Ampronix AMVX1508 Operation Manual

Auto - scanning with digital control lcd color medical monitor

Advertisement

Quick Links

AUTO - SCANNING WITH DIGITAL CONTROL
LCD COLOR MEDICAL MONITOR
AMVX1508
Operation Manual
For future reference, record the serial number of your display
monitor in the space below :
Serial Number
The serial number is located on the back of the monitor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMVX1508 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ampronix AMVX1508

  • Page 1 AUTO - SCANNING WITH DIGITAL CONTROL LCD COLOR MEDICAL MONITOR AMVX1508 Operation Manual For future reference, record the serial number of your display monitor in the space below : Serial Number The serial number is located on the back of the monitor...
  • Page 3 Ampronix 2007 All other trademarks are the property of their reference owners. This document is subject to change without notice. Ampronix provides this information as reference only. Reference to other vendor’s products does not imply any recommendation or endorsement. Revision Control...
  • Page 4: Table Of Contents

    Cleaning Your Monitor.................. Power Management Function..............Preset Modes....................DDC......................Installation....................Connecting the Power Cord..............Component / RGB / RGBS Connection Instruction......... User Controls....................OSD Screen Basic Section............... OSD Function Description................. Troubleshooting..................Specification of (AMVX1508)..............Classification....................Electromagnetic Compatibility..............Dimension Drawing (mm)................Connectors....................
  • Page 5: Product Description And Intended Use

    • AMVX1508 LCD Monitor and two video cable (1) DVI-A to HD15 VGA cable* (1) DVI-D cable* (1) BNC to RCA adapter (1) DVI-A to BNC Female cable* •...
  • Page 6: Warnings And Cautions

    Federal law (United States of America) restricts this device to use by, or on order of a physician. The Ampronix AMVX1508 monitor has been tested under UL 60601-1 standard and UL listed for Medical application. Ampronix reserves the right to make improvements in the product(s) described herein.
  • Page 7 AMVX1508 5 Warnings 1. Read the operating manual thoroughly and be familiar with its contents prior to using this equipment. 2. Carefully unpack the unit and check if any damage occurred during shipment. 3. Should any solid object or liquid fall into the panel, unplug the unit and have it checked by qualified personnel before operating it any further.
  • Page 8 Cautions 1. The AC Adapter must be plugged into a Grounded power outlet. 2. Use only the proprietary AMVX1508 power supply for the AMVX1508 monitor. Make a proper connection by ensuring that the shrink tubing completely secures the connection between the DC power cord and the extension cord.
  • Page 9: Symbol Explanations

    AMVX1508 7 Symbol Definitions...
  • Page 10: Eu Declaration Of Conformity For Medical Applications

    For a copy of the Declaration of Conformity document, please contact Ampronix and request for AMVX1508 DOC. Prepare for Unpack Before you unpack your monitor, prepare a suitable workspace. You...
  • Page 11: Safety Precaution

    AMVX1508 9 SAFETY PRECAUTION · Avoid placing the monitor, or any other heavy object, on the power cord to prevent fire or electrical shock from damage to the power cord. · Do not expose the monitor to rain, excessive moisture, or dust to avoid fire or shock hazard.
  • Page 12: Power Management Function

    1 seconds On and 1 second Off. The screen is displayed after the vertical and horizontal sync signals are restored. Power Management System The AMVX1508 Medical Monitor power management proposal. Provides four phases of power-saving modes by detecting the horizontal sync signal as shown in the table below.
  • Page 13: Preset Modes

    AMVX1508 11 PRESET MODES i t u *Best resolution 1024 x 768, 60 Hz...
  • Page 14: Ddc

    12 User’s Guide To make your installation easier, the monitor is able to Plug and Play with your system if your system also supports DDC protocol. The DDC (Display Data Channel) is a communication protocol through which the monitor automatically informs the host system about its capabilities, for example, supported resolutions and corresponding timing.
  • Page 15: Connecting The Power Cord

    AMVX1508 13 CONNECTING the POWER CORD * Check first to make sure that the power cord you use is the correct type required for your area. * This monitor has an universal AC adapter that allows operation in either AC 100 - 240 V ac voltage area.
  • Page 16: Component / Rgb / Rgbs Connection Instruction

    14 User’s Guide Component / RGB / RGBS CONNECTION INSTRUCTION For Component (YPbPr) Connection 1. Connect DVI-A to BNC Female cable onto the monitor via DVI port. 2. Connect BNC (YPbPr) cables from the video source to the DVI-A to BNC Female cable.
  • Page 17: User Controls

    AMVX1508 15 USER CONTROLS Front Panel Controls 1. Power LED : Lights up to indicate the power is turned ON. 2. Power Switch : To turn ON or OFF the power. 3. + : To increase the value of the parameter in the OSD you have selected for adjustment.
  • Page 18: Osd Screen Basic Section

    16 User’s Guide OSD Screen Basic Section Brightness / Contrast * Frequency / Phase * (#1) Position * OSD Control * Color Temperature * Utilities * #1 Only available when you using the (VGA) or (Component / RGB) connection * Follow the Standard OSD Operation.Use “-” or “+” button to adjust...
  • Page 19 AMVX1508 17 OSD Screen Basic Section Hue and Saturation * (#2) Sharpness * (#2) Zoom * Input Source Select * Scale Mode * (#3) Scale Mode * (#4) #2 Only available when you using the (C-Video) or (S-Video) connection #3 Only available when you using the (VGA) or (DVI) connection #4 Only available when you using the (C-Video), (S-Video) or (Component/RGB) connection * Follow the Standard OSD Operation.Use “-”...
  • Page 20 18 User’s Guide OSD Screen Basic Section Auto Adjust / Factory Reset * (#5) Factory Reset * (#6) Information (#7) #5 Only available when you using the (VGA) connection #6 Only available when you using the (DVI), (C-Video), (S-Video) or (Component/RGB) connection #7 Different video input may have different information * Follow the Standard OSD Operation.Use “-”...
  • Page 21: Osd Function Description

    AMVX1508 19 OSD Function Description & " " t , t l l l i l l i i t i i t i i l i . t l (#1) Only available when you using the (C-Video), (S-Video) connection...
  • Page 22: Troubleshooting

    20 User’s Guide TROUBLESHOOTING Before sending your LCD monitor for servicing, please check the troubleshooting list below to see if you can self-diagnose the problem. • • • • • • • l l i , t f • •...
  • Page 23: Specification Of (Amvx1508)

    AMVX1508 21 SPECIFICATION l l i t l i - i t ° 0 ° 0 > & " 2 " 9 , I - ° 0 ° 4 ° 0 ° 0 ° 4 ° 0 ° 0 ° 0 , y t &...
  • Page 24: Classification

    51LJ Medical Equipment E215822 This monitor is intended for use in Health Care Facilities model AMVX1508 Equipment is not suitable for use in the presence of flammable anesthetic mixture with air or with oxygen or nitrous oxide. No user serviceable parts inside, ask qualified personnel when accessing inside.
  • Page 25: Electromagnetic Compatibility

    AMVX1508, as this may result in increased electromagnetic emissions or decreased immunity to such emissions. Warning If the AMVX1508 is used adjacent to or stacked with other equipment, observe and verify normal operation of the AMVX1508 in the configuration in which it will be used prior to using it in surgical procedure.
  • Page 26 24 User’s Guide ± ± ± ± ± ± ± ± ± f f i ± f f i ± ± < > < > i l i < > < > t t i t t i t t i t t i t t i t t i...
  • Page 27 AMVX1508 25...
  • Page 28: Dimension Drawing (Mm)

    26 User’s Guide Dimension Drawing (mm)
  • Page 29: Connectors

    AMVX1508 27 Connectors DC Input Connector Jack Power Input The SCD-014-1-A (SHIUA CHYUAN) or equivalent. i r c i t p Video Input 24 pin DVI-I connector. DDWG or equivalent connector. Touch Port 9Pin D-subminiature connector.
