Summary of Contents for Ecotech LCD-213
- Page 1 USER MANUAL Model：LCD-213...
- Page 2 The display: Power On/Off "Ok" button "+" button; inrease the value "-" button; decrease the value Motor power indictor Battery voltage indicator Zone for showing "total km","trip","V", "A","trip time" Zone for showing the PAS mode Speed indicator 10. "Maintenance required" sysmbol...
-
Page 3: Display Operation
Display operation ◎ The display features 4 buttons（single button ） Long press for 2 seconds（photo 1） switch on/off the power。Once switch on the display, quick press the button can show the "odo"，"trip", "volt" , "current" and "time"。 TRIP VOLT TIME CURRENT... - Page 4 Setup/cancel manual operated cruise，turn （photo 2）。 on/off healight 1、Long press for more than 2 seconds ， cruise on，long press again to cancel cruise。 2、Quick press to turn on/off the light。 Boost button for changing pedal assistance 。 Activate the PAS mode （photo 3）S+，...
- Page 5 ◎ The display features 4 buttons（ composite button，for setup the controller） （photo 3） Long press （photo 4） entern to setup the parameter of contrroller） 。 Item No parametter reset The parameter which can be reset containing wheel size(inch), numbers of magnetic jar, LCD screen light, undervoltage value and so on。...
- Page 6 P0 2 (photo 8）：the motor rotate one cycle，the number of sampling signal by display。 P0 3 (photo 9）：The background light of LCD ， optional for 3 levels。 P0 4 (photo 10）：setup the unit of odo and speed。“0” is （KM/H）,“1” is（ MPH）. NOTE：SOME SPECIAL MODELS ONLY（KM/H）, CAN NOT ADJUSTABLE。...
- Page 7 P0 6 (photo 12）：setup the working voltage of battery：24V、 36V、48V。The reset working voltage should be same as the actural battery capacity。 Otherwise the all system will not work。 P0 7(photo 13）：setup the undervoltage value of battery。After setting the battery voltage from P0 6 ，setup the undervoltage value according to different capacoty of battery type，different battery type...
- Page 8 APPENDIX 1 The reference of battery undervoltage value battery type lead LiMn Li-polymer acid LiFePo4 battery battery battery rate voltage（V） 31.5V...
