USER MANUAL
ENGLISH
VT101 - HDMI Matrix Switcher 4x4
V1
Product code: 101221
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VT101 and is the answer not in the manual?

Questions and answers

Summary of Contents for DMT VT101

  • Page 1 USER MANUAL ENGLISH VT101 - HDMI Matrix Switcher 4x4 Product code: 101221 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
  • Page 2 VT101 - HDMI Matrix Switcher 4x4 Preface Thank you for purchasing this DMT product. The purpose of this user manual is to provide instructions for the correct and safe use of this product. Keep the user manual for future reference as it is an integral part of the product. The user manual shall be stored at an easily accessible location.

  • Page 3: Table Of Contents

    VT101 - HDMI Matrix Switcher 4x4 Table of contents Introduction ................................3 Before Using the Product ..........................3 Intended Use ............................... 3 Product Lifespan ..............................4 Text Conventions ..............................4 Symbols and Signal Words ..........................4 Symbols on the Information Label ........................4 Safety ..................................

  • Page 4: Introduction

    After unpacking, check the contents of the box. If any parts are missing or damaged, contact your Highlite International dealer. Your shipment includes: ● DMT VT101 - HDMI Matrix Switcher 4x4 ● 1x IR remote control ● 1x DC Power Adapter (input 100-240VAC, Output 12V 2A) (1,1 m) ●...

  • Page 5: Product Lifespan

    VT101 - HDMI Matrix Switcher 4x4 Product Lifespan This device is not designed for permanent operation. Disconnect the device from the electrical power supply when the device is not in operation. This will reduce the wear and will improve the device’s lifespan.

  • Page 6: Safety

    VT101 - HDMI Matrix Switcher 4x4 Safety Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual.

  • Page 7: Requirements For The User

    VT101 - HDMI Matrix Switcher 4x4 Attention General safety ● Do not insert objects into the air vents. ● Do not switch the device on and off in short intervals. This decreases the device’s life. ● Do not shake the device. Avoid brute force when installing or operating the device.

  • Page 8: Description Of The Device

    An HDMI switch or splitter could never give the same functionality or flexibility. The DMT VT101 supports resolutions up to 3840 x 2160 p @ 60 Hz. Indicators at the front of the unit display the current routing status for a clear overview of your output signals.

  • Page 9: Product Specifications

    VT101 - HDMI Matrix Switcher 4x4 Product Specifications Model: VT101 - HDMI Matrix Switcher 4x4 Electrical: Input voltage: 100–240 V AC, 50/60 Hz Power consumption: 15 W Power supply 12V DC / 2A Physical: Dimensions: 276 x 135 x 26 mm (LxWxH)

  • Page 10: Installation

    VT101 - HDMI Matrix Switcher 4x4 Installation Installation Site Requirements The device must be installed only indoors. The device can be positioned on a flat surface. The maximum ambient temperature t = 40 °C must never be exceeded. The relative humidity must not exceed 50 % with an ambient temperature of 40 °C.

  • Page 11: Setup

    VT101 - HDMI Matrix Switcher 4x4 Setup Warnings and Precautions Attention Connect all data cables before supplying power. Disconnect power supply before connecting or disconnecting data cables. Setup Example Fig. 06 Product code: 101221...

  • Page 12: Operation

    VT101 - HDMI Matrix Switcher 4x4 Operation The device can be operated with a remote control or the dipswitches. Manual operation can be done using: ● the dipswitches, or ● the remote control. Safety Instructions for Operation Attention This device must be used only for the purposes it is designed for.
  • Page 13 VT101 - HDMI Matrix Switcher 4x4 To install the batteries: Press on one side of the remote and open the battery housing (Fig. 08). Remove the entire battery holder bracket (Fig. 09). Make sure that you’ve got the polarity of the battery correctly (Fig. 10).

  • Page 14: Dipswitch Setting

    VT101 - HDMI Matrix Switcher 4x4 Button Function Description Back Return to the last input port. Forward Forward to the next input port. Input 1 Press the button to switch to Input 1. Input 2 Press the button to switch to Input 2.

  • Page 15: Rs232 Commands

    VT101 - HDMI Matrix Switcher 4x4 RS232 Commands Command Feedback Description cir 1e\r\n 63 69 72 20 31 65 0D 0A s1x\r\n Output 1 select input port No.+1 "x"value range 0~3 cir 1d\r\n 63 69 72 20 31 64 0D 0A s1x\r\n Output 1 select input port No.-1...

  • Page 16: Troubleshooting

    VT101 - HDMI Matrix Switcher 4x4 Troubleshooting This troubleshooting guide contains actions which can be carried out by the user. The device does not contain user-serviceable parts. Unauthorized modifications to the device will render the warranty void. Such modifications may result in injuries and material damage.

  • Page 17: Maintenance

    VT101 - HDMI Matrix Switcher 4x4 Maintenance Safety Instructions for Maintenance Maintenance and cleaning shall be carried out only by instructed persons. Follow the maintenance schedule established for the site where the electrical enclosure is installed. Disconnect power supply before servicing or cleaning.

  • Page 18: Deinstallation, Transportation And Storage

    VT101 - HDMI Matrix Switcher 4x4 Deinstallation, Transportation and Storage ● Disconnect power supply before deinstallation. ● Use the original packaging to transport the device, if possible. ● Always observe the handling instructions printed on the outer carton box, for example: “Handle with care”, “This side up”, “Fragile”.

  • Page 19: Disposal

    VT101 - HDMI Matrix Switcher 4x4 Disposal Correct disposal of this product Disposal of Old Electrical and Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems) This symbol on the product, its packaging or documents indicates that the product shall not be treated as household waste.

  • Page 20: Approval

    VT101 - HDMI Matrix Switcher 4x4 Approval Check the respective product page on the website of Highlite International (www.highlite.com) for an available declaration of conformity. Product code: 101221...
  • Page 21 VT101 - HDMI Matrix Switcher 4x4 Product code: 101221...
  • Page 22 VT101 - HDMI Matrix Switcher 4x4 Product code: 101221...
  • Page 23 VT101 - HDMI Matrix Switcher 4x4 Product code: 101221...
  • Page 24 ©2021 DMT...
