Operating Instructions
LED TV
Thank you for purchasing this Panasonic product.
Please read these instructions carefully before operating this product and
retain them for future reference.
Please carefully read the "Safety Precautions" of this manual before use.
The images shown in this manual are for illustrative purposes only.
M0116-0
Australia
TH-55DX640A TH-55DX640Z
TH-65DX640A TH-65DX640Z
For more detailed instructions, please refer to
[eHELP] (Built-in Operating Instructions).
●
How to use [eHELP]
Model No.
New Zealand
(p. 15)
TQB4GC1531
English
Advertisement
Table of Contents
Related Manuals for Panasonic Viera TH-55DX640A
Summary of Contents for Panasonic Viera TH-55DX640A
- Page 1 ● How to use [eHELP] (p. 15) Thank you for purchasing this Panasonic product. Please read these instructions carefully before operating this product and retain them for future reference. Please carefully read the “Safety Precautions” of this manual before use.
-
Page 2: Table Of Contents
● For information about the trademarks, refer to [eHELP] (Support > Licence). The illustration for TH-55DX640A is used in this manual unless otherwise mentioned. Illustrations shown may be different between models and countries. Contents Be Sure to Read Important Notice··················································· 3 Safety Precautions ···············································... -
Page 3: Important Notice
Panasonic has no authority to and does not grant you that permission and explicitly disclaims any right, ability or intention to obtain such permission on your behalf. -
Page 4: Safety Precautions
● Do not use an unapproved pedestal / mounting plug. equipment. Be sure to ask your local Panasonic dealer to perform the setup or installation of approved wall-hanging brackets. ● Do not apply any strong force or impact to the display ●... - Page 5 Do not use the pedestal if it becomes warped or Caution physically damaged. If this occurs, contact your nearest Panasonic dealer immediately. Allow sufficient space (at least 10 cm) around the TV in order to help prevent excessive heat, which could lead ●...
-
Page 6: Accessories
■ Accessories Battery for the Remote Control Caution ● Incorrect installation may cause battery leakage, corrosion and explosion. ● Standard accessories Replace only with the same or equivalent type. ● Do not mix old and new batteries. Remote Control ● Do not mix different battery types (such as alkaline (p. - Page 7 Base ■ Assembling the pedestal ■ Preventing the TV from falling over It is recommended to secure the pedestal to a furniture as shown to prevent the TV from falling over. ● This information is designed to reduce the risk of injuries caused by the TV falling over.
-
Page 8: Connections
Connections ● External equipment and cables shown are not supplied with this TV. ● Please ensure that the unit is disconnected from the mains socket before attaching or disconnecting any cables. ● Check the terminal type and cable plugs are correct for connection. - Page 9 2 HDMI3 the correct connection cable and plug between the wall aerial socket and the TV. 3 AV IN (COMPONENT / VIDEO) (p. 10, 10) ● Your local Television Service Centre or dealer may 4 ETHERNET terminal (p. 10) be able to assist you in obtaining the correct aerial 5 Aerial terminal (p.
- Page 10 1. Select the HDMI input mode connected to the Network equipment. A broadband network environment is required to be able 2. Display the menu and select [HDMI Auto Setting] to use internet services. (Setup Menu). ● If you do not have any broadband network services, ●...
- Page 11 ■ Amplifier (listening with external speakers) ● Use HDMI2 to connect the TV to an amplifier which has ARC (Audio Return Channel) function. If connecting to an amplifier without ARC function, use DIGITAL AUDIO OUT. ● To enjoy multi-channel sound from external equipment (e.g.
-
Page 12: Identifying Controls
Identifying Controls 7 OK ● Confirms selections and choices. ● Press after selecting channel positions to quickly change channel. ● Displays channel list. Remote Control 8 [Option Menu] ● Easy optional setting for viewing, sound, etc. 9 Coloured buttons (red-green-yellow-blue) ●... - Page 13 ■ Installing / Removing batteries 6 Volume Up / Down ● Cursor Left / Right (when in the menu system) 7 Mains power On / Off switch Pull open ● Use to switch the mains power. ● To turn Off the apparatus completely, you must pull Hook the mains plug out of the mains socket.
-
Page 14: First Time Auto Tuning
First time Auto Tuning Tick the TV signal mode to tune, and then select [Start Auto Tuning] : tune (search for the available channels) : skip tuning When the TV is turned on for the first time, it will automatically search for available TV channels and give Select your region (Satellite) New Zealand options to set up the TV. -
Page 15: Watching
Watching TV How to Use eHELP [eHELP] is the detailed operating instructions built into Turn power on the TV, and gives a more detailed explanation for a better understanding of the operation of each feature. (TV) Display [eHELP] (Remote Control) ●... -
Page 16: Faqs
FAQs ● Parts of the TV may become hot. These temperature rises do not pose any problems in terms of performance or quality. Before requesting service or assistance, please follow When pushed with a finger, the display panel moves these simple guides to solve the problem. slightly and makes a noise ●... -
Page 17: Maintenance
Maintenance Specifications ■ First, remove the mains plug from the mains socket. Model No. : TH-55DX640A, TH-55DX640Z Display panel, Cabinet, Pedestal 55-inch model : TH-65DX640A, TH-65DX640Z 65-inch model Regular care: Dimensions (W × H × D) Gently wipe the surface of the display panel, cabinet, or pedestal by using a soft cloth to remove dirt or 55-inch model fingerprints. - Page 18 Connection terminals M.NTSC AV IN (COMPONENT / VIDEO) Playback from M.NTSC Video recorders (VCR) VIDEO RCA PIN Type × 1 NTSC 1.0 V[p-p] (75 ) Playback from NTSC Video recorders (VCR) AUDIO L - R RCA PIN Type × 2 Satellite dish input 0.5 V[rms] New Zealand...
- Page 19 ■ When using the wall-hanging bracket Choosing to wall mount the TV shall be done at the owner’s risk. Always use a qualified installer to perform a TV wall bracket installation. Incorrect fitting may cause equipment to fall, resulting in injury and product damage. Any such damage will void your warranty.
- Page 20 If there is a major failure in regard to the product which cannot be remedied then you must notify us within a reasonable period by contacting the Panasonic Customer Care Centre. If the failure in the product is not a major failure then Panasonic may choose to repair or replace the product and will do so in a reasonable period of time from receiving notice from you.
- Page 21 New Zealand WARRANTY - New Zealand only NEW ZEALAND Distributed in New Zealand by Panasonic New Zealand Limited 350 Te Irirangi Drive East Tamaki, Private Bag 14911, Panmure Auckland Tel. 09 272 0100 Customer Care Center Email: Customerservice@nz.panasonic.com www.panasonic.co.nz Warranty Information on Disposal in other Countries outside the European Union This symbol is only valid in the European Union.
