- Page 1 Operator’s Manual Models: 8G, 10G, 12G Pure & Secure LLC. 4511 NW 42nd St • Lincoln, NE 68524 USA Tel: 402.467.9300 • Toll Free in the USA: 800.875.5915 • Fax: 402.467.9393 www.MyAquaNui.com...
-
Page 2: Table Of Contents
Table of Contents Important Safety Information ..............3 Introduction ....................4 Record Important Information ..............4 Included With Your Distiller ................ 4 Getting to Know Your AquaNui Distiller ............. 5 How Your Distiller Works ................6 Installation Storage Tank and Optional Pump ............7 Unpacking and Installing the AquaNui Distiller ........ -
Page 3: Important Safety Information
Important Safety Information If you are not sure that your electrical outlet is properly grounded or that the cir- • cuit protection is correct, have it checked by a quali ed electrician. Operate indoors only. • The area MUST be well ventilated. •... -
Page 4: Introduction
Congratulations on purchasing the nest home water distillation system on the mar- ket. With proper care and attention, the Pure Water AquaNui will give you many years of top performance and high-quality drinking water. Please read this manual thor- oughly before installing and operating your Pure Water AquaNui. -
Page 5: Getting To Know Your Aquanui Distiller
Getting to Know Your AquaNui Distiller Cooling Fan Power Cord Receptacle Power/Fan Switches Raw Water Valve VOC Pre lter Overtemperature Reset Boiling Tank Drain Storage Tank 5 Gallon, 10 Gallon, or 15 Gallon (Shown) Distilled Water Spigot Pump Outlet Legs Adjustable Feet... -
Page 6: How Your Distiller Works
1500 Watt Heating Element ........approximately 12 gallons per day. The Pure Water AquaNui is a fully automatic unit. The water level in the boiling tank is controlled by a oat and microswitches and the storage tank is controlled by level sensing probes. -
Page 7: Installation
Installation Things to consider when installing your Pure Water AquaNui : Special Feature Select an area that will allow the distiller to remain level. (The feet are adjust- • able to help level the unit.) Improper leveling could aff ect the production rate. -
Page 8: Unpacking And Installing The Aquanui Distiller
Once the storage tank and distiller are Pump Installation Diagram completely connected and installed, connect 3/8” tubing to the outlet of the pump and run the tubing to the desired location. Note: Do not plug the pump into the wall outlet until the storage tank is full of water. -
Page 9: Connecting The Raw Waterline
Note: The use of soft ened water for the raw water supply is recommended to minimize scale build-up in the boiling tank and drain valve. Note: The Pure Water AquaNui comes standard with a saddle tapping valve. In some areas a saddle tapping valve may not be permitted. In such instances, contact your authorized AquaNui Sales Associate, Pure &... -
Page 10: Connecting The Power Cord
3. Connect the 5” piece of tubing to the outlet of the Carbon Filter. 4. Connect the remaining 1/4” tubing to the saddle tapping valve. 3. Connect the 1/4” tubing from the saddle tapping valve to the inlet of the carbon ... -
Page 11: Maintenance And Cleaning
1. Turn the main power switch to ON. Power Switch (ON) 2. Open the faucet on the storage tank and place a cup or small bucket under the faucet. 3. Turn the fan switch to OFF. This will start a “Steam Sterilization” cycle. -
Page 12: Changing The Pre Filter
Important Note: If the unit is hot, turn the power OFF and allow it to cool before draining the boiling tank. 1. Turn the Power Switch to OFF. 2. Turn the valve on the back of the AquaNui and allow the residue to drain into a sink, drain or bucket. -
Page 13: Tank Sterilizing
8. If needed, use a wet/dry vacuum to remove any remaining debris from the tank. 9. Rinse the inside of the tank with fresh water. 10. Reinstall the boiling tank and turn the power ON. When Needed: Sterilize the Storage Tank Sterilizing Steam Sterilization is a method of disinfecting your storage tank. -
Page 14: Troubleshooting
Troubleshooting The machine will not operate at all. Note: The water level in the storage tank must be below 3/4 full before the distiller will start. • Make sure the power cord is plugged into the wall outlet and inserted fully into the “Power Cord Plug”... - Page 15 The boiling tank lls to normal operating level, but the heating element will not heat or bring water to a boil. • If the heater reset is not popped or the fan is running and the boiling tank is full of water, you may have a defective heating element.
-
Page 16: Aquanui Distiller Parts List
Aqua-Nui Distiller Parts List Item # 100V 120 V 240V Description 21005 21005 21005 PANEL, TOP, AQUANUI 9029 9029 9029 SCREW, #10-16 X 1/2”, SHT.MTL. 9019 9019 9019 SCREW, #8-32 X 3/4”,PHD, PLPS 9342 9342 9342 GUARD, FAN, 6”, METAL 9344BJ 9344B 9344B... -
Page 17: Aquanui Distiller Exploded View
AquaNui Distiller Exploded Drawing... -
Page 18: Storage Tank And Pump Parts List
Storage Tank and Pump Parts List Item # 100V 120 V 240V Description 21508-02 21508-02 21508-02 TANK, STORAGE, STUDDED, 5 GAL 21509-02 21509-02 21509-02 TANK, STORAGE, STUDDED, 10 GAL 21510-02 21510-02 21510-02 TANK, STORAGE, STUDDED, 15 GAL 21016-01 21016-01 21016-01 LEG, STORAGE TANK, ULTIMA 2 9039 9039... -
Page 19: Storage Tank And Pump Exploded View
Storage Tank and Pump Exploded Drawing Optional Pump Kit... - Page 20 ©2013, Pure & Secure LLC US and Foreign Patents Pending Form# 21038...
