OZCO Project #342 IW - Patio Pergola
V2.00 - Installation Instructions, Specifications and Project Plans are effective 4/27/2017 . This information is updated periodically
1
OZCO Project #342 IW - Patio Pergola
and should not be relied upon after 2 years from 4/27/2017 . Please visit OZCOBP.com to get current information.
Advertisement
Table of Contents
Related Manuals for OWT OZCO 342 IW
Summary of Contents for OWT OZCO 342 IW
- Page 1 OZCO Project #342 IW - Patio Pergola V2.00 - Installation Instructions, Specifications and Project Plans are effective 4/27/2017 . This information is updated periodically OZCO Project #342 IW - Patio Pergola and should not be relied upon after 2 years from 4/27/2017 . Please visit OZCOBP.com to get current information.
-
Page 3: Overview-Front
16'0" 8 " (1'0") (1'0") 7'10 8 " 16 " 13'6 8 " Overview-Front V2.00 - Installation Instructions, Specifications and Project Plans are effective 4/27/2017 . This information is updated periodically OZCO Project #342 IW - Patio Pergola and should not be relied upon after 2 years from 4/27/2017 . Please visit OZCOBP.com to get current information. -
Page 4: Overview-Top
16'0" 12'0" 6" 6" 1'2" typ Overview-Top V2.00 - Installation Instructions, Specifications and Project Plans are effective 4/27/2017 . This information is updated periodically OZCO Project #342 IW - Patio Pergola and should not be relied upon after 2 years from 4/27/2017 . Please visit OZCOBP.com to get current information. - Page 5 12'0" 8 " 4 " 9'0" Overview-Right V2.00 - Installation Instructions, Specifications and Project Plans are effective 4/27/2017 . This information is updated periodically OZCO Project #342 IW - Patio Pergola and should not be relied upon after 2 years from 4/27/2017 . Please visit OZCOBP.com to get current information.
- Page 6 Translucent V2.00 - Installation Instructions, Specifications and Project Plans are effective 4/27/2017 . This information is updated periodically OZCO Project #342 IW - Patio Pergola and should not be relied upon after 2 years from 4/27/2017 . Please visit OZCOBP.com to get current information.
-
Page 7: Bill Of Material
ITEM PART NO. QTY. NUMBER DESCRIPTION 6x6 Post Base 51708 (6x6-PB-IW) 4" Flush Inside 51768 45 (FI45-IW-4) OWT Timber 56651 Bolt 8-10" 2" Timber Bolt Heavy Duty 56680 Washer (OWT- TBW-2) 2" Standard 51717 Rafter Clip (RC-IW-2) OWT Timber 56651 Bolt 8-10"... -
Page 8: Material List
PART QTY. DESCRIPTION NUMBER 51708 6x6 Post Base (6x6-PB-IW) 51717 2" Standard Rafter Clip (RC-IW-2) 56651 OWT Timber Bolt 8-10" 51777 8” Post to Beam Coupler (P2B-SB-IW) 51737 Post to Beam Bolt Inline (P2B-BI-IW) 6x6x8L 6x6x8 2x10x8L 2x10x8 2x10x16L 2x10x16... -
Page 9: Suggested Tools
Suggested Tools (others may be required) OZCO Project #342 IW - Patio Pergola V2.00 - Installation Instructions, Specifications and Project Plans are effective 4/27/2017 . This information is updated periodically and should not be relied upon after 2 years from 4/27/2017 . Please visit OZCOBP.com to get current information. - Page 10 56651 56680 51708 51777 51737 51768 51717 OZCO V2.00 - Installation Instructions, Specifications and Project Plans are effective 4/27/2017 . This information is updated periodically OZCO Project #342 IW - Patio Pergola and should not be relied upon after 2 years from 4/27/2017 . Please visit OZCOBP.com to get current information.
- Page 11 2x10 Cedar Board see template 1 8 with Decora cut see template 1 2x10 Cedar Board 16 with Decora cut both ends 2x6 Cedar Board see template 2 12 with Decora cut both ends 2x2 Cedar Board 16 with chamfer on both ends 2 "...
- Page 12 2 " 2 " 2 " 2 " SCALE 1 : 2 8 " 7" Template 1 V2.00 - Installation Instructions, Specifications and Project Plans are effective 4/27/2017 . This information is updated periodically OZCO Project #342 IW - Patio Pergola and should not be relied upon after 2 years from 4/27/2017 .
- Page 13 2 " 2 " R3" SCALE 1 : 2 8 " 4 " Template 2 V2.00 - Installation Instructions, Specifications and Project Plans are effective 4/27/2017 . This information is updated periodically OZCO Project #342 IW - Patio Pergola and should not be relied upon after 2 years from 4/27/2017 . Please visit OZCOBP.com to get current information.
- Page 14 13'6 8 " 16'2 16 " Locate desired 9'0" center of structure 16 " if site is not level, see Ozco Site Leveling instruction site plan V2.00 - Installation Instructions, Specifications and Project Plans are effective 4/27/2017 . This information is updated periodically OZCO Project #342 IW - Patio Pergola and should not be relied upon after 2 years from 4/27/2017 .
- Page 15 (Hex Cap Nut) provided Tool Required 3/8" Driver (OWT Screw) provided step 1 V2.00 - Installation Instructions, Specifications and Project Plans are effective 4/27/2017 . This information is updated periodically OZCO Project #342 IW - Patio Pergola and should not be relied upon after 2 years from 4/27/2017 . Please visit OZCOBP.com to get current information.
- Page 16 2x10x16 Beams Tool Required 3/8" Driver 2x10x8 Beams (OWT Screw) provided see "Overview- Front" page for Beam spacing step 2 V2.00 - Installation Instructions, Specifications and Project Plans are effective 4/27/2017 . This information is updated periodically OZCO Project #342 IW - Patio Pergola...
- Page 17 Rafter see "Overview- Right" page for Rafter spacing step 3 V2.00 - Installation Instructions, Specifications and Project Plans are effective 4/27/2017 . This information is updated periodically OZCO Project #342 IW - Patio Pergola and should not be relied upon after 2 years from 4/27/2017 . Please visit OZCOBP.com to get current information.
- Page 18 Purlin secure with nails or screws chamfer facing see "Overview- down Top" page for Purlin spacing step 4 V2.00 - Installation Instructions, Specifications and Project Plans are effective 4/27/2017 . This information is updated periodically OZCO Project #342 IW - Patio Pergola and should not be relied upon after 2 years from 4/27/2017 .
