Summary of Contents for eSSL ThermoAccess-9
- Page 1 User Manual ThermoAccess-9...
- Page 2 Infrared Thermometer Access Control ThermoAccess-9 Basic specifications: Sensor WTTS001 Display Infrared LED Accurate ±0.2℃ Measuring time <0.5s Working voltage 5V ~ 12V input Working ambient temperature: 5℃~44℃ Measuring distance: 5~10cm Temp measurement range: 35℃~42.9℃ Internal relay Wiegand input/output Alarm Yes(external available)
- Page 3 1. Alarm temperature setting: Press key “M” one time, the display will show 1. 37.5, meaning the default high temperature value is 37.5℃, press key “+/-“ to adjust the target high temperature 2. Temperature compensation value setting: Press key “M” twice, the display will show 2. 0.0, press key “+/-“...
- Page 4 IM3 connection diagram Connection descriptions: Connection A: 1. GND: GND input 2. D2 OUT：wiegand output 3. D2 IN：wiegand input 4. GND：GND input 5. DI OUT：wiegand output 6. D1 IN: wiegand input Connection B: 1. NO IN：Relay input 2. NO OUT：Relay output 3.
- Page 5 #24, Shambavi Building, 23rd Main, Marenahalli, JP Nagar 2nd Phase, Bengaluru - 560078 Phone : 91-8026090500 | Email : sales@esslsecurity.com www.esslsecurity.com...
