This section of the manual covers the 25-Watt Loc3-25Tx transmitter.
1. Loc3-25Tx Transmitter Overview
The Loc3 series transmitters are rugged portable transmitters powered by Li-ion rechargeable batteries or alkaline "D" cells.
1
3
4
1.1
Display
1
4 Hz/98 Hz
3 9 0
8
7
*Output Protect Warning
The transmitter checks the line when connected. Output protected against accidental momentary connection to up to 230V
AC (RMS), it will display the "high voltage" warning icon and not allow the transmitter to operate. In addition, the transmitter is
protected by a 4A/250V fuse in the event of excessive voltage or voltage spikes on the line.
1.2
Pushbuttons
1
4
P/N: 4.04.000220
The Loc3-25Tx Transmitter Insert
2
3
mA
6
5
2
3
5
www.vivax-metrotech.com
1
Loc3-25Tx Transmitter
2
2
Li-ion battery tray
3
Carry bag
5
4
AC/DC Adapter, Loc3-25Tx
5
Direct connection lead, Loc3-25Tx
6
6
Ground stake
7
Mini-USB lead
7
1
High Voltage Warning*
2
Active frequency
3
Mode icon
4
Units (mA, volts, ohms)
4
5
Speaker level
6
Output step bar graph
7
Battery level or DC Input icon
8
Digital readout (mA, volts, ohms)
1
On/Off control
2
Frequency select
Information (Volume, Volts, Ohms, Multi-frequencies
3
LCD contrast, Bluetooth menu, Frequency menu)
4
Output decrease/Navigate through the menu
5
Output increase/Navigate through the menu
™
Page 1
