HID Technology Solutions 1062 Quick Start Manual

1062 Handscanner Quick Start Guide
Technology Solutions (UK) Ltd, Suite A, Loughborough Technology Centre,
Epinal Way, Loughborough. Leicestershire. LE11 3GE. United Kingdom.
www.tsl.com
Main Features
Status LEDs Trigger Button
LASER LIGHT
DO NOT STARE INTO BEAM.
CLASS 2 LASER PRODUCT.
LASERSTRAHLUNG NICHT IN
DEN STRAHL BLICKEN.
LASER KLASSE 2.
LUMIÈRE LASER NE PAS
REGARDER DANS LE
FAISCEAU. APPAREIL À
LASER DE CLASSE 2.
630-670nm 1mW
Battery cover release.
Docking
connector
Replacing the battery
1. Press in the yellow
button
2. Slide the
battery cover
down and lift
it off.
The battery can then be lifted out and replaced. Refit the cover by
sliding it back up until the button clicks in place.
Charging cradle
The Handscanner functionality depends on the software running on
the host device. Generally pressing the button on the Handscanner
triggers a barcode and/or RFID read. The RFID read zone is in front
of the window on the Handscanner.
Charging slot for spare battery.
The status LEDs on the front of the Handscanner and charger
provide an indication of the operating status the units.
Docking port for Handscanner.
Charge Status LEDs
Communications port Input from
connector. charger.
Using the Handscanner
Status LEDs
Handscanner
