HODEDAH
Assembly Instructions
This instruction booklet contains important safety information, please read and keep for future reference.
ITEM # HITV107-G
57 INCH WIDE TV STAND
FRONT VIEW
Product Dimensions: Height 21.62" x Width 57" x Depth 17.75"
www.Hodedah.com
®
Accommodates up to a 60 inch TV
BACK VIEW
2 people
90 mins
1 YR LTD
1 Box
Advertisement
Table of Contents
Summary of Contents for Hodedah HITV107-G
- Page 1 HODEDAH ® Assembly Instructions 2 people This instruction booklet contains important safety information, please read and keep for future reference. 90 mins ITEM # HITV107-G 57 INCH WIDE TV STAND 1 YR LTD 1 Box FRONT VIEW BACK VIEW Product Dimensions: Height 21.62" x Width 57" x Depth 17.75"...
-
Page 2: Warranty
FREE of charge within ONE YEAR of purchase! WARRANTY Hodedah warrants this product to be free from defects in materials and workmanship and agrees to remedy any such defect. This warranty covers one year from the date of original purchase. This is solely limited to replacement of defective parts and no assembly for labor is included. -
Page 3: Product Care And Maintenance
HODEDAH ® · Never open more than one drawer at a time. · The use of tip-over restranits may reduce but not eliminate the risk of tip-over. Let's get started… Helpful hints, read before beginning assembly · Make sure you receive all boxes. If your item is packed in one box, box count will read 1 of 1, likewise if your item is packed in two boxes, box count will read 1 of 2 and second box will read 2 of 2. -
Page 4: Hardware List
HODEDAH ® Hardware List 16 Pcs 36 Pcs 8 Pcs Screw M6 x 40mm Pvc Dowel Screw M3.5 x 14mm 8 Pcs Pvc Cap 8 Sets 4 Pcs 4 Pcs Mini Fix Door Support 8 Pcs Shelf Support Pvc Cap... -
Page 5: Parts List
HODEDAH ® Parts List Bottom Panel Left Side Panel Left Stand Panel 1448 x 446 x 15mm 464 x 445 x 15mm 464 x 445 x 15mm 1 Pc 1 Pc 1 Pc Right Stand Panel Right Side Panel Top Panel... - Page 6 HODEDAH ® The Breakdown www.Hodedah.com...
-
Page 7: Pre-Assembly
HODEDAH ® Pre - Assembly Insert, push down and tighten mini fixscrew ④ , to` the hole as shown, 8pcs. Insert mini fix ④ (nuts) with the cross arrow mark facing upward and aim to the panel 's top thru holes. -
Page 8: Door Panel Assembly
HODEDAH ® Door Panel Assembly Put the glasses on backside of the panel as shown, next use Glass Round Bracket ⑦ to mount and fix the glass edge as shown, then tighten it with screw ② , after that close the Glass Round Bracket ⑦... - Page 9 HODEDAH ® Step 1 Fix Panel onto Panels by pushing and slotting the dowels . Use allen key ⑪ to tighten 8 screws ③ onto the non-thru holes at Panel from the thru-holes of panel Screw Allen Key M 6 x 40mm 1 Pc.
- Page 10 HODEDAH ® Step 2 Place and fix panel onto panel ,·panel , panel and panel , and align properly by inserting the 8 (down) mini fix screws ④ onto the L-thru holes at top edge of panel . At the...
- Page 11 HODEDAH ® Step 3 Align properly the door supports ⑤ to door and push to slot onto the non-thru hole of top panel F and bottom panel Then take the adjust panel place it inside the middle compartment by putting it on top of the 4 shelf supports.
- Page 12 HODEDAH ® Step 4 Place the back Panels onto the back of the main unit, then align them properly for nailing. 2.Use hammer to insert the nails at the center of the edges. Gap between nails should be about 100mm.
- Page 13 HODEDAH ® FITTING OF ANTI-TIP SAFETY STRAP STEP 1: · Attach the mounting bracket a to the furniture in the solid part below the top panel a few inches away from the side of the unit. · Screw b through the smallest hole of a .
-
Page 14: Job Complete
HODEDAH ® Job Complete Enjoy & Thank you for purchasing from Hodedah! www.Hodedah.com...
