17
18 YEAR
AL1 AL2 DATE TIME AL MODE - TUNE / SET +
TIME
VOL VOL+ STORE MEM.
ZONE
19
20
SNOOZE
SLEEP
DIMMER
21
22
23
1. 1 (AL 1'Radio') Alarm Indicator. 16. Speaker (Back Cabinet).
1
2. (AL 1'Buzzer')Alarm Indicator. 17. TIME Setting / MEM FM Station Recall
3. AM Indicator.('On'=AM;'Off'=PM) 18. MONTH/DATE Setting / STORE
4. AUX Indicator. abc Station .
5. DAY OF WEEK Indicators.(MON, 19. ALARM 1 Setting / VOLUME-
TUE,WED,THU,FRI,SAT,SUN) 2 0. ALARM 2 Setting / VOLUME+
21. Projector.
6. Projection clock ON/OFF Button.
22. UNIT ON / OFF ( Standby)
7. ROTATE IMAGE Button.
8. LOW Battery Indicator. 23. SNOOZE DIMMER / Button.
9. FM Radio Indicator. 24. SLEEP Button(Sleep To Music Timer).
▲ Button.
10. 2 (AL 2 'Buzzer') Alarm Indicator. 25. TUNE +/ SET
▼
11. 2 (AL 2 'Radio') Alarm Indicator. 26. TUNE -/ SET Button.
12. Time/Date Display. 27. AC adapter(Bottom Cabinet).
28. Adapter's cable (also acts
13. TIME ZONE / AL MODE Button.
as the FM antenna)
14. USB Charge Out
15. AUX IN Jack. 29. Backup Battery Holder( Back Cabinet)
6

Setting Time Zone / Clock / Alarm Week Mode

®
The first time you connect your new SmartSet clock radio to the AC outlet
the internal computer will automatically set the time correctly for the Eastern
Time Zone, which is the initial default setting.The display will scan for a few
seconds and then show the correct Day and Time in the Eastern zone. If you
live in the Eastern Time zone, there's nothing else to do. Your clock is set
correctly and running.If you do not live in the Eastern Time zone you must
change the default zone display to your own zone. You only do this one time
®
and the SmartSet will remember the new default zone setting and will
always return to that setting after a power interruption.
There are 7 time zones programmed into your SmartSet
follows:
ZONE 1 — Atlantic Time ZONE 2 — Eastern Time (Default Setting)
ZONE 3 — Central Time ZONE 4 — Mountain Time
ZONE 5 — Pacific Time ZONE 6 — Yukon Time
ZONE 7 — Hawaiian Time
1
YEAR
TIME
AL1 AL2 DATE AL MODE
TIME
VOL VOL+ STORE MEM.
ZONE
DIMMER
1
Depress and hold the "TIME ZONE" button.
2
Press the "▼" or "▲" button until your own time zone appears on the
display, then release the buttons.
Note: Time Zone and Date/Time setting can only be adjusted
in standby mode, where the function
of Radio and AUX are
disabled (indicators of "MHz" and "AUX" are Off).

Date and Year Display and Adjustment

DATE DISPLAY(MM.DD):
Press and hold the "DATE" button
DATE ADJUSTMENT:
Press and hold the "DATE" button, and then short or long press the
"▼" or "▲" button to advance Month or Date.
For example, May 21st will appear as "5.21".
Release the buttons to finish the adjustment.
YEAR DISPLAY(YYYY)
Press and hold the "DATE" and "TIME" button
YEAR ADJUSTMENT:
While at YEAR DISPLAY, press the"▼" or "▲" button to adjust the Year

Manual Time Adjustments

Press and hold the "TIME" button, and then short or long press the
"▼" or "▲" button to advance Hour or Minutes.
Release the buttons to finish the adjustment.
NOTE: If you manually adjust the time, your new setting is entered into the
®
SmartSet memory. If the power is interrupted, the display will return to
your new setting, not the original setting, when the power is restored.

Daylight Saving and Leap Year Adjustments

A l l D a y l i g h t S a v i n g a n d L e a p Ye a r a d j u s t m e n t s a r e m a d e
®
a u t o m a t i c a l l y b y the SmartSet internal computer as follows:
• Start of Daylight Saving Time:
At "2:00 AM" on the 2nd Sunday in March, the clock will automatically
advance to "3:00 AM".
12
• End of Daylight Saving Time:
11
At '3:00 AM' on the 1st Sunday in November, the clock will automatically
10
reset to "2:00 AM".
9 • Leap Year:
8
At "12:00 Midnight" on February 28th, the calendar display will change
to "2.29".
Adjusting The Wake Up Times and
Alarm Week Mode
29
28
Alarm Week Mode Adjusting The Wake Up Times for AL1 or AL2
27
Press and hold the "AL1" ("AL2") button until the
A
display flashes, then release the button.
Everyday
Short or long press the "▼" or "▲"
button to
26 advance Hour or Minutes.
Short press the "AL1" ("AL2") button again,
25
Alarm Volume (U03-U15) will display.
The alarm will
24 Short or long press the "▼" or "▲"
button to
turn on all 7 days.
decrease or increase the maximum volume of the
B
buzzer or radio alarm at which the alarm will
Weekdays only
reach gradually at wake up time.
Then, short press the "AL1" ("AL2") button again
to finish this alarm setting process, or leave the
unit idle, that will resume to time/standby mode
The alarm will only
automatically.
turn on Monday
Radio
Selecting The Alarm Week Mode(
through Friday.
Press and hold the "AL1" ("AL2") button until the
Button.
C
display flashes, then release the buttons.
Button.
Press the "AL MODE" button to select the
Weekends only
Alarm Week Mode
A B
Button.
Short press the "AL1" ("AL2") button again,
The alarm will only
Alarm Volume (U03-U15) will display.
turn on Saturday
Repeat the Alarm Volume setting procedure
and Sunday.
stated above.
NOTE: Be sure that you have set the wake up time by observing the AM
indicator. If the AM indicator is 'On ' the wake up time is "AM". Otherwise
the wake up time is "PM".
®
clock radio as
2
- TUNE / SET +
SLEEP
A B / / C )
, or that suits your need.
