Owner's Manual &
Safety Instructions
Model
HC023B
20V/120V 2 Gallon Wet/Dry Portable Vacuum with HEPA Filter
Battery and Charger sold separately.
WARNING:
To prevent serious injury,
User must read and
understand Owner's Manual. SAVE THIS MANUAL.
When unpacking, make sure that the product is intact and
undamaged. If any parts are missing or broken, please call
1-888-866-5797 as soon as possible. Reference 56789.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HC023B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hercules HC023B

Summary of Contents for Hercules HC023B

  • Page 1 Owner’s Manual & Safety Instructions Model HC023B 20V/120V 2 Gallon Wet/Dry Portable Vacuum with HEPA Filter Battery and Charger sold separately. WARNING: To prevent serious injury, User must read and understand Owner’s Manual. SAVE THIS MANUAL. When unpacking, make sure that the product is intact and undamaged.

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 15. Stay alert, watch what you are doing and use INSTRUCTIONS PERTAINING TO A common sense when operating an appliance. Do not RISK OF FIRE, ELECTRIC SHOCK, use an appliance while you are tired or under the OR INJURY TO PERSONS influence of drugs, alcohol or medication.

  • Page 3: Grounded Tools: Tools With Three Prong Plugs

    h. Follow all charging instructions and do e. Li-Ion BATTERY MUST BE RECYCLED not charge the battery pack or appliance OR DISPOSED OF PROPERLY. outside of the temperature range specified SAVE THESE in the instructions. Charging improperly or at temperatures outside of the specified range may INSTRUCTIONS damage the battery and increase the risk of fire.

  • Page 4: Double Insulated Tools: Tools With Two Prong Plugs

    8. Protect the extension cords from sharp objects, Double Insulated Tools: Tools excessive heat, and damp or wet areas. with Two Prong Plugs TABLE A: RECOMMENDED MINIMUM WIRE GAUGE FOR EXTENSION CORDS* (120/240 VOLT) EXTENSION CORD NAMEPLATE LENGTH AMPERES 25´ 50´...

  • Page 5: Specifications

    SPECIFICATIONS Gulper Nozzle Exhaust/Blower Power Switch Power Battery Type Hercules 20V Li-ion (sold separately) Cord Input Power 120VAC / 3.2A / 60Hz SETUP - BEFORE USE: Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning...

  • Page 6: Vacuum Operation

    7. Replace the Motor Housing assembly OPERATING INSTRUCTIONS and close both Latches. Clean external surfaces of the tool with clean and dry cloth. Store the tool indoors out of children′s reach. Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the 8.

  • Page 7: Removing Battery Pack

    5. All parts are permanently lubricated. USER-MAINTENANCE Do not use additional lubrication. AND STORAGE 6. AFTER EACH USE, empty and clean the Tank. Procedures not specifically explained 7. Li-Ion BATTERY MUST BE RECYCLED OR in this manual must be performed DISPOSED OF PROPERLY.

  • Page 8: Troubleshooting

    Troubleshooting Problem Possible Causes Likely Solutions Tool will not start. 1. Cord not connected. 1. Check that cord is plugged in. 2. No power at outlet. 2. Check power at outlet. If outlet is unpowered, turn off tool and check circuit breaker. If breaker is tripped, make sure circuit is right capacity for tool and circuit has no other loads.
  • Page 9 Problem Possible Causes Likely Solutions Excessive noise Internal damage or wear. (Motor Have technician service tool. or rattling. or bearings, for example.) Low suction. 1. Dirty Filter. 1. Clean Filter and Tank. 2. Extension cord too long or cord 2. Eliminate use of extension cord. If an diameter too small.

  • Page 10: Please Read The Following Carefully

    PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.

  • Page 11: Assembly Diagram

    Assembly Diagram Item 56789 For technical questions, please call 1-888-866-5797. Page 11...

  • Page 12: Limited 90-Day Warranty

    LIMITED 90 DAY WARRANTY Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
