C4i GEN-1 Quick Operation Manual

Mini hdmi signal generator and display emulator
Hide thumbs
1
2
3
4
5

Advertisement

Quick Links

Download this manual
C4i
Consultants for Industry
C4i
ul. Batalionu Platerówek 3, bud. B-7, I p.
03-308 Warszawa, Polska
+48 22 398 33 42, +48 22 390 62 36
biuro@c4i.com.pl c4i.com.pl
The GEN-1 is a portable mini HDMI signal generator and display emulator (signal analyzer), two functions combine into a compact
size chassis. This is very useful for AV installers or testers; When work as signal generator, it can generate 4 signals, max
resolution up to 4K@60Hz, 4:4:4, also can analyze the HDCP content, there is a 4 pin DIP switcher to control this; When work as a
display emulator, it also can analyze the HDCP content and signal status (5V, TMDS). The LEDs will show the signal or HDCP
status.
Features
 Used as HDMI signal generator or display emulator (signal analyzer).
 Provides 4-pin DIP switch for setting video resolution and HDCP content.
 Supports 4K@60Hz 4:4:4, 4K@60Hz 4:2:0, 4K@30Hz 4:4:4, or 1080p@60Hz video signal output.
 Supports HDCP OFF, HDCP 1.4 or HDCP 2.2 output.
 Supports four different test patterns for HDCP version.
 LEDs show signal and HDCP status.
Packing List
 1x GEN-1 Mini HDMI Signal Generator
 1x USB Power Cord
 1x Brown Cloth Bag
 1x User Manual
Quick Operation Guide
GEN-1
Mini HDMI Signal Generator and Display Emulator

Advertisement

loading
Need help?

Need help?

Do you have a question about the GEN-1 and is the answer not in the manual?

Questions and answers

Related Manuals for C4i GEN-1

Summary of Contents for C4i GEN-1

  • Page 1 Mini HDMI Signal Generator and Display Emulator The GEN-1 is a portable mini HDMI signal generator and display emulator (signal analyzer), two functions combine into a compact size chassis. This is very useful for AV installers or testers; When work as signal generator, it can generate 4 signals, max resolution up to 4K@60Hz, 4:4:4, also can analyze the HDCP content, there is a 4 pin DIP switcher to control this;...

  • Page 2: Product Description

     When the GEN-1 is used as a HDMI signal generator, the LED turns red when there is HDMI signal output.  When the GEN-1 is used as a display emulator, the LED turns green when only 5V signal is detected, or turns red when 5V and TMDS signals are detected simultaneously, or off when no HDMI signal input.

  • Page 3: System Diagram

    Switch Status (1 & 2) EDID 4K@60Hz 4:4:4, 2CH PCM 4K@60Hz 4:2:0, 2CH PCM 4K@30Hz 4:4:4, 2CH PCM 1080p@60Hz/3D, 2CH PCM Switch Status (3 & 4) HDCP Test Pattern HDCP 2.2 Red Screen HDCP 1.4 Green Screen HDCP OFF Blue Screen HDCP OFF AlternateWB System Diagram...

  • Page 4: Specifications

    Specifications Connectors Input (1) HDMI IN Input Connector (1) 19-pin type-A male HDMI Output (1) HDMI OUT Output Connector (1) 19-pin type-A male HDMI Power Connector (1) Micro-USB Control (1) 4-pin DIP switch General Input Video Resolution Up to 4K@60Hz 4:4:4 8bit Supports 4K@60Hz 4:4:4, 4K@60Hz 4:2:0, 4K@30Hz 4:4:4, and 1080p@60Hz to Output Video Resolution be selected.
  • Page 5 Skład – Tomasz Bujnowski 16-11-2020 Poniedziałek...
