2-in-1 Convertible Crib
KSN No:
950008441890
NOTE:
THIS INSTRUCTION BOOKLET
CONTAINS
IMPORTANT SAFETY
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
Lot number:
(TAKEN FROM CARTON)
_____________________________________
Date of purchase:
_______ / _______ / _______
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our
customer service department. We will replace the
part FREE of charge.
NEED HELP!
Tel #: 1-800-295-1980
CALL US FOR ASSISTANCE
E-Mail: das@dorel.com
1-800-295-1980
Fax #: 514-353-7819
DO NOT RETURN PRODUC
E-MAIL:DAS@DOREL.COM
Advertisement
Table of Contents
Related Manuals for Baby Relax DA7427B2
Summary of Contents for Baby Relax DA7427B2
- Page 1 DOREL ASIA Model No: DA7427B2 (BLACK) UPC CODE: 0-65857-17265-2 2-in-1 Convertible Crib KSN No: 950008441890 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Lot number: (TAKEN FROM CARTON) _____________________________________ Date of purchase: _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE.
- Page 2 CUSTOMER SERVICE If you are missing parts or have any questions about this product, contact our customer service representative first! CALL 1-800-295-1980 You can also order parts by writing to the address listed below. Please include the product model number, color and a detailed description of the part.
-
Page 3: Care And Cleaning
NOTES * Ensure all parts and components are present before beginning assembly. * Assemble on a soft, smooth surface to prevent damage to product finish. * DO NOT use power tools. * CAUTION: Adult assembly required. * Assembly will require two people. * Estimated assembly time: 60 minutes. -
Page 4: Hardware List
2-in-1 Convertible Crib DA7427B2 HARDWARE LIST Ø1/4" X 13mm X 35mm Ø1/4" X 13mm X 55mm BOLT BOLT 4 PCS 10 PCS Ø1/4" X 13mm X 75mm Ø1/4" X 13mm X 60mm BOLT BOLT 8 PCS 2 PCS Ø8 X 30mm Ø1/4"... -
Page 5: Parts List
2-in-1 Convertible Crib DA7427B2 PARTS LIST FRONT POST BACK POST BACK PANEL 2 PCS 2 PCS 1 PC SIDE PANEL TOP RAIL FRONT PANEL 2 PCS 2 PCS 1 PC FRONT RAIL MATTRESS SUPPORT 1 PC 1 PC... - Page 6 2-in-1 Convertible Crib DA7427B2 CRIB ASSEMBLY INSTRUCTION NOTE: When inserting bolts, turn clockwise until tight. Then loosen 1/2 - 3/4 of a turn. After crib is completely assembled, return to each bolt and tighten. Use wax or soap on all bolts to facilitate assembly.
- Page 7 2-in-1 Convertible Crib DA7427B2 STEP 1 Attach top rails (E) to the side panels (D) as shown below. NOTE: The side panels (D) and top rails (E) are labeled "INSIDE". To ensure proper assembly, the side panel (D) and top rails (E) must be assembled facing the same side.
- Page 8 2-in-1 Convertible Crib DA7427B2 STEP 2 Insert wood dowels (5) into the top rail (E). Insert barrel nuts (6) into the side panel (D). Attach left front post (A1) and left back post (B1) to the side panel (D) and top rail (E) with bolts (1 &...
- Page 9 2-in-1 Convertible Crib DA7427B2 STEP 3 Insert barrel nuts (6) into the back panel (C). Attach back panel (C) to the left and right back posts (B1 & B2) with wood dowel (5) and bolts (3). Use Allen key (7) to tighten the bolts.
- Page 10 2-in-1 Convertible Crib DA7427B2 STEP 4 Insert barrel nuts (6) into the front rail (G) as shown below. Attach front rail (G) to the left and right front posts (A1 & A2) with bolts (3) using Allen key (7). Note: Do not fully tighten the bolts. Loose bolts will facilitate assembly in the following steps.
- Page 11 2-in-1 Convertible Crib DA7427B2 STEP 5 Attach mattress support (H) to the posts (A1, A2, B1 and B2) with mattress support bolts (8) using Allen key (7). CORRECT CORRECT "THIS SIDE UP" Tabs on corners of label shows which mattress support should side to face point up.
- Page 12 2-in-1 Convertible Crib DA7427B2 STEP 6 Insert wood dowels (5) into the left and right front post (A1 & A2). Insert barrel nuts (6) into the front panel (F). Attach front panel (F) to the front posts (A1 & A2) with bolts (3) and bolts (2) as shown.
- Page 13 2-in-1 Convertible Crib DA7427B2 STEP 7 Attach front rail (G) to the front panel (F) with bolts (4) using Allen key (7).
- Page 14 2-in-1 Convertible Crib DA7427B2 WARNINGS: * CAUTION- ANY MATTRESS USED IN THIS CRIB MUST BE AT LEAST 27-1/4 INCHES BY 51-5/8 INCHES (69CM BY 131CM) WITH A THICKNESS NOT EXCEEDING 6 INCHES (15CM). * The day bed is not intended for children under 15 months of age or over 50 lbs (22.7 kgs).
- Page 15 2-in-1 Convertible Crib DA7427B2 CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. ANY MATTRESS USED IN THIS CRIB...
-
Page 16: Customer Service
MODEL #: DA7427B2 Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819...
