Genlantis TempZAP ETZT100 Manual

Catalog # Description/Content
ETZT100 TempZAP™ Automatic
Infrared Thermometer

INTRODUCTION

The TempZAP™ Automatic Infrared Thermometer with 12 to 1 distance-to-sight ratio and
temperature alarm offers fast response and high accuracy. Advanced features include high and
low temperature alerts, adjustable temperature alert limit, 100 memory bank, automatic
temperature readings, auto power-off. Careful use of this meter will provide years of reliable
service.
The TempZAP™ Automatic Infrared Thermometer is the ultimate in convenient, safe, accurate,
and fast temperature monitoring. The provided tripod stand makes setup and placement of the
thermometer very easy and convenient.
1 Voice on/off switch 4
2 Page down 5
3 Page up 6

Key Features

12:1 Distance-to-sight ratio
1% basic accuracy
Rapid detection function
Precise noncontact measurements
Automatic power off
Low and High temp alerts (visual and audible)
Backlit LCD
Automatic data hold
User-selectable °C or °F units
Adjustable temperature alert settings
Contents
1. TempZAP Thermometer
2. Tripod stand
3. USB-A/USB-C power cable
4. Wall installation kit
OFF
ON
10 11
9
°F/°C selection button
Speaker
LCD screen
Automatic Infrared Thermometer
Related Products
FirstResponder® Sterilizer, 110V
FirstResponder® Handheld Sterilizer
FirstResponder® Portable Sterilizer (cordless)
SteriZAP™ UV-C Room Sterilizer, 110V
12
8
7 Infrared sensor
8 Battery compartment
9 ¼ inch tripod connector

Specifications

Measurement method
Measurement distance (min.)
Measurement range
Operating Temperature
Memory size
Automatic power off
Power modes
TempZAP Thermometer weight
TempZAP Thermometer size
Tripod Range
6
1 2 3 4
5
10 On/Off switch
11 USBC power input
12 Wall hanging port
Infrared, no-contact
3 inches (8 cm)
32-122°F (0-50°C)
50-104°F (10-40°C)
100 measurements
30 seconds
USB 5V or 2 x AAA batteries (3V)
6.4 oz (180 grams)
6.7 x 4.0 x 1.32 in. (170 x 100 x 5 mm)
27-84 inches (0.7-25.13 meters)
Catalog #
E4110FRS
E600UVCH
E600UVCP
E500UVCT
7
