Summary of Contents for nvent SCHROFF 60118583
- Page 1 User Manual INSTALLATION AND MAINTENANCE GUIDE 1U Ultra short depth LCD Console Drawer Ultra short depth 400mm / 15.7″ Options : - SDI - HDMI - DC power Item Number 60118-599 nVent.com/SCHROFF...
-
Page 2: Legal Information
Causes external to the product, such as electric power fluctuation or failure. • Use of supplies or parts not meeting our specifications. • Normal wear and tear. • Any other causes which does not relate to a product defect. • Removal, installation, and set-up service charges. nVent.com/SCHROFF... -
Page 3: Regulatory Notices Federal Communications Commission (Fcc)
INSTALLATION AND MAINTENANCE GUIDE Regulatory Notices Federal Communications Commission (FCC) This equipment has been tested and found to comply with the limits for a Class B digital device, pur- suant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 4: Table Of Contents
Supporting layouts ........................15 Keyboard Features ........................15 SUN Keyboard/Mouse Options ....................16 How to Use "S" Keyboard ......................16 On-screen Display Operation (OSD) ..................17 On-screen Display Operation (OSD) ..................18 Options: ............................19 Options: DC Power ........................20 Options: ORB-2.1 - 2-Post Rack Mounting Brackets21 Notes ............................22 nVent.com/SCHROFF... -
Page 5: Before Installation
3. Gently wipe the surface. Use as little pressure as possible. 4. Wait until your monitor is completely dry before plugging it in and powering it up. nVent.com/SCHROFF... -
Page 6: Package Content
Keyboard interchangeable module kit Audio speaker ( for SDI or HDMI option ) Mouse interchangeable module kit The above package content is only for the single console models. It varies with options such as KVM, SDI, HDMI, Touchscreen & DC power. nVent.com/SCHROFF... -
Page 7: Dimension
60118584 17.4 x 15.7 x 1.73" 23.2 x 24.5 x 5.5" 18.9 lb 29.9 lb 60118585 The weight is only for the single console models. It varies with accessories & options such as KVM, SDI, HDMI & DC power. nVent.com/SCHROFF... -
Page 8: Installation - Installation Slides
INSTALLATION AND MAINTENANCE GUIDE Installation - Installation Slides Step 1 • Insert the left and right rear mounting brackets into the LCD console drawer. Step 2 • Measure the depth of the front and rear mounting rails. • Align each rear mounting bracket to a suitable length. -
Page 9: Installation - How To Use The Drawer
INSTALLATION AND MAINTENANCE GUIDE Installation - How to use the drawer • Press the handle button and gently slide out the drawer. • Flip up the LCD to a suitable angle. • Operate the LCD console drawer. -
Page 10: Connection To Usb Server Via Cx-6 Cable
INSTALLATION AND MAINTENANCE GUIDE Connection to USB Server via CX-6 cable LCD Console Drawer Power DVI-D CX-6 DVI-D console cable DVI-D USB server *Monitor keyboard screen in external power Connection to external KVM via CX-6 cable LCD Console Drawer Power DVI-D CX-6 DVI-D console cable... -
Page 11: Connection To Usb Server Via Cb-6 Cable
INSTALLATION AND MAINTENANCE GUIDE Connection to USB Server via CB-6 cable LCD Console Drawer DVI-D CB-6 VGA console cable USB server *Monitor keyboard screen in external power Connection to external KVM via CB-6 cable LCD Console Drawer DVI-D CB-6 VGA console cable USB console KVM *Monitor keyboard screen in external power... -
Page 12: Product Specifications
INSTALLATION AND MAINTENANCE GUIDE Product Specifications 60118583, 60118584, 60118585 Panel Native Resolution 1920 x 1080 Panel Size ( diagonal ) 17.3" Brightness ( cd/m² ) Contrast Ratio ( typ. ) 600:1 Colors 16.7 M, 8-bit Viewing Angle ( L/R/U/D ) 80/80/60/80 Response Time ( ms ) Dot pitch ( mm ) - Page 13 INSTALLATION AND MAINTENANCE GUIDE Environmental Operating Temperature 0 to 55°C degree Conditions Humidity 20~90%, non-condensing Altitude 16,000 ft Storage / Temperature -20 to 60°C degree Non-operating Humidity 5~90%, non-condensing Altitude 40,000 ft Shock 10G acceleration (11ms duration) Vibration 10~300Hz 0.5G RMS random Physical 60118583, 60118584, 60118585 Specification...
-
Page 14: Standard Keyboard / Mouse Specifications
INSTALLATION AND MAINTENANCE GUIDE Standard Keyboard / Mouse Specifications G keyboard integrated with touchpad G keyboard integrated with trackball Key force 55 ± 5g Travelling distance 3 ± 0.3mm Switch life > 10 million life cycle time OS support Windows / Linux / Unix / Mac OS Supporting layouts America United States... -
Page 15: Mac Keyboard/Mouse Options
INSTALLATION AND MAINTENANCE GUIDE MAC Keyboard/Mouse Options MAC keyboard integrated with touchpad MAC keyboard integrated with trackball Supporting layouts America United States *English, German and French as standard. Other layouts on request. How to Use "MAC" Keyboard Keyboard Features Decrease display brightness Fast-forward Increase display brightness Mute sound... -
Page 16: Sun Keyboard/Mouse Options
INSTALLATION AND MAINTENANCE GUIDE SUN Keyboard/Mouse Options S keyboard integrated with touchpad S keyboard integrated with trackball Ca ps Scro ll Comp ose Ca ps Scro ll Comp ose S keyboard integrated with touchpad / trackball ■ Incorporates SUN keys, including Stop, Cut, Paste, Compose, Copy and Help ■... -
Page 17: On-Screen Display Operation (Osd)
Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen Toggle analog, digital & video connection (DVI-D and video options only) nVent.com/SCHROFF... -
Page 18: On-Screen Display Operation (Osd)
INSTALLATION AND MAINTENANCE GUIDE On-screen Display Operation (OSD) Picture Picture mode : Standard / Vivid / Soft / User mode to choose Brightness : Adjust background black level of the screen image Contrast : Adjust the difference between the image background (black level) and the foreground (white level) Hue: Adjust the screen hue value... -
Page 19: Options
INSTALLATION AND MAINTENANCE GUIDE Options: - HDMI 1.4 ( HDCP 1.4 ) ( 1 ) In some circumstances, if the user connects the LCD to PC via HDMI port for video and audio signals, the LCD may display incorrectly on a full screen. If so, please adjust the display card setting on display size to fix the issue. -
Page 20: Options: Dc Power
INSTALLATION AND MAINTENANCE GUIDE Options : DC Power Model 125V Input rating Input voltage: 12-Volt 24-Volt 48-Volt 110-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V 66 ~ 160V Input current - No load 50 mA 50 mA 50 mA 35 mA - Full load... -
Page 21: Options: Orb-2.1 - 2-Post Rack Mounting Brackets21
INSTALLATION AND MAINTENANCE GUIDE Options: ORB-2.1 - 2-Post Rack Mounting Brackets Step Right bracket ■ Before apply 2-post rack brackets, please release front mounting ears and rear mounting wheels. flat head screw 6#32*4.5mm x 3 ■ Attach left and right mounting brackets to the drawer with the screws below : Left bracket 6#32*3.5 mm screw x 8 ( only for front ) -
Page 22: Notes
SCHROFF TRACER ©2019 nVent. All nVent marks and logos are owned or licensed by nVent Services GmbH or its affiliates. All other trademarks are the property nVent.com/SCHROFF of their respective owners. nVent reserves the right to change specifications without notice. SCHROFF-IM-H85082-Monitor751-UKEN-1907...
