- Page 1 (Hotplate) Magnetic Stirrer User Manual RSM-10HS/HP LED Digital Hotplate Magnetic Stirrer RSM-10P LED Digital Magnetic Stirrer Please read the User Manual carefully before use, and follow all operating and safety instructions! www.phoenix-instrument.de 12300174...
-
Page 2: Table Of Contents
Contents Preface ................. 1 Service ................. 1 Warranty ................1 Safety Instructions ............2 Proper Use ..............3 Inspection ..............4 3.1 Receiving Inspection ..........4 3.2 Listing of Items ............. 4 Control ................. 4 4.1 Control elements ............ 4 4.2 Display.............. -
Page 3: Preface
Department of manufacturer for technical support in the Warranty following ways: This instrument is warranted to be free from defects in Phoenix Instruments GmbH materials and workmanship under normal use and service, Heinkelstr. 10 for a period of 24 months from the date of invoice. The 308927 Garbsen/Germany warranty is extended only to the original purchaser. -
Page 4: Safety Instructions
BlueSpin (Hotplate) Magnetic Stirrer substances or under water. 1. Safety Instructions • Gradually increase the speed, reduce the speed if: - Stirring bar breaks away due to high speed Warning! • - The instrument is not running smoothly, or container Read the operating instructions carefully moves on the base plate before use. -
Page 5: Proper Use
BlueSpin (Hotplate) Magnetic Stirrer • The instrument can only be disconnected from the main power supply by pulling out the main or the connector plug. • The voltage stated on the label must correspond to the >100mm main power supply. •... -
Page 6: Inspection
BlueSpin (Hotplate) Magnetic Stirrer 3. Inspection 4. Control 3.1 Receiving Inspection 4.1 Control elements Unpack the equipment carefully and check for any damages which may have arisen during transport. Please contact Probe manufacturer/supplier for technical support. ( Hotplate model ) Note: If there is any apparent damage to the system, please do not plug it into the power line. - Page 7 BlueSpin (Hotplate) Magnetic Stirrer LED Display Speed Control Knob Speed Control Knob Figure 4 Classic model Figure 3 Digital model Figure 5...
- Page 8 BlueSpin (Hotplate) Magnetic Stirrer Items Descriptions Set the temperature parameters. The function “heating” is switched ON or Temperature Control Knob Heat OFF via push ON/OFF knob. Set the rotary speed. The function “Stirring” is switched ON or OFF via Speed Control Knob Stir push ON/OFF knob.
-
Page 9: Display
4.2 Display Speed display area Temperature display area Speed display area Figure 7 Digital model Figure 6 Digital hotplate model Characters Descriptions Speed display When stirring function was switched Characters Descriptions area ON, LED displays the speed setting Temperature When heating function was switched ON, value and flashes. -
Page 10: Trial Run
5. Trial Run 6. Function: Heating Digital hotplate model ) • Make sure the required operating voltage and power supply voltage match. The device is controlled by digital temperature control • Ensure the socket must be properly grounded. technology, which has two separate safe circuits. The hotplate is kept at a constant temperature by a digital •... -
Page 11: Working With External Temperature Sensor
Hotplate center and outer edge. heating function will be stopped automatically under The sample in the vessel and hotplate surface. abnormal conditions. Please operate follow the instructions In order to ensure the accuracy of the temperature inside the below: • container, please use the external temperature sensor Switch OFF the instrument. -
Page 12: Stirring
7. Stirring 8. Faults • The function “stirring” of LED digital model is switched on Instruments can’t be power ON - Check whether the power line is unplugged or off via pushing on/off speed control knob. The speed - Check whether the fuse is broken or loose range of 100 to 1500 rpm and in steps of 10 rpm. -
Page 13: Maintenance And Cleaning
• 9. Maintenance and Cleaning If you require maintenance service, must be cleaned the instrument in advance to avoid • Proper maintenance can keep instruments working pollution of hazardous substances, and to properly and lengthen its lifetime. send back into original packing. •... -
Page 14: Specifications
Changes or modifications not expressly approved by the 11. Specifications party responsible for compliance could void the user's Specifications authority to operate the equipment. Items Classic NOTE: This equipment has been tested and found to Digital model model comply with the limits for a Class A digital device, *100~120/200~240 pursuant to Part 15 of the FCC Rules. - Page 15 Specifications Specifications Items Classic Items Classic Digital model Digital model model model Plate material *Ceramic coated/Plastic 220×160×75 Dimensions of Weight [kg] *1.4/0.7 φ135 φ135 workplate (mm) Permitted ambient 5－40 *Heating power [W] temperature [°C] RT-280, Permitted relative *Temperature range [°C] increment:1 humidity *Temperature display...
