1x1 HDMI Signal Manager 1. Introduction CVHH2 is a 1x1 HDMI signal manager supports HDMI2.0&HDCP2.2. It is designed to enhance the compatibility between HDMI source and display. The high-definition HDMI signal can be transmitted from HDMI source to match all kinds of display device. - Page 5 Illuminate red when powered on ② Connect with HDMI/ DVI source ③ DC 5V Micro USB power port, insert DC 5V 1A power adapter ④ Connect with HDMI/ DVI display Pictures shown in this manual are for reference only. Altimium www.altimium.com...
-
Page 6: System Connection
HDTV HDMI Signal: Step1. Connect a HDMI source (e.g. a Blu-ray DVD) to IN port of CVHH2; Step2. Connect a HDMI display (e.g. a Blu-ray DVD) to OUT port of CVHH2; Step3. Plug DC 5V 1A power adapter into the power port of CVHH2. -
Page 7: Specification
4.1 Supported Resolution 3840*2160, 4096*2160（30Hz/60Hz） 16:9 1920*1080, 1600*900, 1366*768, 1280*720, 1024*576（60Hz） 16:10 1920*1200, 1680*1050, 1440*900, 1360*768, 1280*800（60Hz） 1600*1200, 1400*1050, 1280*1204, 1024*768, 800*600, 640*480 （60Hz） 21:9 2560*1080（30Hz/60Hz） Use quality HDMI cable to connect the devices to ensure preferred transmission effect. Altimium www.altimium.com... - Page 8 1x1 HDMI Signal Manager 5. Panel Drawing 45.50 mm CVHH2 Altimium www.altimium.com...
-
Page 9: Troubleshooting And Maintenance
No output on the display Poor contact of HDMI ports by one to make sure they’re in well contact. If your problem persists after following the above troubleshooting steps, seek further help from authorized dealer or our technical support. Altimium www.altimium.com... -
Page 10: After Sales Service
Product version and name. Detailed failure situations. The formation of the cases. Remarks: For any questions or problems, please try to get help from your local distributor. Altimium www.altimium.com... - Page 12 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
